Oventrop Regtronic RD-W Manual de usuario

EN "Regtronic RD-W" System controller

Operating instructions

Valves, controls + systems

Read these operating instructions in their entirety before initial

operation!

Read separate installation instructions for installation and

electrical connection!

The installation instructions of all other system components

must be observed!

All safety notes must be observed!

Hand the operating instructions over to the user of the system!

The operating instructions have to be kept for later reference!

Content "Regtronic RD-W"

2/36

1. General information 3

1.1 Supply an contact 3

1.2 Important information regarding operating instructions 3

1.3 Note regarding declaration of conformity 3

1.4 Storage 3

1.5 General conditions of sales an delivery 3

1.6 Copyright an protective rights 3

2. Safety notes 4

2.1 Correct use 4

2.2 Denition of the warning notices 4

2.3 Residual dangers 5

3. Construction and function 6

3.1 Product components 6

3.2 Control of "Regudis" dwelling stations 7

3.2.1 Buffer storage cylinder loading 8

3.2.2 Riser control 8

4. Operation fundamentals 9

4.1 Display 9

4.2 Starting sequence, status page, navigation elements 9

4.3 Commissioning 12

4.3.1 Password entry for "professional" 12

4.3.2 Basic settings, date/time 15

4.3.3 Sensor error in case of incomplete installation 17

5. Setting of system parameters 18

5.1 Sitemap storage cylinder loading and riser control 18

5.2 Modication of presettings and control parameters 20

5.2.1 Buffer storage cylinder loading 20

5.2.2 Riser control 26

6. Manual operation 31

7. Software updates and factory settings 32

8. Decommissioning and disposal 34

3/36

General information "Regtronic RD-W"

1. General information

1.1 Supply an contact

•Controller with console an terminal

board

•SD card with software

• 4 x Cover strip

• 16 x Strain relief

•Wall fixing material

• 2 x Manual (installation & operation)

Contact address

OVENTROP GmbH & Co. KG

Paul-Oventrop-Straße 1

D-59939 Olsberg

Technical service

Phone: +49 2962 82 234

(Mo.-Fr. 7:30-16:30 h)

1.2 Important information regarding

operating instructions

These operating instructions have to be

read, understood and applied by any person

working on the controller and using it.

Commissioning has to be carried out by a

heating, gas and water specialist.

1.3 Note regarding declaration of

conformity

The separate installation inst-

ructions (doc. no. 134209380)

have to be taken into account for

the installation and necessary

electrical connections of the con-

troller.

Installation must only be carried

out by a qualied electrician.

1.4 Storage

Oventrop GmbH & Co. KG hereby declares

that the system controller “Regtronic RD-

W” complies with the basic requirements

and the other relevant provisions of the rel-

evant EC Directives.

The declaration of conformity can be ob-

tained from the manufacturer.

1.5 General conditions of sales an

delivery

The product must only be stored under the

following conditions:

• Storage temperature: +5°C up to

+45°C.

• Do not store in open air, keep dry and

free from dust.

• Do not expose to aggressive uids

or heat sources and protect from UV

rays.

• Protect from mechanical agitation

during transport.

Packing material is to be disposed of in an

environmentally friendly manner.

Oventrops general conditions of sales and

delivery valid at the time of supply are

applicable.

1.6 Copyright an protective rights

These installation and operating

instructions are copyrighted and are

exclusively designed for persons involved

with the product.

4/36

Safety notes "Regtronic RD-W"

2. Safety notes

2.1 Correct use 2.2 Denition of the warning notices

WARNING

Warning symbol and signal are

indicating a dangerous situa-

tion with moderate risk which

may lead to death or serious

injury if not avoided.

NOTICE

Signal word (without warning

symbol) indicating a possible

danger to property.

The Oventrop system controller "Regtronic

RD-W" serves the control engineered

integration of "Regudis W" dwelling

stations into the heat supply. It provides for

a heating water temperature according to

requirements in the buffer storage cylinder

(storage cylinder loading control) and the

supply pipe of the riser for the connected

"Regudis" dwelling stations (heating circuit

control). The system-specic parameters

for an adaptation of the control to the

requirements can be entered via a user

interface.

Any use with dwelling stations of other

manufacturers is not allowed.

On principle, the controller must only be

used in a technically perfect condition, ac-

cording to its intended use and in complian-

ce with these operating instructions.

These installation and operating instruc-

tions show warnings which are displayed

by symbols. The symbols are linked to sig-

nal words which dene the seriousness of

the danger which arises from a situation.

CAUTION

Warning symbol and signal are

indicating a dangerous situ-

ation with low risk which may

lead to minor or moderate in-

jury or damage to property if

not avoided.

5/36

Safety notes "Regtronic RD-W"

2.3 Residual dangers

The following residual dangers for persons

and property exist during installation and

operation:

WARNING

Danger to life due to electric

shock!

• Opening of the controller casing

and all electrical connections must

only be carried out by a qualied

electrician.

• The following 5 safety

regulations must be observed

during installation and cabling:

- Disconnect

- Protect against accidental

restart

- Check that no voltage is

present

- Earth and short-circuit

- Cover adjacent live parts

• Please make sure that the

controller can be disconnected

from the power supply with an all-

pole disconnecting device (plug/

socket or 2-pole circuit breaker)

• The local safety directive must be

observed.

• Installation must only be carried

out in dry indoor areas.

• The low voltage connections

(e.g. sensor connections) must

not be mixed up with the 230 V

connections.

• Newly installed controllers must

only be energized once cabling of

all system components has been

carried out.

• Completely disconnect the

controller from the power supply

before removing any connected

system components (e.g. for

maintenance and repair).

CAUTION

Risk of burns due to hot

components and pipework!

A modication of the parameter settings

may lead to very high ow temperatures

in the supply riser. There is a risk of

burns from hot surfaces.

• Wear safety gloves during

installation and maintenance, if

required.

• When installing a new heating

system, the pipework has to be

insulated.

6/36

Construction and function "Regtronic RD-W"

3b Flap

3c Back plate

4Terminal assignment plate

5Terminal block

6Cover strips

1 System controller "Regtronic RD-W"

1a Touch screen

1b LED

2 SD card

3a Console

3. Construction and function

Illustr. 1

3.1 Product components

7/36

Construction and function "Regtronic RD-W"

3.2 Control of "Regudis" dwelling stations

The Oventrop system controller "Regtronic

RD-W" (1) serves the control engineered

integration of dwelling stations "Regudis W"

into the heat supply.

The controller provides for a heating water

temperature according to requirements

in the buffer storage cylinder (6) and the

supply pipe of the riser supplying the

connected "Regudis" dwelling stations.

The stations require a permanent differential

pressure of at least 300 mbar and a

minimum temperature in the supply pipe.

The controller activates the heat generator

(7) and the loading pump (8) in such a

way that the buffer storage cylinder (6) is

loaded with as constant a temperature as

possible. Depending on the heating water

temperature in the buffer storage cylinder,

loading is started or interrupted.

The differential pressure (5) and the ow

and return temperatures (4) are detected

by sensors in the heating circuit riser. Based

on the detected values, the riser pump (3,

differential pressure) and the mixing valve

(2, ow temperature) are activated by the

controller (1).

1 System controller "Regtronic RD-W"

2 Actuator/mixing valve

3 Riser pump1

Flow/return (PT1000)

5 Differential pressure sensor1

6 Buffer storage cylinder

6a Buffer storage cylinder sensors (PT1000)

7 Heat generator

8 Loading pump

9 Sensor ow temperature control

(PT1000)

10 Outside temperature sensor (PT1000)

Graphical overview controller controlled heating installation:

Illustr. 2

This system illustration shows all possible control tasks. Control engineered subtasks may,

however, also be carried out by the system controller (1). Loading of the buffer storage

cylinder can, for instance, also be carried out by a control integrated in the heat generator.

In- and outputs at the system controller (1) which are not in use remain free!

1 If differential pressure control is carried

out by the riser pump (3), a differential

pressure sensor (5) is not required.

Regudis

...

Supply Return

Regumat

8/36

Construction and function "Regtronic RD-W"

3.2.1 Buffer storage cylinder loading

Loading of the buffer storage cylinder

with as constant a loading temperature as

possible results in the following advantages:

• optimised storage cylinder loading

• low return temperature to the heat

generator

• fewer burner starts

Depending on the system constellation,

distinction is made between the following to

variants of storage cylinder loading:

• 0-10 V activation

• Two point activation (volt free)

3.2.2 Riser control

The supply of heat to the connected dwelling

stations according to requirements is

guaranteed by the riser control. The actual

temperatures in the supply and return pipe

are constantly detected by two sensors

(4) and are transmitted to the controller (1)

which activates the motor-operated mixing

valve (2) on this basis.

If, for instance, the temperature in the return

pipe of the riser drops signicantly as water

is drawn off at several draw off points in

parallel, the mixing valve (2) will be fully

opened temporarily, i.e. colder return water

will no longer be added to the supply

pipe in order not to undercut its required

minimum temperature. An excessive ow

temperature is avoided by adding return

water to the supply pipe.

The current differential pressure is

detected by another sensor (5). If the

differential pressure in the return pipe drops

quickly, an immediate correction leading to

a short-term increase of the ow pressure

during an adjustable period will be carried

out by the riser pump (3).

9/36

Operation fundamentals "Regtronic RD-W"

Illustr. 3

4. Operation fundamentals

The display of the controller has two basic

functions:

• Retrieval of system-speci c

information, especially regarding

temperatures and pressure

conditions.

• Entry of system-speci c parameters

for the control of storage cylinder

loading and of the heating

temperature in the supply pipe of

the riser supplying the connected

"Regudis" dwelling stations.

1. red (boot sequence)

2. yellow (hardware initialisation)

3.  ashing green (detection of sensor

values)

4. green continuously (= service)

You will also hear a beep.

The controller is be ready for operation after

about one minute.

The following display, hereafter referred to as

"status page", will appear  rst (illustr. 5).

Illustr. 4

4.1 Display

The display is designed as a touch screen

(1a), i.e. the icons and menu buttons can

be selected directly.

4.2 Starting sequence, status page,

navigation elements

As soon as the controller is energized,

the LED will glow successively in the

following sequence:

10/36

Operation fundamentals "Regtronic RD-W"

Illustr. 5

Status page

S9 Outside temperature sensor (see installation instructions 5.5)

S5 Flow temperature sensor (from heat generator) (see installation instructions

5.4.2 and 5.4.3)

S4 Storage cylinder temperature sensor (upper) (see installation instructions 5.2)

S2 Storage cylinder temperature sensor (lower) (see installation instructions 5.2)

S7 Differential pressure sensor (in the riser) (see installation instructions 5.1.4)

S10 Riser temperature sensor (supply) (see installation instructions 5.1.3)

S11 Riser temperature sensor (return) (see installation instructions 5.1.3)

Info Heat generator or loading pump (ON/OFF) (see installation instructions 5.3.2 or

5.4.3)

Outputs (A1...16) (see installation instructions doc. no. 134209380) used by the

controller software are displayed here; outputs which are currently switched (for

instance for the pump) are highlighted in green.

A3 Mixing valve opens (see installation instructions 5.1.1)

A4 Mixing valve closes (see installation instructions 5.1.1)

A5 Heat generator / Loading pump volt free (see installations instructions

5.3.2 and 5.4.3)

A8 Riser pump 230 V (see installation instructions 5.1.2)

A9 Loading pump 230 V (see installation instructions 5.4.1, 5.4.2 and 5.4.3)

A13 Heat generator 0-10 V (see installation instructions 5.3.1)

A14 Riser pump 0-10 V (see installation instructions 5.1.2)

A15 Loading pump 0-10 V (see installation instructions

5.4.2 and 5.4.3)

A16 Supply voltage 5 V for differential pressure sensor

(see installation instructions 5.1.4)

Setting date and time

via direct selection (see

4.3.2)

S10 S11

Info

OFF

Mo 20.06.2016 10:36

75.0ºC

20.0ºC 0.60 bar

70.0ºC 68.0ºC

Tabla de contenidos

Otros manuales de Controladores de oventrop

oventrop

oventrop Aktor M ST L Modbus Manual de usuario

oventrop

oventrop Regtronic BS/2-B Manual de usuario

oventrop

oventrop REGTRONIC PM Manual de usuario

oventrop

oventrop Aktor M ST L Manual de usuario

oventrop

oventrop Hydromat DTR Manual de usuario

oventrop

oventrop NR 230 Manual de usuario

oventrop

oventrop 1158021 Manual de usuario

oventrop

oventrop Hydromat DTR Series Manual de usuario

oventrop

oventrop REGTRONIC PC Manual de usuario

oventrop

oventrop Regumaq K Manual de usuario

oventrop

oventrop Regtronic RX Manual de usuario

oventrop

oventrop R-Tronic RT B Manual de usuario

oventrop

oventrop Aktor M Manual

oventrop

oventrop ENOCEAN R-Tronic RT B Manual de usuario

oventrop

oventrop Aktor T ST 1012953 Manual

oventrop

oventrop OV-5 Manual del propietario

oventrop

oventrop Unibox E RTL Manual de usuario

oventrop

oventrop EnOcean Aktor MH CON B Manual de usuario

oventrop

oventrop REGTRONIC PX Manual de usuario

oventrop

oventrop REGTRONIC PX Manual de usuario

oventrop

oventrop Regtronic RM Instrucciones de funcionamiento

oventrop

oventrop Regtronic RH HT Instrucciones de funcionamiento

oventrop

oventrop R-Tronic Manual de usuario

oventrop

oventrop Hydromat DP DN 25 Manual

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario

oventrop Regtronic RD-W Manual de usuario

Manuales populares de Controladores de otras marcas
