Patton electronics SmartNode 2292 Manual de usuario

Model 2292 & 2294

Leased-Line Extenders over IP

Quick Start Guide

Important

—This is a Class A device and is intended for use in a light industrial environment. It is not

intended nor approved for use in an industrial or residential environment.

Part Number: 07M2292-QS, Rev. A

Revised: April 13, 2009

Sales Ofﬁce: +1 (301) 975-1000

Technical Support: +1 (301) 975-1007

E-mail: [email protected]

WWW: www.patton.com

Model 2292/2294 Quick Start Guide

1.0 Installing the SmartNode extender

1.1 Mounting the SmartNode extender

Place the extender on a desktop or similar sturdy, ﬂat surface that offers easy access to the cables. The extender

should be installed in a dry environment with sufﬁcient space to allow air circulation for cooling.

For proper ventilation, leave at least 2 inches (5 cm) to the left, right, front, and rear of the SmartNode

extender.

1.2 Connecting cables

Install the cables in the following order:

Installing the RJ-11 voice port cable or cables

(see

1.3 “Installing an interface cable on the extender’s voice ports”

on page 3)

• This device contains no user serviceable parts. The equipment shall be

returned to Patton Electronics for repairs, or repaired by qualiﬁed

service personnel.

• Mains Voltage: Do not open the case when the power cord is con-

nected. For systems without a power switch, line voltages are

present within the power supply when the power cord is connected.

• The external power adapter shall be a listed Limited Power Source.

Ensure that the power cable used meets all applicable standards for

the country in which it is to be installed, and that it is connected to a

wall outlet which has earth ground. The mains outlet that is utilized

to power the devise shall be within 10 feet (3 meters) of the device,

shall be easily accessible, and protected by a circuit breaker.

• Hazardous network voltages are present in WAN ports regardless of

whether power to the SmartNode is ON or OFF. To avoid electric

shock, use caution when near WAN ports. When detaching cables,

detach the end away from the SmartNode ﬁrst.

• Do not work on the system or connect or disconnect cables during

periods of lightning activity.

• Before opening the chassis, disconnect the telephone network cables

to avoid contact with telephone line voltages.

• Do not work on the system or connect or disconnect cables during

periods of lightning activity.

• The Interconnecting cables shall be acceptable for external use and

shall be rated for the proper application with respect to voltage, cur-

rent, anticipated temperature, ﬂammability, and mechanical service-

ability.

WARNING

Model 2292/2294 Quick Start Guide

Installing the 10/100 Ethernet port cable or cables

(see

1.4 “Installing the Ethernet cable”

on page 5)

Installing the power input

(see

1.5 “Connecting to external power source”

on page 6)

1.3 Installing an interface cable on the extender’s voice ports

The SmartNode extender comes with at least two voice ports (see

ﬁgure 1

) located on the back of the extender.

The voice ports are connected to analog devices via cables (see

ﬁgure 2

and

ﬁgure 3

) terminated with RJ-11 con-

nectors (see

ﬁgure 4

and Table 1 on page 4 for pin-out information).

Figure 1.

Rear view showing location of Ethernet connectors and voice ports (SmartNode 2294 shown)

Figure 2.

FXS connection

, 1.25A Reset

Ports

ETH 0/1 ETH 0/0

Ethernet connectors Voice ports

RJ-11, male RJ-11, male

, 1.25A Reset

Ports

ETH 0/1 ETH 0/0

Model 2292/2294 Quick Start Guide

Figure 3.

FXO connection

Figure 4.

RJ-11 pinout diagram

Note

Unit must not connect directly to telecom network voltage (TNV).

Table 1.

RJ-11 socket

Pin Signal

3 Ring (-)

4 Tip (+)

RJ-11, male RJ-11, male

PSTN

wall plate

, 1.25A Reset

Ports

ETH 0/1 ETH 0/0

Socket

654321

Plug

123456

Link

100M

Activity

0/0

0/1

0/2

0/3

Enet 0 Ports

Power

Console

Leased-LineExtenderOverIP

SmartNode2294

Run

VoIPLink

Link

100M

Activity

Enet 1

Model 2292/2294 Quick Start Guide

1.4 Installing the Ethernet cable

The SmartNode 2292 Series has automatic MDX (auto-cross-over) detection and conﬁguration on the Ethernet

ports. Any of the two ports can be connected to a host or hub/switch with a straight-through wired cable (see

ﬁgure 5

). Ethernet devices (10Base-T or 100Base-T) are connected to the SmartNode’s Ethernet ports (see

table 2

for port pin-out listing) via a cable terminated with RJ-45 plugs. Because the SmartNode 2294 Series

does not have the MDX feature, a cross-over cable is required when connecting SmartNode 2294 Series devices

to a host (see

ﬁgure 6

Note

Pins not listed are not used.

Figure 5.

Connecting a SmartNode 2294 Series device to a hub

Table 2.

Ethernet 10/100Base-T (RJ-45) port pin-outs (SmartNode 2294 Series)

Pin Signal

1 TX+

2 TX-

3 RX+

6 RX-

Hub

Straight-through cable

RJ-45, male

Tx+

Tx-

Rx+

Rx-

RJ-45, male

1 Rx+

2 Rx-

3 Tx+

6 Tx-

, 1.25A Reset

Ports

ETH 0/1 ETH 0/0

Model 2292/2294 Quick Start Guide

Figure 6.

Connecting to a host

1.5 Connecting to external power source

The extender comes with an external power supply. This section describes installing the power cord into the

extender. Do the following:

Note

Do not connect the power cord to the power outlet at this time.

Insert the barrel type connector end of the AC power cord into the external power supply connector.

Verify that the AC power cord included with your extender is compatible with local standards. If it is not,

contact Patton to ﬁnd out how to replace it with a compatible power cord.

Connect the male end of the power cord to an appropriate power outlet.

Verify that the green

Power

LED is lit.

2.0 Conﬁguring the SmartNode extender

Patton SmartNodes can be used for a wide variety of IP-based network applications. To support and ease the

conﬁguration of the SmartNodes conﬁguration, templates for the most important applications are available on

the Patton server at www.patton.com/voip.

The main steps for setting up a new SmartNode are shown in

ﬁgure 7

The extender power supply automatically adjusts to accept an input voltage from 100

to 240 VAC (50/60 Hz).

Verify that the proper voltage is present before plugging the power cord into the

receptacle. Failure to do so could result in equipment damage.

Host

Cross-over cable

RJ-45, male

Tx+

Tx-

Rx+

Rx-

RJ-45, male

1 TX+

2 TX-

3 RX+

6 RX-

Twisted pair 1

Twisted pair 2

, 1.25A Reset

Ports

ETH 0/1 ETH 0/0

CAUTION

Model 2292/2294 Quick Start Guide

Figure 7.

Steps for setting up a new SmartNode

2.1 Conﬁgure the IP address

Power connection and default conﬁguration

First the SmartNode must be connected to the mains power supply with the power cable. Wait until the 'Run' LED

stops blinking and lights constantly. Now the SmartNode is ready.

The factory default conﬁguration for the Ethernet interface IP addresses and network masks are listed in

table 3

Both Ethernet interfaces are activated upon power-up.

Table 3.

Factory default IP address and network mask conﬁguration

IP Address Network Mask

Interface Ethernet 0 (ETH0)

DHCP DHCP

Interface Ethernet 1 (ETH1)

192.168.1.1 255.255.255.0

Configure IP address

Connect the SmartNode to the network

Load configuration

Console port

Serial

interface

PC or workstation

with VT-100

emulation terminal

Ethernet interface

ETH0 PC or workstation

or VT-100 emulation

terminal

2. Modify configuration

Internet

3. Load configuration

1. Download configuration example

Patton Web server

with configuration examples

Note You can manually configure the

SmartNode. You do not have to load a

configuration file.

Link

100M

Activity

0/0

0/1

0/2

0/3

Enet0Ports

Power

Console

Leased-LineExtenderOverIP

SmartNode2294

Run

VoIPLink

Link

100M

Activity

Enet1

Link

100M

Activity

0/0

0/1

0/2

0/3

Enet0Ports

Power

Console

Leased-LineExtenderOverIP

SmartNode2294

Run

VoIPLink

Link

100M

Activity

Enet1

Link

100M

Activity

0/0

0/1

0/2

0/3

Enet0Ports

Power

Console

Leased-LineExtenderOverIP

SmartNode2294

Run

VoIPLink

Link

100M

Activity

Enet1

Model 2292/2294 Quick Start Guide

Connect with the serial interface

The

Console

port is wired as an EIA-561, RS-232 port. Use the included Model 16F-561 adapter and cable (see

ﬁgure 8

) between the SmartNode’s

Console

port and a PC or workstation’s RS-232 serial interface. Activate the

terminal emulation program on the PC or workstation that supports the serial interface (e.g. HyperTerm).

Figure 8.

Connecting to the terminal

Terminal emulation program settings:

•

9600 baud

•

no parity

•

8 bit

•

1 stop bit

•

1 start bit

•

No ﬂow control

Serial Terminal

Note A Patton Model 16F-561 RJ45 to DB-9 adapter is included with

each SmartNode Series device

Link

100M

Activity

0/0

0/1

0/2

0/3

Enet0Ports

Power

Console

Leased-LineExtenderOverIP

SmartNode 2294

Run

VoIP Link

Link

100M

Activity

Enet1

Model 2292/2294 Quick Start Guide

2.2 Login

Accessing your SmartNode via the local console port (or via a Telnet session) causes the login screen to

display. Type the factory default login:

administrator

and leave the password empty. Press the

Enter

key

after the password prompt.

password: <Enter>

172.16.40.1>

After you have successfully logged in you are in the operator execution mode, indicated by > as com-

mand line prompt. With the commands

enable

and

conﬁgure

you enter the conﬁguration mode.

172.16.40.1>enable

172.16.40.1#configure

172.16.40.1(cfg)#

Enter the following commands for the ﬁrst SmartNode 229x device in the pair:

Copy nvram:a-side-config startup-config

Copy running-config startup-config

Follow the same procedure for the other SmartNode 229x device in the pair:

Copy nvram:b-side-config startup-config

Copy running-config startup-config

Note

The conﬁguration above is only a sample conﬁguration that you may use as an example. You should

specify your own parameters such as your IP address and other related information as required. For

detailed information about conﬁguring and operating your SmartNode, set-up procedures, and trouble-

shooting, refer to the

SmartNode Series SmartWare Software Conﬁguration Guide

on the CD-ROM that

came with your unit.

Reboot both units and connect them back-to-back through their Ethernet 0/1 ports. Voice connections will

automatically be set up between the units.

The steps above will conﬁgure the IP addresses as well as the required conﬁgurations for voice connections.

Model 2292/2294 Quick Start Guide

3.0 Additional Information

Refer to the

Model 2292/2294 Getting Started Guide

located on the CD-ROM shipped with your device and avail-

able online at

www.patton.com/manuals.

For detailed information about:

•

Installing, conﬁguring, operating, and troubleshooting.

•

Warranty, trademark & compliance

A.0 Customer and Technical Support

Toll-Free VoIP support: call

sip:[email protected]

with a VoIP SIP client

Online support: www

.patton.com

E-mail support:

[email protected]

—answered within 1 business day

Telephone support:

•

Standard: +1 (301) 975-1007 (USA), Monday–Friday: 8:00 am to 5:00 pm EST (1300 to

2200 UTC/GMT)

•

Alternate: +41 (0)31 985 25 55 (Switzerland), Monday–Friday: 8:00 am to 5:00 pm CET (0900 to 1800

UTC/GMT)

Fax:

+1 (253) 663-5693

(USA)

or +41 (0)31 985 25 26 (

Switzerland)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Extensor de Patton electronics

Patton electronics

Patton electronics EnviroNET 2100 Series Manual de usuario

Patton electronics

Patton electronics 2156 Manual de usuario

Patton electronics

Patton electronics CopperLink 2158 Manual de usuario

Patton electronics

Patton electronics CopperLink 2168 Manual de usuario

Patton electronics

Patton electronics CopperLink 2155 Manual de usuario

Patton electronics

Patton electronics Industrial Ethernet Extender with LCD Interface... Manual de usuario

Patton electronics

Patton electronics COPPER LINK 2174 Manual de usuario

Patton electronics

Patton electronics CopperLink Ethernet Extenders 2158A Manual de usuario

Patton electronics

Patton electronics 1173R Manual de usuario

Patton electronics

Patton electronics 2156 Manual de usuario

Patton electronics

Patton electronics 2156 Manual de usuario

Patton electronics

Patton electronics 2113 Manual de usuario

Patton electronics

Patton electronics CopperLink Ethernet Booster 2110 Manual de usuario

Patton electronics

Patton electronics 2113 Manual de usuario

Patton electronics

Patton electronics CopperLink 2160 Series Manual de usuario

Patton electronics

Patton electronics CopperLink 2172R Manual de usuario

Patton electronics

Patton electronics CopperLink 2156 Manual de usuario

Patton electronics

Patton electronics SmartNode 2290 Series Manual de usuario

Patton electronics

Patton electronics EnviroNet Ethernet Extenders Manual de usuario

Patton electronics

Patton electronics CopperLINK 2173 Manual de usuario

Patton electronics

Patton electronics SmartNode 2294 Manual de usuario

Patton electronics

Patton electronics EnviroNET 2100 Series Manual de usuario

Patton electronics

Patton electronics CopperLINK 2168B Manual de usuario

Patton electronics

Patton electronics 2173R Manual de usuario

Manuales populares de Extensor de otras marcas

SY HDBT-60T Manual de usuario

Appsys ProAudio

Appsys ProAudio ADX-16 Manual de usuario

Atlona

Atlona RS232 Manual de usuario

IDK

IDK OPF-TH1000-A Manual de usuario

Enable-IT

Enable-IT 824WP Manual de usuario

Worx

Worx Landroid RadioLink WA0864 Hoja de especificaciones

TP-Link

TP-Link TL-WA730RE Manual de usuario

Camplex

Camplex CMX-HDMI-SFPL Manual de usuario

SC&T

SC&T HE03-4K Manual de usuario

Marmitek

Marmitek MegaView70 Manual de usuario

Samsung

Samsung SCS-26UC4 Manual de usuario

Foxun

Foxun SX-GES24 Manual de usuario

MuxLab

MuxLab 500771 Manual de usuario

foxunhd

foxunhd SX-AEX01 Manual de usuario

TERK Technologies

TERK Technologies LFIRX2 Manual de usuario

Devolo

Devolo Audio Extender Manual

Edimax

Edimax EW-7438RPn V2 Manual de usuario

Shinybow USA

Shinybow USA SB-6335T5 Manual de usuario
