Paradox Digiplex DGP-641 Manual de usuario

Digiplex LCD Keypad

DGP-641

User’s Manual

1.0 TABLE OF CONTENTS

INTRODUCTION ...........................................6

1.1 Legend ..............................................................6

BASIC OPERATION .....................................7

2.1 Auditory Feedback (Beep Tones) .....................8

2.2 Keypad Indicator Lights ....................................8

2.3 LCD Screen ......................................................8

2.4 User Menu .......................................................10

2.5 Partitioned System ...........................................11

2.6 Area Status Display .........................................11

ARMING .......................................................13

3.1 Exit Delay Timer ..............................................13

3.2 Regular Arming ................................................13

3.3 Stay Arming .....................................................14

3.4 Instant Arming ..................................................15

3.5 Force Arming ...................................................16

3.6 One-Touch Buttons ..........................................18

3.7 Keyswitch Arming ............................................19

3.8 Auto-Arming .....................................................19

3.9 Bypass Programming ......................................20

DISARMING .................................................23

4.1 Entry Delay Timer ............................................23

4.2 Disarming an Armed System ...........................23

4.3 Alarm Memory Display .....................................25

ACCESS CODES .........................................26

5.1 Keypad Lock-out ..............................................26

5.2 Erasing Access Codes ....................................26

5.3 System Master Code .......................................27

5.4 User Access Codes .........................................27

TROUBLE DISPLAY ....................................33

6.1 Event Record Display ......................................38

ADDITIONAL FEATURES ...........................40

7.1 Programmable Outputs (PGMs) ......................40

7.2 Keypad Settings ..............................................40

7.3 Set Time & Date ..............................................42

7.4 Programming Chime Zones .............................42

7.5 Panic Alarms ...................................................44

7.6 Quick Function Buttons ....................................45

FIRE AND BURGLAR ALARMS .................46

8.1 Standard Fire Zone ..........................................46

8.2 Delayed Fire Zone ...........................................46

8.3 Fire Safety Tips ...............................................49

8.4 Minimizing Home Fire Hazards .......................49

8.5 Home Fire Warning System ............................50

8.6 Burglar Alarm ...................................................50

TESTING AND MAINTENANCE ..................51

9.1 Burglar Alarm Testing ......................................51

9.2 Fire Alarm Testing ............................................51

9.3 System Maintenance .......................................51

9.4 System Test......................................................52

SYSTEM CHECKLIST .................................53

10.1 Zone Description..............................................53

10.2 Access Codes .................................................56

10.3 Special Buttons and Features .........................60

10.4 Other Information ............................................61

6 User’s Manual

2.0 INTRODUCTION

Your Digiplex™ Security System is an advanced technology

security system that will provide you with reliable security

protection and powerful features that are easy to use. The

elegant and user-friendly Digiplex LCD Keypad will allow you

easy access to your security system's functions and information

at the touch of a button. The 32-character LCD screen will

display messages and menus to guide you through the system’s

operations. Your installer can even customize the messages for

your home or business.

Since you will communicate your instructions to your system

through the keypad, please read this manual carefully and have

your installer explain basic system operation.

2.1 LEGEND

Indicates a warning or an important note.

Indicates useful information or tip.

[WORD]

[NUMBER] Indicates information that must be entered on the

keypad.

Italics Indicates references to features, options or sections.

Digiplex LCD Keypad’s 7

3.0 BASIC OPERATION

Everything you need to know about your security system is

clearly displayed on the large LCD screen. The menus and the

prompt on the LCD screen provide simple, step-by-step

instructions on how to use your system and display what is

occurring in your system. The following sections will introduce

you to the roles of the buttons, the lights, and messages on your

Digiplex LCD Keypad.

Figure 2-1: Basic Overview

8 User’s Manual

3.1 AUDITORY FEEDBACK (BEEP TONES)

When you enter information on the keypad, the keypad will guide

you with beep tones to communicate acceptance or rejection of

your entries.

Confirmation Beep: When an operation (i.e. arming/disarming)

is successfully entered or when the system switches to a new

status/mode, the keypad emits an intermittent beep tone (“BEEP-

BEEP-BEEP-BEEP-BEEP”).

Rejection Beep: When the system reverts to previous status, or

when an operation is incorrectly entered, the keypad emits a tone

(“BEEEEEEEEEEP”).

3.2 KEYPAD INDICATOR LIGHTS

The state of the two colored lights on the keypad (see Figure 2-1

page 7) represents a specific condition in your system.

3.3 LCD SCREEN

The LCD (liquid crystal display) is a 32-character screen that

communicates messages, instructions, and the status of your

system. The backlight, contrast, and scrolling speed are

adjustable (see section 8.2). Your installer can customize many of

the messages to suit your needs.

Digiplex LCD Keypad’s 9

3.3.1 Normal Mode

When no actions are being performed on the keypad, the keypad will

remain in Normal Mode as shown in Figure 2-2 on page 9 and will

automatically display:

•The current status of the zones for every area the keypad is

assigned

•The Alarm Memory Display (see section 5.3) if any alarms have occurred

•The Trouble Display (see section 7.0) if any troubles are occurring

•The current state of the Indicator Lights

Figure 2-2: Normal and Confidential Mode

3.3.2 Confidential Mode

The installer can program keypads not to display the status of your system

automatically by changing the LCD screen to Confidential Mode. In

Confidential Mode:

• The zones and status messages will NOT be displayed

• The Indicator Lights will not illuminate

• Depending on how your keypad was programmed by the installer,

you must either press a button or enter your User Access Code to

illuminate the Indicator Lights and activate Normal Mode.

10 User’s Manual

3.4 USER MENU

Once you enter your User Access Code and are granted access to

the system, the LCD screen will display the User Menu as shown in

Figure 2-3. From this menu you can access various features and

other menus. Depending on the User Options programmed on your

User Access Code, you will have access to some or all of the

features and menus in the User Menu.

Press the desired Action Button (see Figure 2-1, page 7), or

scroll through the menu by using the and buttons on

the right of the keypad and press the button. Once you

have completed an action (i.e. arming, disarming, etc.), the LCD

screen will return to Normal Mode.

Figure 2-3: User Menu

Digiplex LCD Keypad’s 11

3.4.1 Multiple-action

The Multiple-action feature permits you to complete more than one action

after entering the User Menu. If your installer has enabled this feature, the

LCD screen will return to the User Menu after each action so you may

perform another action without having to re-enter your User Access Code.

Press the button to exit the User Menu.

3.5 PARTITIONED SYSTEM

Your installer can design your system to recognize up to four

separate protected areas. A separated system is called a

Partitioned System, which can be useful in situations where

shared security systems are more practical. For example, a

company that has both an office area and a warehouse area can

arm and disarm each area separately and control the access to

each area. Therefore, one person may have access to only one

area, whereas another person may have access to all areas.

Access to the areas is determined by the User Access Code.

3.6 AREA STATUS DISPLAY

In Area Status Display you will be able to see the status of the

areas in a Partitioned System (see section 3.5) for the area(s) the

keypad is assigned. If your LCD screen is in Confidential Mode

(see section 3.3.2), you must first press a button or enter your

User Access Code to activate Normal Mode depending on how

your keypad is programmed.
