Parker D1FV EE Series Manual de usuario

Bulletin MSG11-5715-728/UK

Proportional Pressure

Reducing Valve /

Proportional DC Valve

Brief Operation Manual

Series

D1FV*EE (Design series 13)

D1FB*EE (Design series 18)

D*1FB*EE (Design series 13)

II 2 G c T4 Gb

-20 °C ≤ Ta≤ +40 °C

D*1FB*EEXG371

-20 °C ≤ Ta≤ +60 °C

Parker Hanniﬁn

Manufacturing Germany GmbH & Co. KG

Industrial Systems Division Europe

Gutenbergstr. 38

41564 Kaarst, Germany

Tel.: (+49) 181 99 44 43 0

E-mail: valvesisde@parker.com

Proportional Pressure Reducing Valve /

Proportional DC Valve

Brief Operation Manual

Parker Hanniﬁn Corporation

D1FV-D_1FB-EE 5715-728UK_EXT.indd 19.02.20

Please notice:

Prior to commissioning, this brief operation manual must be read and understood. The safety in-

structions must be strictly observed. Parker disclaims any liability for damage resulting from non-

compliance with the safety instructions listed here.

The detailed and current operation manuals for the individual valve series can be found on the Par-

ker homepage at www.parker.com/isde in the “Support” area. Or download the current manuals

by scanning the following QR codes:

D1FV*EE D1FB*EE D*1FB*EE

The ProPxD parameterizing software can be downloaded free of charge at www.parker.com/isde

in the “Support“ area or directly at www.parker.com/propxd.

FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS DE-

SCRIBED HEREIN OR RELATED ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND

PROPERTY DAMAGE.

This document and other information from Parker-Hanniﬁn Corporation, its subsidiaries and

authorized distributors provide product or system options for further investigation by users

having technical expertise.

The user, through its own analysis and testing, is solely responsible for making the ﬁnal selec-

tion of the system and components and assuring that all performance, endurance, mainte-

nance, safety and warning requirements of the application are met. The user must analyze all

aspects of the application, follow applicable industry standards, and follow the information

concerning the product in the current product catalog and in any other materials provided

from Parker or its subsidiaries or authorized distributors.

To the extent that Parker or its subsidiaries or authorized distributors provide component or

system options based upon data or speciﬁcations provided by the user, the user is respon-

sible for determining that such data and speciﬁcations are suitable and sufﬁcient for all

applications and reasonably foreseeable uses of the components or systems.

WARNING — USER RESPONSIBILITY

Proportional Pressure Reducing Valve /

Proportional DC Valve

Brief Operation Manual

3Parker Hanniﬁn Corporation

D1FV-D_1FB-EE 5715-728UK_EXT.indd 19.02.20

EC declarations of conformity

Proportional Pressure Reducing Valve /

Proportional DC Valve

Brief Operation Manual

Parker Hanniﬁn Corporation

D1FV-D_1FB-EE 5715-728UK_EXT.indd 19.02.20

Proportional Pressure Reducing Valve /

Proportional DC Valve

Brief Operation Manual

5Parker Hanniﬁn Corporation

D1FV-D_1FB-EE 5715-728UK_EXT.indd 19.02.20

Proportional Pressure Reducing Valve /

Proportional DC Valve

Brief Operation Manual

Parker Hanniﬁn Corporation

D1FV-D_1FB-EE 5715-728UK_EXT.indd 19.02.20

Proportional Pressure Reducing Valve /

Proportional DC Valve

Brief Operation Manual

7Parker Hanniﬁn Corporation

D1FV-D_1FB-EE 5715-728UK_EXT.indd 19.02.20

Attention: safety instruction, please note and implement!

A1. Delivery - Please check the delivery immediately after receiving the product if the content is mat-

ching with the specied scope of supply and for apparent damages due to shipping.

A2. Information obligation - Information regarding safety and health in product documentations must

be read and understood before the customer-specic application (e.g. commissioning and mainte-

nance) and before general use (e.g. storage, transport).

A3. Intended use - If our product is not used for the intended purpose, or structurally modied, impro-

perly used, or there is a failure caused by external impact or force majeure, danger may occur which were

not considered by the manufacturer. Damages resulting from this are not the responsibility of Parker.

A4. Marking, name plates -

Instructions applied on the electronics, i.e. wiring diagrams and name

plates, must be observed and maintained legibly.

A5. Work at the electronics and hydraulics - Installation and commissioning of the electronics may

only be allowed by qualied personnel.

All prescribed requirements for the protection of users must be implemented and complied with be-

fore commissioning/installation/dismantling of the hydraulic components. It should be noted that na-

tional schemes for safety must be observed.

Produktspeziﬁsch (P)

P1. Electronic control system - The valve must be operated by a suitable electronic control system.

Connecting to an unsuitable electronic control system may result in irreparable damage to the valve or

the electronic control system.

P2. Temperature - During application, the product may heat up at the surface and exceed the burn

threshold. Even short-term contacts may lead to burns. T

emperatures of more than 80 °C may cau-

se malfunctions of the onboard electronics.

ATEX speciﬁc (E)

E1. ATEX speciﬁc annexes (chapters) must be observed.

E2. Work on the valve - Throughout any installation, commissioning, maintenance and repair work,

it is the responsibility of the operator to ensure that there is no risk of explosion.

Before starting such work, the operator has to ensure that tools and equipment are only used if they

do not damage the valve and they do not leave behind residues that are inammable.

In addition, clean the valve before starting such work, in particular removing dust, liquids and other depo-

sits. Cleaning should be done using a lint-free cloth. Tools may not be used if they might cause a static

charge on use.

E3. Pressure ﬂuids - The pressure uid must have an ignition temperature of at least 50 K above the

maximum surface temperature of the valve (see EN 13463-5 and IEC 60079-4).

Proportional Pressure Reducing Valve /

Proportional DC Valve

Brief Operation Manual

Parker Hanniﬁn Corporation

D1FV-D_1FB-EE 5715-728UK_EXT.indd 19.02.20

D*1FB*EE

D1FV*EE

D1FB*EE

Name plate

Manufacturer's logo and address

CE mark, Ex protection symbol and explosion protection

class of the complete valve to European Directive 2014/34/EU

Serial number (PTS ID: eight-digit number, barcode)

Entire name of the complete valve

Hydraulic data

QR-code (internal use)

Hydraulic symbol

Code for year and month of manufacture

Manufacturer's logo and address

CE mark, Ex protection symbol and explosion protection

class of the complete valve to European Directive 2014/34/EU

Serial number (PTS ID: eight-digit number, barcode)

Entire name of the complete valve

Hydraulical data

QR-code (internal use)

Hydraulic symbol

Code for year and month of manufacture

Manufacturer's logo and address

Serial number (PTS ID: eight-digit number)

QR-code (internal use)

Hydraulic symbol

CE mark, Ex protection symbol and explosion protection

class of the complete valve to European Directive 2014/34/EU

Hydraulic data

Code for year and month of manufacture

Entire name of the complete valve

Proportional Pressure Reducing Valve /

Proportional DC Valve

Brief Operation Manual

9Parker Hanniﬁn Corporation

D1FV-D_1FB-EE 5715-728UK_EXT.indd 19.02.20

Electrical characteristics

Duty ratio [%] 100

Protection class , Ex e mb IIC T4 Gb, IP66 (plugged and mounted correctly)

Solenoid K J J*XG371

Supply voltage [V] 12 24 24

Current consumption [A] 2,3 1,15 1,0

Resistance [Ohm] 3,0 12,0 12,0

Solenoid connection Box with M20x1.5 entry for cableglands. Solenoid identicationas per ISO 9461.

Wiring min. [mm²] 3 x 1.5 recommended

Wiring lenght max. [m] 50 recommended

General

Design

D1FV, direct operated proportional pressure reducing valve

D1FB, direct operated proportional DC valve

D*1FB, pilot operated proportional DC valve

Actuation Proportional solenoid

D1FV; D1FB D*1FB

Size NG06

CETOP 03

NG10

CETOP 05

NG16

CETOP 07

NG25

CETOP 08

NG32

CETOP 10

Mounting interface DIN 24340 / ISO 4401 / CETOP RP121 / NFPA

Mounting position unrestriced

Ambient temperature [°C] -20...+40; XG371: -20...+60

MTTFDvalue [Jahre] 150 75

Weight [kg] 3.5 (2 solenoids),

2.5 (1 solenoid) 9.4 12.8 20.3 69.3

Hydraulic

Max. operating pressure

[bar] Ports P, A, B 350;

port T 185 (D1FV),

210 (D1FB)

Pilot drain internal: P, A, B, X 350; T, Y 185

Pilot drain external: P, A, B, T, X 350; Y 185

Fluid Hydraulic oil as per DIN 51524...535, other on request

Fluid temperature [°C] -20...+40; XG371: -20...+60

Viscosity permitted [cSt] /

recommended [cSt] /

[mm2/s]

20...400

30...80

Filtration ISO 4406; 18/16/13

Max. ow [l/min] D1FV: 10

Min. primary pressure [bar] D1FV: 30

Nominal ow at ∆p=5 bar

per control edge * [l/min]

D1FB*0: 6/12/20;

D1FB*3: 10/20/30 75/90/120 130/200 250/400 1000

Leakage at 100 bar [ml/min] D1FB*0: <50;

D1FB*3: <60 100 200 600 1000

Overlap

[%]

D1FB:

25, electrically

normalized at 10

(see data sheet)

Pilot supply pressure [bar]

[bar] -min. 30 (+ T/Y pressure), max. 350

optimal dynamics at 50

Pilot ow at 100bar [l/min] - <0,5 <1,2 <1,2 <1,2

Pilot ow, step response [l/min] - 2,0 1,9 4,5 18

Static / Dynamic

Step response at 100% step [ms] 30 50 75 100 180

Hysteresis [%] D1FV, D1FB*0: <4;

D1FB*3: <6

Temperature drift solenoid current [%/°K] <0,02

Technical data

With electrical connections the protective conductor (PE W) must be connected according to the relevant regulations.

* Flow rate for different ∆p per control edge: Qx= QNom. · √∆px

∆pNom.

Proportional Pressure Reducing Valve /

Proportional DC Valve

Brief Operation Manual

Parker Hanniﬁn Corporation

D1FV-D_1FB-EE 5715-728UK_EXT.indd 19.02.20

D*1FB*EE

Direct operated proportional pressure reducing valve

Direct operated proportional DC valve

Pilot Operated Proportional DC Valve

D1FV*EE

ISO 4762-12.9 Surface ﬁnish

D1FB, D1FV 4x M5x30 7.6 Nm ±15 %

R 6,3

max

0,01/100

D31FB 4x M6x40 13.2 Nm ±15 %

D41FB 2x M6x55; 4x M10x60 13.2 Nm; 63 Nm ±15 %

D91FB 6x M12x75 108 Nm ±15 %

D111FB 6x M20x90 517 Nm ±15 %

Electrical connection, see D14-2114PD-* in the annex.

D1FB*3*EE, spool/body design D1FB*0*EE, spool/sleeve design

Manual

override

Manual

override

Manual

override

Manual

override

Manual

override

Manual

override

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unidad de control de Parker

Parker

Parker DP-V1 Manual de usuario

Parker

Parker VA01 Series Manual de usuario

Parker

Parker Vansco VMM1210 Manual de usuario

Parker

Parker PEV Manual de servicio

Parker

Parker 2B4 Series Manual de usuario

Parker

Parker S4A-DN Instrucciones de funcionamiento e instalación

Parker

Parker PSST8M23A Instrucciones de instalación y mantenimiento

Parker

Parker 71215 Manual de usuario

Parker

Parker Series PCD 00A-400 Manual de usuario

Parker

Parker S5A-DN Instrucciones de funcionamiento e instalación

Parker

Parker Series DFplus Manual de usuario

Parker

Parker 8902/LS Manual de usuario

Parker

Parker BAM20 Manual de usuario

Parker

Parker ASV5000 Series Manual de usuario

Parker

Parker 810 Series Instrucciones de montaje

Parker

Parker IQAN-XC21 Manual de usuario

Parker

Parker EBV-PR Series Guía del usuario

Parker

Parker PID00A-40X Series Manual de usuario

Parker

Parker MT-700 Series Instrucciones de montaje

Parker

Parker PK2 Manual de usuario

Parker

Parker Series DFplus Manual de usuario

Parker

Parker D Series Manual de usuario

Parker

Parker PQDXXA-Z10 Manual de instalación y operación

Parker

Parker AC30V Series Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
