Panucatt Devices Azteeq X3 3DP Guía de inicio rápido
Z-AXIS EXTR1Y-AXISX-AXIS STEPPER MOTORS
X-STOP
Y-STOP
Z-STOP
ENDSTOPS
HOTBED
Max Min
POWER INPUT
PC POWER SUPPLY OR
AC/DC SWITCHING PS
12-24VDC +
_
5V FAN
12V FAN LED STRIPS
(OPTIONAL)
FAN OR 2ND HOT-END
HOT-END
HOTEND1
HOTEND2
HEATED BED
EXTR2
PANUCATT DEVICES
meters | controllers | sensors
reprap.org/wiki/Azteeg_X3
LOW POWER SWITCH
(PWM)
USB PORT
MINI B
RESET
STEP SIZE
SELECTOR
0.15in
#6-32 X 4
ATX PWR
ICSP
SD ACTIVITY LED
microSD
(TransFlash)
BUZZER
PANUCATT DEVICES
20
H-BED
_+
H-END
_+
H-END
_+
SERIAL
DIR
STEP
SLEEP
RST
MS3
MS2
MS1
ENABLE
STEPPER DRIVER
ORIENTATION
GND
VDD
2B
1A
2A
2B
GND
VMOT
v1.01
PARALLEL
OR SERIES
THERMISTORS
J11 J2
D23
D25 D27
D29
D17 D16 A5
A12 A4
A11
D31 D32 D22
SDA +5V
SCL
D7 GND
J11
D40
D41
D37
D35
J2
RX
TX
GND
+5V
EXPANSION
BASIC SETTINGS
SELECTARDUINO MEGA 2560 on Arduino IDE
SELECT MOTHERBOARD 33 or 34 on Marlin, Repetier or Sprinter
C(Common)
NO(Normally Open)
Location of Cand NO on switch
may vary. Check markings.
azteeg x3
PANUCATT DEVICES
20
H-BED
_+H-END
_+H-END
_+
SERIAL RX
H-BED
h-end2
h-end1 TX
PANUCATT DEVICES
3D PRINTER CONTROLLER
ENDSTOPS EXPANSION aux Switch
x-AXIS y-AXIS Z-AXIS EXTR1 EXTR2
THERMISTORS
azteegx3
AZTEEG X3 3DP
3d pRINTER CONTROLLER
WIRING DIAGRAM
PANUCATT DEVICES
meters | controllers | sensors
AZTEEG X3 3DP CONTROLLER
WWW.PANUCATT.COM
reprap.org/wiki/Azteeg_X3
2.85"
4.33"
4"
2.53"
