COMSPHERE 3800

Plus

Modems

U.K. Supplement

Document Number 3980-A2-GK40-10

June 1995

Overview

This document highlights government requirements, safety warnings, installation procedures, features, and

functions that are unique to COMSPHERE

3800Plus modems installed within the United Kingdom. This

document is intended to be used in conjunction with the COMSPHERE 3800Plus Modems User’s Guide,

Document No. 3980-A2-GB30. Please consult the User’s Guide for overall operation of the 3800Plus modem.

Regulatory Information

Ringer Equivalence Number

The Ringer Equivalence Number (REN) is a customer guide indicating approximately the maximum number of

items of apparatus that should be connected simultaneously to the telephone line. The sum of the RENs should

not exceed four. This value includes any BT-provided instrument which may be assumed to have a REN of 1

unless marked otherwise. The REN of this modem is 1.

Connection to Leased Lines

If any other apparatus, including cable or wiring, is connected between the apparatus and the point of connection

to any speechband circuit, then all that other apparatus shall comply with the following:

1. The overall transmission characteristics of all that other apparatus shall be such as to introduce no material

effect upon the electrical conditions presented to one another by the apparatus and the speechband circuit;

and

2. All that other apparatus shall comprise only:

(i) apparatus approved for the purpose of connection between the apparatus and a speechband circuit; and

(ii) cable or wiring complying with a code of practice for the installation of equipment covered by this

part of BS 6328 or such other requirements as may be applicable.

This modem is suitable for connection to BT circuits with signalling at a nominal frequency of 2280 Hz and may

be connected to multipoint or point to point circuits. The apparatus does not require signalling or otherwise use

the frequency range 0–200 Hz.

No d.c. interaction is intended between the modem and the telephone network.

This apparatus may be directly connected to a speechband circuit or connected to a relevant branch system for

speechband circuits.

Connection to Supply Mains

IMPORTANT: The wires in the mains lead supplied with this equipment are coloured in accordance with the

following code:

Blue — Neutral

Brown — Live

As the colours of the cores in the mains lead of this equipment may not correspond with the coloured markings

identifying the terminals in your plug, proceed as follows:

•The core which is coloured blue must be connected to the terminal which is marked with the colour N or

coloured black.

•The core which is coloured brown must be connected to the terminal which is marked with the letter L or

coloured red.

Safety Notice

For pluggable equipment, the mains socket outlet shall be installed near the equipment and be easily accessible.

Interconnection circuits between this modem and any other equipment should be such that the equipment

continues to comply with the requirements of EN41003 for TNV (Telephone Network Voltage) circuits and

EN60950 for SELV (Safety Extra Low Voltage) circuits after making connection between circuits.

The power supply must be properly connected and switched on before the modem will work correctly.

Technical Specifications

Table 1 shows technical specifications that are unique to 3800Plus modems installed in the United Kingdom.

Table 1

Technical Specifications for the United Kingdom

Specifications Description

TRANSMIT LEVEL

Leased Line –13 dBm (factory default setting)

Dial Line –9 dBm (factory default setting)

These settings can only be changed by qualified AT&T Paradyne

service personnel.

TELEPHONE INTERFACE

Leased-Line Connectivity 8-position modular jack (3810

Plus

requires VF cord with BT631A-type

modular plug)

50-pin mass termination (3811

Plus

)

Dial-Line Connectivity 8-position modular jack (3810

Plus

requires VF cord with BT431A-type

modular plug)

50-pin mass termination (3811

Plus

)

Equipment List

Table 2 shows a list of modems and telephone cords available for use in the United Kingdom.

Table 2

Equipment List for the United Kingdom

Equipment Model/Part Number

3810

Plus

4-wire/2-wire standalone

3811

Plus

4-wire/2-wire carrier card

8-position, 4-wire to BT631A modular cord (leased line)

8-position, 2-wire to BT431A modular cord (dial line)

6-position, 4-wire modular cord, 7-foot length

8-position, 8-wire modular cord, 14-foot length

8-position to 6-position crossover modular cord

3980-A2-303

3981-B1-004

035-0170-0031

035-0169-0031

125-0067-0031

125-0053-1431

125-0054-1531

3810

Plus

Input Voltage Requirements

The power supply used with the 3810Plus modem (Figure 1) is designed for an input voltage of 240 Vac

(±10 percent), and an input frequency of 50 Hz.

3810

Plus

Modem Installation

The following procedures describe how to connect the standalone modem to the leased line, dial line, and power

supply.

Before installing your modem, make sure your installation site is clean and well-ventilated. Allow space around

the modem for installing cables and telephone cords, and make sure the modem is located within reach of the

ac power outlet. The distance between your modem and DTE should be minimized if DTE data rates exceed

19,200 bps. Also, low capacitance cables may be necessary for speeds greater than 19,200 bps or distances greater

than 50 feet.

Figure 1 shows how 3810Plus modems are connected to certain TELCO jack types using the supplied cables.

3810

Plus

4-wire/2-wire Leased-Line Connection

Use the following procedure to connect a 3810Plus to the leased-line network interface (use the VF cord labeled

LEASED LINE):

1. Insert the 8-position, 4-conductor modular plug into the jack labeled LEASED (3810Plus), Figure 1.

2. Insert the BT631A-type modular plug into the leased-line network interface.

3810

Plus

Dial-Line Connection

Use the following procedure to connect the modem to the dial network interface (use the VF cord labeled

DIAL LINE):

1. Insert the 8-position, 2-conductor modular plug into the jack labeled DIAL, Figure 1.

2. Insert the BT431A-type modular plug into the dial network interface.

Power Supply Connection

Use the following procedure to connect the standalone modem to an ac power outlet:

1. Make sure the modem’s power switch is in the OFF position.

2. Insert the power supply’s cylindrical connector into the modem’s rear panel power receptacle

(Figure 1).

3. Insert the transformer into the appropriate grounded ac outlet in accordance with requirements as stated in

EN60950: ‘‘For pluggable equipment, the socket outlet shall be installed near the equipment and shall be

easily accessible.”

4. Refer to the Modem Power-Up section in Document No. 3980-A2-GB30 for modem start-up procedures.

POWER

SUPPLY

OFF

NMS PWR ON

495-14711

8-POSITION,

4-CONDUCTOR

KEYED PLUG

FOR

LEASED-LINE

NETWORK

OPERATION

8-POSITION,

2-CONDUCTOR

KEYED PLUG FOR

DIAL NETWORK

OPERATION

BT631A-TYPE

PLUG FOR

LEASED

NETWORK

INTERFACE

BT431A-TYPE

PLUG FOR DIAL

NETWORK

INTERFACE

LEASED

(3810

Plus

)

DIAL

DTE

LEASED

(3820

Plus

)

Figure 1. 3810

Plus

Rear Panel and Power Supply

3811

Plus

Modem Installation

To install the 3811Plus modem (carrier card) into the COMSPHERE 3000 Series Carrier, follow the same

installation procedures described in the 3811Plus Modem Installation section of Document No. 3980-A2-GB30.

For correct power, DTE, dial, and leased-line cabling procedures, refer to the COMSPHERE 3000 Series Carrier,

Installation Manual, Document No. 3000-A2-GA31.

Note that the 3811Plus modem supports the following features:

•Carrier assembly

— 3000-B1-301 – COMSPHERE 3000 Series Carrier with 230 volt power transformer unit

— 3000-B1-701 – COMSPHERE 3000 Series Carrier with 200 volt power transformer unit (Hong Kong)

•Network Interface Modules (NIMs)

— 3000-F1-003 – RJ21X NIM without the Make Busy and Service Line feature

Configuration Options

This section lists functions and configuration options that are unique to the operation of 3800Plus modems

installed in the United Kingdom. The information described in this section differs from what is listed in

Document No. 3980-A2-GB30.

Please note that if a function or configuration option is not listed in this supplement, then your modem’s

functionality and operation follow what is described in Document No. 3980-A2-GB30.

Control Branch — Make Busy/Remove Make Busy Function

The Make Busy function, described in Document No. 3980-A2-GB30, is not offered in the 3810Plus or 3811Plus

modems (3980-A2-404 and 3981-B1-004) for the United Kingdom. If this function is selected from the diagnostic

control panel (DCP), the message Invalid Command appears.

Control Branch — Service Line/Disconnect Service Line Function

The Service Line function, described in Document No. 3980-A2-GB30, is not offered in the 3811Plus modem

(3981-B1-004) for the United Kingdom. If this function is selected from the DCP, the message Invalid

Command appears.

Configuration Tables

Tables 3, 4 and 5 describe configuration options that are different for 3800Plus modems installed in the

United Kingdom.

Table 3

Line Dialer Configuration Options for the United Kingdom

Blind Dial Paus: 2sec

Nxt 2sec

Blind Dial Pause. Set to 2 seconds. Read-only and cannot be changed. Only appears when Dial Tone Detect is disabled.

The AT command is S6=2 and cannot be changed.

NoAnswer Timout: 45sec

Nxt 45sec 30sec 60sec

No Answer Abort Time-out. Set to 45 seconds.

The AT command is S-Register S7=

, where

is a value from 1 to 60 in 1-second increments.

Auto Make Busy: Disable

Nxt Disable

Auto Make Busy. Set to Disable. Read-only and cannot be changed. Only appears when using 3811

Plus

modems.

The AT command is S40=0 and cannot be changed.

MakeBusyVia DTR: Disable

Nxt Disable

Make Busy Via DTR. Set to Disable. Read-only and cannot be changed.

The AT command is S69=0 and cannot be changed.

Table 4

Dial Line Configuration Options for the United Kingdom

Dial Line Rate: 2400(V22bis)

Nxt 2400(V22bis) 1200(V22) 1200(212A) 0–300(V21) 0–300(103J)

Dial Line Rate. Does not support the Bell modulation schemes of 1200 (212A) and 0–300 (103J).

NOTE: The rates and modulations displayed for Dial Line Rate depend on the setting of the Modulation configuration

option. The selection shown above is displayed when the Modulation configuration option is V21/V22/Bell.

The factory default is 28800(V34).

AT command for Dial Line Rate is S-Register S41=

, where

is:

6 = 2400 (V.22bis)

7 = 1200 (V.22)

10 = 0–300 (V.21)

Dial TX Level: –9 dBm

Nxt –9 dBm

Dial Transmit Level. Set to –9 dBm. Read-only and cannot be changed.

The AT commands are &I9 and &J11 and cannot be changed.

V22b Guard Tone: 1800 Hz

Nxt 1800 Hz

V.22bis Guard Tone. Set to 1800 Hz. Read-only and cannot be changed.

The AT command is &G2 and cannot be changed.

Table 5

Leased Line Configuration Options for the United Kingdom

Leased TX Level: –13 dBm

Nxt –13 dBm

Leased Transmit Level. Set to –13 dBm. Read-only and cannot be changed.

The AT command is S45=13 and cannot be changed.

Otros manuales para COMSPHERE 3800PLUS

Tabla de contenidos

Otros manuales de Módem de Paradyne

Paradyne

Paradyne COMSPHERE 3920PLUS Series Manual de usuario

Paradyne

Paradyne COMSPHERE 3911 Manual de usuario

Paradyne

Paradyne Comsphere 3400 Series Manual de usuario

Paradyne

Paradyne COMSPHERE 3920PLUS Series Instrucciones de funcionamiento e instalación

Paradyne

Paradyne DataPort Manual de usuario

Paradyne

Paradyne COMSPHERE 3810 Instrucciones de instalación

Paradyne

Paradyne COMSPHERE 3800 Series Manual de uso y cuidado

Paradyne

Paradyne Hotwire 6210 Instrucciones de funcionamiento originales

Paradyne

Paradyne COMSPHERE 3821PLUS Manual de usuario

Paradyne

Paradyne HotWire 7914 Manual de usuario

Paradyne

Paradyne COMSPHERE 3910 Manual del propietario

Paradyne

Paradyne COMSPHERE 3830 Manual de usuario

Paradyne

Paradyne COMSPHERE 3920PLUS Series Manual de usuario

Paradyne

Paradyne COMSPHERE 3920PLUS Series Manual de usuario

Paradyne

Paradyne COMSPHERE 3811Plus Manual de usuario

Paradyne

Paradyne 6218-A1-200 Manual de usuario

Paradyne

Paradyne COMSPHERE 3920PLUS Series Manual de usuario

Paradyne

Paradyne COMSPHERE 3910 Manual de instrucciones

Paradyne

Paradyne Hotwire 8775 Manual de usuario

Paradyne

Paradyne HotWire 5170 Manual de usuario

Paradyne

Paradyne HotWire 7915 Manual de usuario

Paradyne

Paradyne Hotwire 7975 Manual de usuario

Paradyne

Paradyne StormPort 1020 Manual de usuario

Paradyne

Paradyne COMSPHERE 3910 Manual de usuario

Manuales populares de Módem de otras marcas

Davicom

Davicom DM562AP Manual de usuario

EpiValley

EpiValley TATA indicom SXC-1080 Manual de usuario

Zte

Zte WiMAX Manual de usuario

Intelimax

Intelimax MA-2060 Manual de usuario

SMC Networks

SMC Networks D3CM1604V Manual de uso y cuidado

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manual de usuario

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manual de usuario

Samsung

Samsung AceLink SAM-335A Manual de usuario

Enfora

Enfora Enabler-G Guía de configuración rápida

iRZ

iRZ ATM2-232 Manual de usuario

Zhone

Zhone 6310 Manual de usuario

US Robotics

US Robotics 3453C Manual de usuario

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manual de usuario

Zte

Zte MF823 Manual de usuario

Four-Faith

Four-Faith F1403 Manual de usuario

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manual de usuario

Gemtek

Gemtek WiMAX WIXFBR-103 Manual de usuario

Zoom

Zoom 1070 Series Manual de usuario
