Quick Guide
Digital Camera/
Lens Kit
Model No. DMC-GM1SK
SQT0922~Cover_mst.fm 1 ページ ２０１５年１月２７日 火曜日 午後１時９分
2
Contents
Preparation/Basic
Care of the camera ...............................3
Standard Accessories ..........................4
Names and Functions of
Components..........................................5
Preparation............................................8
• Attaching the Shoulder Strap ...........8
• Charging the Battery........................8
• Inserting/Removing the Battery........9
• Inserting/Removing the Card
(Optional).........................................9
• Formatting the card
(initialisation)..................................10
• Changing the Lens.........................10
• Setting Date/Time (Clock Set) .......11
Basic Operations ................................12
• Shutter button (Taking pictures) .....12
• Mode dial (Selecting a Recording
Mode) ............................................13
• Function buttons (Assigning
frequently used functions to the
buttons)..........................................14
• Touch screen
(Touch operations).........................14
Calling frequently-used menus
instantly (Quick Menu) .......................15
Setting the Menu.................................16
Recording
Taking Pictures using the Automatic
Function (Intelligent Auto Mode).......17
Taking Pictures with
Manual Focus......................................19
Recording Motion Picture..................21
Recording Snap Movies .....................22
Playback
Playing Back Pictures ....................... 23
Playing Back Motion Pictures........... 23
Deleting Pictures................................ 24
Wi-Fi
What you can do with the Wi-FiR
function............................................... 25
Connecting to a smartphone/
tablet.................................................... 26
Controlling with a Smartphone/
Tablet................................................... 27
Others
Monitor Display .................................. 29
Menu list ............................................. 31
Troubleshooting................................. 33
Specifications..................................... 37
Digital Camera Accessory System
...... 42
DMC-GM1S_eng.book 2 ページ ２０１５年１月１９日 月曜日 午後１時３０分
3
Preparation/Basic
Care of the camera
Do not subject to strong vibration, shock, or pressure.
•The lens, monitor, or external case may be damaged if used in the following conditions.
It may also malfunction or image may not be recorded if you:
–Drop or hit the camera.
–Press hard on the lens or the monitor.
This camera is not dust/drip/water proof.
Avoid using the camera in places with a lot of dust, water, sand, etc.
•Liquid, sand and other foreign material may get into the space around the lens, buttons, etc. Be
particularly careful since it may not just cause malfunctions, but it may also become irreparable.
–Places with a lot of sand or dust.
–Places where water can come into contact with this unit, such as when using it on a rainy day
or at the beach.
Do not place your hands inside the mount of the digital camera body. Since the
sensor unit is a precision apparatus, it may cause a malfunction or damage.
∫About Condensation (When the lens or monitor is fogged up)
•Condensation occurs when the ambient temperature or humidity changes. Be careful of
condensation since it causes lens and monitor stains, fungus and camera malfunction.
•If condensation occurs, turn the camera off and leave it for about 2 hours. The fog will
disappear naturally when the temperature of the camera becomes close to the ambient
temperature.
For smoother recording, we recommend updating the firmware of the interchangeable lens
to the latest version.
•To view the latest information on the firmware or to download the firmware, visit the
support site below:
http://panasonic.jp/support/global/cs/dsc/
(This Site is English only.)
•To check the firmware version of the interchangeable lens, attach it to the camera body and
select [Version Disp.] in the [Setup] menu.
About the firmware of your interchangeable lens
DMC-GM1S_eng.book 3 ページ ２０１５年１月１９日 月曜日 午後１時３０分
Preparation/Basic
4
Standard Accessories
Check that all the accessories are supplied before using the camera.
Product numbers correct as of September 2014. These may be subject to change.
Digital Camera Body
1 Interchangeable Lens¢2
2 Lens Cap¢1
3 Battery Pack
(Indicated as battery pack or battery in the text)
Charge the battery before use.
4 Battery Charger
(Indicated as battery charger or charger in the
text)
5 USB Connection Cable
6DVD
7 Shoulder Strap
¢1 This is attached to the interchangeable lens at the time
of purchase.
¢2 This is attached to the camera body at the time of
purchase.
•SD Memory Card, SDHC Memory Card and SDXC
Memory Card are indicated as card in the text.
•The card is optional.
•Consult the dealer or Panasonic if you lose the supplied
accessories. (You can purchase the accessories
separately.)
VYF3562
H-FS12032
12
DE-A99A
DMW-BLH7
34
6
VFC5071
7
K1HY08YY0031
5
SQT0922~Body_mst.fm 4 ページ ２０１５年１月２７日 火曜日 午前９時５分
5
Preparation/Basic
Names and Functions of Components
∫Camera body
1 Self-timer indicator/
AF Assist Lamp
2 Sensor
3Flash
4 Lens fitting mark (P10)
5 Mount
6 Lens lock pin
7 Lens release button (P10)
8 Flash open lever
•The flash opens, and recording with the flash
becomes possible.
9 Speaker
•Be careful not to cover the speaker with your
finger. Doing so may make sound difficult to
hear.
10 Motion picture button (P21)
11 [(] (Playback) button (P23)
12 Touch screen/monitor (P14)
13 [MENU/SET] button (P16)
14 [ ] (Delete) button (P24)/
[ ] (Quick Menu/Return) button (P15)
15 Control dial
16 [DISP.] button
•Each time this is pressed, the display on the monitor is switched.
17 Cursor buttons
3/[È] (Exposure Compensation)
1/[ ] (White Balance)
2/[ ] (Auto Focus Mode)
4/[ ] (Drive mode)
Single/Burst/Auto bracket/Self-timer
2
3
1
45 67
8
12
14 1613 15 17
910 11
DMC-GM1S_eng.book 5 ページ ２０１５年１月１９日 月曜日 午後１時３０分
Preparation/Basic
6
18 Stereo microphone
•Be careful not to cover the microphone with
your finger. Doing so may make sound
difficult to record.
19 Camera ON/OFF switch (P11)
20 Shutter button (P12)
21 Focus distance reference mark
22 [Fn1] button (P14)
•At the time of purchase, [Wi-Fi] is set to
[Fn1]. (P25)
23 Focus mode lever (P19)
24 Status indicator (P11)/
Wi-Fi® connection lamp
•The lamp lights green when the camera is turned on, and lights blue when it is connected
to Wi-Fi.
25 Mode dial (P13)
26 Shoulder strap eyelet (P8)
•Be sure to attach the shoulder strap when
using the camera to ensure that you will not
drop it.
27 [HDMI] socket
28 [AV OUT/DIGITAL] socket
29 Tripod mount
•A tripod with a screw length of 5.5 mm or
more may damage this unit if attached.
30 Card/Battery door (P9)
31 DC coupler cover
•When using an AC adaptor, ensure that the
Panasonic DC coupler (DMW-DCC15:
optional) and AC adaptor (DMW-AC8:
optional) are used.
32 Release lever (P9)
21 22 25
2019
18
24
23
27
26
28
30 31 3229
DMC-GM1S_eng.book 6 ページ ２０１５年１月１９日 月曜日 午後１時３０分
7
Preparation/Basic
∫Lens
•The interchangeable lens (H-FS12032) does not have a focus ring, but you can use manual
focus by operating the camera. Refer to P19 for details.
H-FS12032 1 Lens surface
2Tele
3 Zoom ring
4Wide
5 Contact point
6 Lens fitting mark (P10)
34 5 612
DMC-GM1S_eng.book 7 ページ ２０１５年１月１９日 月曜日 午後１時３０分
Preparation/Basic
8
Preparation
•Check that the camera is turned off.
•We recommend attaching the shoulder strap when using the camera to prevent it from
dropping.
•Perform steps 1 to 4 and then attach the other side of the shoulder strap.
•Use the shoulder strap around your shoulder.
–Do not wrap the strap around your neck.
It may result in injury or accident.
•Do not leave the shoulder strap where an infant can reach it.
–It may result in an accident by mistakenly wrapping around the neck.
The battery that can be used with this unit is DMW-BLH7.
1Attach the battery paying attention to the direction of the battery.
2Connect the charger to the electrical outlet.
•The [CHARGE] indicator A lights up and charging begins.
∫About the [CHARGE] indicator
•When the [CHARGE] indicator flashes
–The battery temperature is too high or too low. It is recommended to charge the battery again
in an ambient temperature of between 10 oC and 30 oC.
–The terminals of the charger or the battery are dirty. In this case, wipe them with a dry cloth.
Attaching the Shoulder Strap
Charging the Battery
On: Charging.
Off: Charging has completed.
(Disconnect the charger from the electrical socket and detach the
battery after charging is completed.)
1
2 3
4
90°
DMC-GM1S_eng.book 8 ページ ２０１５年１月１９日 月曜日 午後１時３０分
9
Preparation/Basic
∫Charging time
•The indicated charging time is for when the battery has been discharged completely.
The charging time may vary depending on how the battery has been used.
The charging time for the battery in hot/cold environments or a battery that has not been
used for a long time may be longer than normal.
•Always use genuine Panasonic batteries (DMW-BLH7).
•If you use other batteries, we cannot guarantee the quality of this product.
•Being careful about the battery orientation, insert all the way until you hear a locking sound and
then check that it is locked by lever A.
Pull the lever A in the direction of the arrow to remove the battery.
•Push it securely all the way until you hear a “click” while being careful about the direction in
which you insert it.
To remove the card, push the card until it clicks, then pull the card out upright.
∫About cards that can be used with this unit
SD Memory Card (8 MB to 2 GB)
SDHC Memory Card (4 GB to 32 GB)
SDXC Memory Card (48 GB, 64 GB)
Charging time Approx. 130 min
Inserting/Removing the Battery
Inserting/Removing the Card (Optional)
DMC-GM1S_eng.book 9 ページ ２０１５年１月１９日 月曜日 午後１時３０分
Preparation/Basic
10
∫About the motion picture recording and SD speed class
Confirm the SD Speed Class (the speed standard regarding continuous writing) on a card
label etc. when you record a motion picture. Use a card with SD Speed Class with
“Class 4” or more for [AVCHD]/[MP4] motion picture recording.
•Please confirm the latest information on the following website.
http://panasonic.jp/support/global/cs/dsc/
(This Site is English only.)
•Keep the Memory Card out of reach of children to prevent swallowing.
Format the card before recording a picture with this unit.
Since data cannot be recovered after formatting, make sure to back up necessary
data in advance.
Select [Format] in the [Setup] menu.
•Confirmation screen is displayed. It is executed when [Yes] is selected.
•When attaching or detaching the interchangeable lens (H-FS12032), retract the lens barrel.
•Change lenses where there is not a lot of dirt or dust.
•Do not press the lens release button A when you attach a lens.
∫Detaching the lens
1Attach the lens cap.
2While pressing on the lens release button B, rotate
the lens toward the arrow until it stops and then
remove.
e.g.:
Formatting the card (initialisation)
Changing the Lens
DMC-GM1S_eng.book 10 ページ ２０１５年１月１９日 月曜日 午後１時３０分
Tabla de contenidos
Otros manuales de Cámara digital de Panasonic
Panasonic
Panasonic LUMIX DMC-FS12 Especificaciones técnicas
Panasonic
Panasonic Lumix DMC-ZS15 Manual de usuario
Panasonic
Panasonic VDR-D105 Manual de usuario
Panasonic
Panasonic DMCFZ40 - DIGITAL CAMERA - ADVANCED FEATURES Manual de usuario
Panasonic
Panasonic Lumix DMC-TS4 Manual de usuario
Panasonic
Panasonic LUMIX DMC-GM1 Manual del propietario
Panasonic
Panasonic Lumix DC-FZ1000 II Instrucciones de instalación y servicio
Panasonic
Panasonic DMC-GH4 Instrucciones de instalación y servicio
Panasonic
Panasonic Lumix DMC-FX100 Manual de usuario
Panasonic
Panasonic S-S50E Manual de usuario
Panasonic
Panasonic Lumix DMC-TZ57 Manual de usuario
Panasonic
Panasonic Lumix DMC-G10W Manual de usuario
Panasonic
Panasonic Lumix DMC-LS1 Manual de usuario
Panasonic
Panasonic Lumix DMC-FS20 Manual de instrucciones
Panasonic
Panasonic LUMIX DMC-FZ2EN Manual de usuario
Panasonic
Panasonic DMC-F7A Manual de usuario
Panasonic
Panasonic Lumix DMC-GF7K Especificaciones técnicas
Panasonic
Panasonic DMC-ZS25K Instrucciones de instalación y servicio
Panasonic
Panasonic Lumix DMC-FZ50 Manual de usuario
Panasonic
Panasonic LUMIX DMC-FX48 Manual de usuario
