Basic Operating Instructions

Digital Camera

Model No. DMC-SZ9

Please read these instructions carefully before using

this product, and save this manual for future use.

More detailed

instructions on

the operation of

this camera are contained in

“Operating Instructions for

advanced features (PDF

format)” in the supplied

CD-ROM. Install it on your PC

to read it.

VQT4P98

F0113SM0

GHGF

until

2013/03/18

DMC-SZ9GF&GH-VQT4P98_eng.book 1 ページ２０１３年１月８日　火曜日　午後５時３９分

VQT4P98 (ENG)

Dear Customer,

We would like to take this opportunity to thank you for purchasing this Panasonic Digital

Camera. Please read these Operating Instructions carefully and keep them handy for

future reference. Please note that the actual controls and components, menu items, etc.

of your Digital Camera may look somewhat different from those shown in the

illustrations in these Operating Instructions.

Carefully observe copyright laws.

•Recording of pre-recorded tapes or discs or other published or broadcast material for

purposes other than your own private use may infringe copyright laws. Even for the purpose

of private use, recording of certain material may be restricted.

Information for Your Safety

∫Product identification marking

WARNING:

To reduce the risk of fire, electric shock or product damage,

•Do not expose this unit to rain, moisture, dripping or splashing.

•Use only the recommended accessories.

•Do not remove covers.

•Do not repair this unit by yourself. Refer servicing to qualified service personnel.

The socket outlet shall be installed near the equipment and shall be easily

accessible.

Product Location

Digital Camera Bottom

For Singapore only

Complies with

IDA Standards

DB01017

DMC-SZ9GF&GH-VQT4P98_eng.book 2 ページ２０１３年１月８日　火曜日　午後５時３９分

(ENG) VQT4P98

∫About the battery pack

•Do not heat or expose to flame.

•Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with

doors and windows closed.

∫About the AC adaptor (supplied)

•The unit is in the standby condition when the AC adaptor is connected. The primary circuit is

always “live” as long as the AC adaptor is connected to an electrical outlet.

CAUTION

•Danger of explosion if battery is incorrectly replaced. Replace only with the type

recommended by the manufacturer.

•When disposing the batteries, please contact your local authorities or dealer and ask for

the correct method of disposal.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC or

incinerate.

CAUTION!

To reduce the risk of fire, electric shock or product damage,

•Do not install or place this unit in a bookcase, built-in cabinet or in another

confined space. Ensure this unit is well ventilated.

DMC-SZ9GF&GH-VQT4P98_eng.book 3 ページ２０１３年１月８日　火曜日　午後５時３９分

VQT4P98 (ENG)

∫Cautions for Use

•Do not use any other USB connection cables except the supplied one or a genuine

Panasonic USB connection cable (DMW-USBC1: optional).

•Always use a genuine Panasonic AV cable (DMW-AVC1: optional).

•Always use a genuine Panasonic HDMI micro cable (RP-CHEU15: optional).

Part number: RP-CHEU15 (1.5 m)

Keep this unit as far away as possible from electromagnetic equipment (such as

microwave ovens, TVs, video games etc.).

•If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be

disrupted by electromagnetic wave radiation.

•Do not use this unit near cell phones because doing so may result in noise adversely

affecting the pictures and/or sound.

•Recorded data may be damaged, or pictures may be distorted, by strong magnetic fields

created by speakers or large motors.

•Electromagnetic wave radiation generated by microprocessors may adversely affect this unit,

disturbing the pictures and/or sound.

•If this unit is adversely affected by electromagnetic equipment and stops functioning properly,

turn this unit off and remove the battery or disconnect AC adaptor (supplied)/AC adaptor

(DMW-AC5G: optional). Then reinsert the battery or reconnect AC adaptor and turn this unit

on.

Do not use this unit near radio transmitters or high-voltage lines.

•If you record near radio transmitters or high-voltage lines, the recorded pictures and/or sound

may be adversely affected.

-If you see this symbol-

Information on Disposal in other Countries outside the

European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact your local

authorities or dealer and ask for the correct method of disposal.

DMC-SZ9GF&GH-VQT4P98_eng.book 4 ページ２０１３年１月８日　火曜日　午後５時３９分

(ENG) VQT4P98

Contents

Information for Your Safety......................................................................................... 2

Before Use .................................................................................................................... 5

Standard Accessories.................................................................................................. 6

Names and Functions of Main Parts .......................................................................... 7

Inserting and Removing the Card (optional)/the Battery ......................................... 8

Charging the Battery.................................................................................................... 9

Sequence of operations ............................................................................................ 10

Remote Shooting ....................................................................................................... 12

• Installing the smartphone/tablet app “Image App” ............................................. 12

• Connecting to a smartphone/tablet..................................................................... 13

• Taking pictures via a smartphone/tablet (remote recording)............................... 15

• Playing back pictures in the camera ................................................................... 15

Reading the Operating Instructions (PDF format) .................................................. 16

Installing supplied software ...................................................................................... 17

Specifications ............................................................................................................. 18

Before Use

∫Care of the camera

•Do not subject to strong vibration, shock, or pressure.

•This camera is not dust/splash/water proof.

Avoid using the camera in places with a lot of dust, water, sand, etc.

∫About Condensation (When the lens is fogged up)

•Condensation occurs when the ambient temperature or humidity changes. Be careful of

condensation since it causes lens stains, fungus and camera malfunction.

•If condensation occurs, turn the camera off and leave it for about 2 hours. The fog will

disappear naturally when the temperature of the camera becomes close to the ambient

temperature.

DMC-SZ9GF&GH-VQT4P98_eng.book 5 ページ２０１３年１月８日　火曜日　午後５時３９分

VQT4P98 (ENG)

Standard Accessories

Check that all the accessories are supplied before using the camera.

Product numbers correct as of January 2013. These may be subject to change.

1 Battery Pack

(Indicated as battery pack or battery

in the text)

Charge the battery before use.

2 AC Adaptor

Can be used for charging and

playback.

3 USB Connection Cable

4 CD-ROM

•Software

•Operating Instructions for advanced

features

Install on your PC before use.

5 Hand Strap

•SD Memory Card, SDHC Memory Card and

SDXC Memory Card are indicated as card in

the text.

•The card is optional.

You can record or play back pictures on

the built-in memory when you are not

using a card.

•Consult the dealer or your nearest Service

Centre if you lose the supplied accessories.

(You can purchase the accessories

separately.)

VFF1142

(DMC-SZ9GH)

VSK0775

(DMC-SZ9GF)

VSK0772

VFC4297

DMW-BCL7E

K1HY08YY0032

DMC-SZ9GF&GH-VQT4P98_eng.book 6 ページ２０１３年１月８日　火曜日　午後５時３９分

(ENG) VQT4P98

Names and Functions of Main Parts

1 Motion picture button

2 Shutter button

3Flash

4 Camera [ON/OFF] button

5 Microphone

6 Self-timer indicator

AF Assist Lamp

7 Zoom lever

8Lens

9 Lens barrel

10 LCD monitor

11 [(] (Playback) button

12 Charging lamp

Wi-Fi®connection lamp

13 Speaker

•Be careful not to cover the speaker

with your finger. Doing so may make

sound difficult to hear.

14 [Wi-Fi] button

15 Strap eyelet

•Be sure to attach the strap when

using the camera to ensure that you

will not drop it.

16 [MODE] button

17 Cursor buttons

18 [DISP.] button

19 [MENU/SET] button

20 [Q.MENU] button/

[ ] (Delete/Cancel) button

21 [HDMI] socket

•Do not connect with any cable other

than an HDMI micro cable

(RP-CHEU15: optional). Doing so

may cause malfunction.

22 [AV OUT/DIGITAL] socket

•This socket is also used when

charging the battery.

23 Tripod mount

•A tripod with a screw length of 5.5 mm

or more may damage this unit if

attached.

24 Card/Battery door

25 DC coupler cover

•When using an AC adaptor

(DMW-AC5G: optional), ensure that

the Panasonic DC coupler

(DMW-DCC13: optional) and AC

adaptor are used.

•Always use a genuine Panasonic AC

adaptor (DMW-AC5G: optional).

26 Release lever





789

25 26

201716 18

465141510

23 24

11 12 13

19 21

DMC-SZ9GF&GH-VQT4P98_eng.book 7 ページ２０１３年１月８日　火曜日　午後５時３９分

VQT4P98 (ENG)

Inserting and Removing the Card

(optional)/the Battery

•Check that this unit is turned off.

•We recommend using a Panasonic card.

Slide the release lever in the direction

of the arrow and open the card/battery

door.

•Always use genuine Panasonic batteries

(DMW-BCL7E).

•If you use other batteries, we cannot

guarantee the quality of this product.

Battery: Being careful about the

battery orientation, securely insert it

all the way in, and then check that it is

locked by the lever A.

To remove the battery, move the lever

Ain the direction of the arrow.

Card: Push it securely all the way until

you hear a “click” while being careful

about the direction in which you insert

it.

To remove the card, push the card until it clicks, then pull the

card out upright.

B: Do not touch the connection terminals of the card.

1:Close the card/battery door.

2:Slide the release lever in the

direction of the arrow.

Note

•Keep the Memory Card out of reach of children to prevent

swallowing.

DMC-SZ9GF&GH-VQT4P98_eng.book 8 ページ２０１３年１月８日　火曜日　午後５時３９分

(ENG) VQT4P98

Charging the Battery

•The battery that can be used with this unit is DMW-BCL7E.

•The battery is not charged when the camera is shipped. Charge the battery before use.

•

Charge the battery with the AC adaptor (supplied) indoors (10

C to 30

C).

Insert the battery to this unit, and then connect this unit to the AC

adaptor A(supplied) or a PC B.

CTo power outlet

DUSB connection cable (supplied)

When using the AC adaptor (supplied), observe the following points as improper

connections may cause malfunctions.

•Do not use any other USB connection cables except the supplied one or a genuine

Panasonic USB connection cable (DMW-USBC1: optional).

•Do not use any other AC adaptors except the supplied one.

•Do not use the AC adaptor (supplied) or the USB connection cable (supplied) with other

devices.

•Check that this unit is turned off.

∫About the charging lamp (E)

Lit red: Charging.

Off: Charging has completed. (Charging time: Approx. 150 min)

DMC-SZ9GF&GH-VQT4P98_eng.book 9 ページ２０１３年１月８日　火曜日　午後５時３９分

VQT4P98 (ENG)

Sequence of operations

Press camera [ON/OFF] button.

•The clock is not set when the camera

is shipped. Set the date and time

before using the camera.

Press the shutter button

halfway to focus and then

press it fully to take the picture.

∫Recording Motion Pictures

1Start recording by pressing the

motion picture button.

2Stop the recording by pressing the

motion picture button again.

•Maximum time to record motion pictures

continuously with [AVCHD] is 29 minutes

59 seconds. (DMC-SZ9GF)

•Maximum time to record motion pictures

continuously with [FHD/50i] in [AVCHD] is

29 minutes 59 seconds. (DMC-SZ9GH)

•Maximum time to record motion pictures

continuously with [MP4] is 29 minutes

59 seconds or up to 4 GB.

You can check the recordable time on the

screen. (For [FHD/25p] in [MP4] format,

the file size is large and so the recordable

time will drop below 29 minutes 59 seconds.)

∫Selecting the Recording Mode

Press [MODE] to select the Recording Mode.

¦: Take pictures with automatic settings.

!: Take pictures with your own settings.

: Record while checking the image effect.

: This mode allows you to take panorama pictures.

Û: Take pictures according to scene.

DMC-SZ9GF&GH-VQT4P98_eng.book 10 ページ２０１３年１月８日　火曜日　午後５時３９分

Otros manuales para DMC-SZ9

Tabla de contenidos

Otros manuales de Cámara digital de Panasonic

Panasonic

Panasonic LUMIX DMC-FP1 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-LC5 Manual de usuario

Panasonic

Panasonic Lumix DC-GH5 Instrucciones de instalación y servicio

Panasonic

Panasonic Lumix DMC-G6K Instrucciones de instalación y servicio

Panasonic

Panasonic AG-GH4UP Manual de usuario

Panasonic

Panasonic Lumix DMC-ZR3 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-FX8GN Manual de usuario

Panasonic

Panasonic LUMIX DMC-GF1K Manual de usuario

Panasonic

Panasonic Lumix DMC-LS85 Manual de usuario

Panasonic

Panasonic LUMIX DMC-LX2 Manual de usuario

Panasonic

Panasonic LUMIX DMC-FX60 Manual de usuario

Panasonic

Panasonic DMC-GF6K Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-FX9 Manual de usuario

Panasonic

Panasonic Lumix DMC-TZ60 Especificaciones técnicas

Panasonic

Panasonic Lumix DMC-FX700P Manual de usuario

Panasonic

Panasonic Lumix DMC-GF5X Especificaciones técnicas

Panasonic

Panasonic LUMIX DMC-FP1 Especificaciones técnicas

Panasonic

Panasonic LUMIX DMC-FX50PP Manual de usuario

Panasonic

Panasonic DMC FS20P - Lumix Digital Camera Manual de usuario

Panasonic

Panasonic AW-UE4 Series Manual de usuario

Panasonic

Panasonic DMC-F5EG Manual de usuario

Panasonic

Panasonic Lumix DMC-GX8A Especificaciones técnicas

Panasonic

Panasonic DMC-FT30EG Manual de usuario

Panasonic

Panasonic HDC-HS20P Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
