SIP Telephones
KX-UT Series
Home & Business Communications
Panasonic System Networks Company of America
Home and Business Communications
SIP Communication Solutions
Flexible, Cost-Effective
Communications Solutions
Businesses large and small are discovering the proven efciencies and cost benets of a SIP-based communi-
cations system. Transmitting voice and data over a single unied network simplies a company’s IT infrastruc-
ture while VoIP technology combined with a Hosted or Open Source PBX solution lowers monthly phone bills.
Now, changing work locations within your ofce means simply taking your phone with you and plugging it into
an Ethernet port. Extensions and other preferences are preserved when you move the phone to a new location.
A pioneer in world-class telephony solutions, Panasonic offers a wide range of SIP endpoints—from feature-
rich desktop models to cordless options that let you cost-effectively outt an entire ofce. Engineered with
extensive, intuitive provisioning options, the Panasonic line of SIP phones features plug and play simplicity to
get you up and running right away.
The Panasonic SIP Phone UT Series
The latest offering in our line of feature-rich SIP endpoints, the new UT Series combines state-of-the-art telephony
with business-friendly features. Choose from entry-level models with conferencing capability and a low power
consumption mode to executive desk terminals with color, touchscreen displays, wireless headset compatibility and
integration with Panasonic network cameras.
Powerful, Business-friendly Features
Crystal Clear Audio
The UT Series features wide-band, high-denition voice for crisp, precise sound quality whether
delivered via the handset, speakerphone or optional headset. An Echo Cancellation feature combined
with an expanded acoustic chamber further enhances sound quality. All phones in the series feature
wideband-compliant, hearing aid compatible handsets along with built-in, high-quality speakers and
microphones
.
Wireless Capability
Select models in the series feature a built-in electronic hookswitch (EHS), enabling compatibility
with the Plantronics line of DECT wireless headsets—perfect for multi-taskers who need hands-
free convenience during a conversation.
High
Definition
Wireless
Easy Navigation Keys
3-Way Conferencing Capability 2-Position Tilt Function
Color Touchscreen Display
HD Voice
Enabled
(2) 1-Gigabit
Ethernet Ports, PoE
KX-UT670 shown
A Smarter Phone for the Desktop
The award-winning KX-UT670 is equipped with a large, 7-inch LCD touchscreen allowing easy access to
features and installed applications. The open-source operating system is programmable in Java enabling
development of third party business applications. Users can browse the web, access email and check daily
calendar appointments right on the phone. The UT670 can also sync with up to 16 Panasonic network secu-
rity cameras so you can monitor live security video directly from the phone.
Open Source Platform Certification
Like all phones in the Panasonic SIP lineup, the UT Series is certied for Use with BroadSoft® BroadWorks®,
Digium® Asterisk®, Metaswitch, Brekeke and many others*. Panasonic SIP phones are a proven, cost-effective
endpoint solution for small to mid-size companies utilizing the latest in Hosted and Open
Source PBX technology.
*Consult your Panasonic representative for a complete, up-to-date list.
Conferencing Solutions
The convenient 3-Way Conferencing feature, available on all UT series phones, will
help you save time and resources. A paging function lets you quickly get two col-
leagues on the phone with you for a conference even if they’re located at
opposite ends of the country.
Low Total Cost of Ownership
The UT Series is designed to complement your existing com-
munications infrastructure, yielding a low TCO and maximiz-
ing ROI. Select models feature a second data port, so you
can connect a second device to the network without the
time and expense of running additional Ethernet cable.
All UT Series models are PoE ready, thus eliminating
the need for adaptors and saving on electricians’
fees. An energy-saving Eco Mode feature lets you
lower power consumption while a comprehen-
sive, two-year limited warranty protects your
investment well into the life of the phone.
1-52 keys include 24 keys, 12 dial keys, 4 soft keys and 12 feature keys. Feature keys include 2 navigation keys (direction and center key).
KX-UT Series
Specifications
KX-UT670 KX-UT248-B KX-UT136-B KX-UT133-B KX-UT123-B K X - UT 113 - B
LCD Display Color 262,000 Greyscale Graphical Monochrome Graphical
LCD Size 7 inch touchscreen 4.4 inch 242 x 109 pix. – 6 lines 242 x 55 pixels – 3 lines
LCD Contrast No 6 levels 6 levels
LCD Backlight 15/Auto On/Auto/Off On/Auto/Off None
INSTALL OPTIONS
Desk Mount Tilt Yes - 2 Positions No
Wall Mount KX-A434-B (optional) KX-A433-B (optional) KX-A432-B (optional)
Power Adaptor KX-A422 (optional) KX-A239 (optional)
NETWORKING
Ethernet Ports 2 – 10/100/1000 2 – 10/100 1 – 10/100
Power Over Ethernet (PoE) Yes Yes (Class 2)
AUDIO FEATURES
Audio Codec G.711, G.722, G.729a G.711, G.722, G.726, G.729a G.711, G.722, G.726, G.729a
Handset, Speaker,
Headset Volume 15 levels
8 levels
(includes echo cancellation
and distortion prevention)
8 levels (includes echo cancellation and distortion prevention)
Ringtones 32 27
Ringer Volume 7 levels + Off 6 levels + Off 6 levels + Off
Headset Port 2.5 mm
Electronic Hook Switch
Control Port 3.5mm Plantronics compatible None
Hearing Aid Compatible with Hearing Aid TIA-8013
KEYS
Keys (total1)24 (4 pages of 6) 28 52 28
FF Keys N/A 24 24 -
Navigator & Cancel Key On screen + menu keys Yes Yes
SOFTWARE FEATURES
Phone Book Entries Memory Dependent2500 - each with 5 numbers 500 - each with 5 numbers 100 - each with 5 numbers
Call Log Entries 100 in + 100 out 30 incoming calls + 30 outgoing calls
Conferencing 3 parties (within terminal – multi-party dependent on server)
IP FEATURES
SIP Accounts 642
SIP Compatibility RFC 3261 Standard SIP Server, Asterisk®,
BroadSoft®, Metaswitch, Brekeke RFC 3261 Standard SIP Server, Asterisk®, BroadSoft®, Metaswitch
IP Version IPv4
DHCP Client Yes
DNS Yes
HTTP/HTTPS Yes
SNTP Client Yes
VLAN (802.1q) Yes
QoS (DiffServ) Yes
CONFIGURATION
Plug & Play Configuration Server based configuration, TR-069, BroadSoft®Device Management Server
Manual Configuration Internal web Configurator, Local (LCD based) network configuration
KX-UT Series Highlights:
• HD Voice and PoE Enabled
• Two Data Ports for Simplied Wiring and Connecting a Second Device (select models)
• Certied for Use with BroadSoft® BroadWorks®, Digium® Asterisk®, Metaswitch, Brekeke and others
• Extensive CODEC support: G.711μ-law, G.711A-law, G722, G.726, G729a
• Environmentally Friendly—Power Consumption 1W in ECO Mode (select models)
• Two-year Limited Warranty
Home and Business Communications
SIP11127BROr1
Design and specications subject
to change without notice.
Home & Business Communications
Panasonic System Networks Company of America
Three Panasonic Way,
Secaucus, NJ 07094
(201) 348 - 7000
www.panasonic.com/sip
