One Stop Systems ExpressBox 3T-V3 Manual de usuario

ExpressBox 3T-V3

Model:EB3T-V3

www.onestopsystems.com

User Manual

One Stop Systems

ExpressBox 3T-V3 | 2

Table of Contents

Preface 5

Advisories 5

Safety Instructions 6

1 Introduction 8

PCI Express Features 8

Thunderbolt Features 8

1.1 Core of EB3T Thunderbolt 3 9

1.2 Parts List 10

1.3 Specifications 11

1.4 Main Components 11

1.5 Parts of EB3T 12

1.6 Thunderbolt 3 card 13

1.6.1 Power and indicator LEDs. 13

1.6.2 J1 connector 14

1.7 Backplane 14

1.7.1 PCIe card Slots 15

1.7.2 J6 15

1.7.3 SW1 switch module 15

1.7.4 SW2 switch 15

1.7.5 JP5 16

1.7.6 J2, J3 and J4 16

1.7.7 J10 16

1.7.8 J11 connector 17

1.8 Backplane LEDs 17

1.8.1 LED1 17

1.8.2 LED2 18

1.8.3 LED3 18

1.9 SLOT LEDS 18

1.9.1 LED5 for SLOT1 18

1.9.2 LED6 for SLOT2 18

1.9.3 LED7 for SLOT3 18

1.9.4 LED8 for SLOT4 19

1.10 Pre-Installation Information 19

1.11 Tools Required for Installation 19

2 Hardware Installation 20

2.1 Installation-Procedures Overview 20

2.2 Open Enclosure 20

One Stop Systems

ExpressBox 3T-V3 | 3

2.3 Remove Card slot Cover 20

2.4 Install PCIe Cards 21

2.4.1 Add-in System Blower (Optional) 22

2.5 Attach Power Cord 23

2.6 Connect Thunderbolt Cable 23

2.7 Start Host Computer 24

3 Verify Installation 25

3.1 Hardware 25

3.2 Thunderbolt™ 3 Interface Card & LEDs 26

3.2.1 LED status: Fully Operational mode 26

3.2.2 LED status: Standby mode 26

3.3 Backplane & LEDs 26

3.3.1 LED1 27

3.3.2 LED2 27

3.3.3 LED5 for SLOT1 27

4 Software Installation 28

4.1 How to check EB3T device on Mac OS 10.10 (or newer) 28

4.2 How To Check PCIe cards on Mac OS (10.10 or newer) 30

4.3 Thunderbolt Aware Driver is required for PCIe cards 30

4.4 PCIe Card and Slot# assignment 31

4.5 How to Check EB3T Device on Windows 10 32

4.6 How to check PCIe card on Windows10 33

5 Important Technical Information 34

5.1 Shipping / Transporting the unit 34

5.2 Fan Specifications 34

5.3 Fan Speed and Noise Adjustment 35

5.3.1 Tools 35

5.3.2 Steps to adjust the fan speed 35

5.4 How to replace the fan 37

5.5 How to install the fan 38

5.6 Installation of x16 PCIe card 38

5.7 Pro Tools HDx cards Installation 39

5.7.1 Using HDx power cable for Mac 39

5.7.2 Using HDx power cable for PC 40

5.8 Power Supply (300 WATT) 42

5.8.1 Power Supply Specifications 42

5.9 Auxiliary Power Cables 47

5.10 Attaching Displays 48

5.11 How to Remove Thunderbolt3 card 48

One Stop Systems

ExpressBox 3T-V3 | 4

5.12 How to remove Power Supply 49

6 Installation on Laptop PC 51

6.1 Installation on laptop running Windows 10 51

6.1.2 How to Check EB3T-V3 device and PCIe card 54

6.2 Installation on Laptop running Linux 56

6.2.1 How to Check EB3T device 56

6.2.2 How to Check PCIe card device 58

7 GPU Installation 59

7.1. Step 1: Set Up EB3T-V3 59

7.1.1 Install Thunderbolt Software and reboot 60

7.2 Step 2: Install GPU 63

7.3 Step 3: Install GPU Software 63

7.4 Quadro GPU Driver Installation Guide 63

7.5 How to verify Thunderbolt device and eGPU card 64

8 Troubleshooting 68

9 How to Get More Help 72

9.1 Contacting Technical Support 72

9.2 Returning Merchandise 72

9.3 Online Support Resources 72

Appendix A Compliance 73

One Stop Systems

ExpressBox 3T-V3 | 5

Preface

Advisories

Five types of advisories are used throughout this manual to provide helpful information, or to alert you to the potential for hardware damage

or personal injury.

NOTE

Used to amplify or explain a comment related to procedural steps or text.

IMPORTANT

Used to indicate an important piece of information or special “tip” to help you

CAUTION

Used to indicate and prevent the following procedure or step from causing damage to the equipment.

WARNING

Used to indicate and prevent the following step from causing injury.

DANGER or STOP

Used to indicate and prevent the following step from causing serious injury or significant data loss

Disclaimer: We have attempted to identify most situations that may pose a danger, warning, or caution condition in this manual. However, the

company does not claim to have covered all situations that might require the use of a Caution, Warning, or Danger indicator.

One Stop Systems

ExpressBox 3T-V3 | 6

Safety Instructions

Always use caution when servicing any electrical component. Before handling the expansion chassis, read the following instructions and safety

guidelines to prevent damage to the product and to ensure your own personal safety. Refer to the “Advisories” section for advisory

conventions used in this manual, including the distinction between Danger, Warning, Caution, Important, and Note.

Always use caution when handling/operating the computer. Only qualified, experienced, authorized electronics personnel should

access the interior of the computer and expansion chassis per UL and IEC 60950-1

The power supplies produce high voltages and energy hazards, which can cause bodily harm.

Use extreme caution when installing or removing components. Refer to the installation instructions in this manual for precautions

and procedures. If you have any questions, please contact Technical Support.

WARNING

Never modify or remove the radio frequency interference shielding from your workstation or expansion unit. To do so may

cause your installation to produce emissions that could interfere with other electronic equipment in the area of your

system.

When Working Inside a Computer

1. Before taking covers off a computer, perform the following steps:

2. Turn off the computer and any peripheral devices.

3. Disconnect the computer and peripheral power cords from their AC outlets or inlets in order to prevent electric shock or system

board damage.

In addition, take note of these safety guidelines when appropriate:

To help avoid possible damage to systems boards, wait five seconds after turning off the computer before removing a component,

removing a system board, or disconnecting a peripheral device from the computer.

When you disconnect a cable, pull on its connector or on its strain-relief loop, not on the cable itself. Some cables have a connector

with locking tabs. If you are disconnecting this type of cable, press in on the locking tabs before disconnecting the cable. As you pull

connectors apart, keep them evenly aligned to avoid bending any connector pins. Also, before connecting a cable, make sure both

connectors are correctly oriented and aligned.

CAUTION

Do not attempt to service the system yourself except as explained in this manual. Follow installation

instructions closely.

One Stop Systems

ExpressBox 3T-V3 | 7

Protecting Against Electrostatic Discharge

Electrostatic Discharge (ESD) Warning

Electrostatic Discharge (ESD) is the enemy of semiconductor devices. You should always take precautions to eliminate any

electrostatic charge from your body and clothing before touching any semiconductor device or card by using an

electrostatic wrist strap and/or rubber mat.

Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedures to reduce the risk of

damage to components. We strongly encourage you to follow proper ESD procedures, which can include wrist straps and smocks, when

servicing equipment.

You can also take the following steps to prevent damage from electrostatic discharge (ESD):

When unpacking a static-sensitive component from its shipping carton, do not remove the component’s anti-static packaging

material until you are ready to install the component in a computer. Just before unwrapping the anti-static packaging, be sure you

are at an ESD workstation or are grounded.

When transporting a sensitive component, first place it in an anti-static container or packaging.

Handle all sensitive components at an ESD workstation. If possible, use anti-static floor pads and workbench pads.

Handle components and boards with care. Do not touch the components or contacts on a board. Hold a board by its edges or by its

metal mounting bracket.

One Stop Systems

ExpressBox 3T-V3 | 8

1 Introduction

ExpressBox 3T-V3 provides an 'outside-the-box' solution for using PCIe® cards with Thunderbolt-equipped computers. High-performance work

flows are possible by connecting a Thunderbolt equipped computer to an ExpressBox 3T-V3 containing PCIe cards such as video capture, media

transcoding, audio processing, and fast data storage. In addition, because Thunderbolt is also based on DisplayPort technology, you can daisy

chain a high-resolution display with your ExpressBox 3T-V3. Thunderbolt cable is sold separately.

Thunderbolt 3 allows you to connect your computer / notebook to multiple 4K displays, attach external storage devices, transfer large data

files, or capture or move RAW video from high-end camera. Thunderbolt 3 is capable of transmitting at a rate of 40Gbps (maximum speed),

which is faster than a USB 3.1 rate of 10 Gbps or USB 3.0 of 5Gpbs.

EB3T-V3 uses Thunderbolt3 - USB Type-C 3.1 thin cable / connector. The EB3T-V3 connects to Thunderbolt 3 port and USB Type-C ports. The

Thunderbolt 3 cable provides four times the data and twice the video bandwidth while also supplying power. Gives the user the power to use

for 4K video, single-cable docks with charging and built-in 10 G networking

PCI Express Features

Supports three full-length cards

This chassis includes a PCI Express Gen 3 switch with 48 lanes.

Three slots (slot2, slot3 and slot4) are all x8 lanes Gen3.

Slot 1 is the upstream slot, it is x16 lane connector, Gen3. However, thunderbolt3 card is only x4 lane.

Therefore, the upstream slot will operate at x4 lane Gen 3

Thunderbolt Features

High-speed Thunderbolt connection –Thunderbolt 3 40 Gbps. Thunderbolt 2: 20Gbps. Thunderbolt1: 10Gbps

o–Bi-directional, dual-protocol (PCI Express and Display Port)

o4 lanes of PCI Express Gen 3

Automatic power-up control by computer

USB 3.1 (10 Gbps) –compatible with existing USB devices and cables

DisplayPort 1.2 –compatible with existing DisplayPort displays, devices, and cables.

oConnect DVI, HDMI, and VGA displays via adapters

Power (based on USB power delivery)

oUp to 100W system charging

o15W to bus-powered devices

Thunderbolt Networking

o10Gb Ethernet connection between computers

Daisy-chain (up to six devices) or end-point device

Lowest latency for PCI Express audio

One Stop Systems

ExpressBox 3T-V3 | 9

Slot#

PCIe SLOT1

PCIe SLOT2

PCIe SLOT3

PCIe SLOT4

1.1 Core of EB3T Thunderbolt 3

*The PCIe slot connector is x16, but the Thunderbolt3 card is x4. Therefore, upstream port will operate at x4 speed.

Figure 1.2

Figure 1.4

One Stop Systems

ExpressBox 3T-V3 | 10

Note:

SLOT#3 is designated closed-type; as there is a heatsink at the end of the slot NO.3, a x16 card cannot be installed in the slot.

1.2 Parts List

Number

Qty

Item

ExpressBox 3T-V3 - Three Slot PCIe Expansion Chassis

Fan Blower

Carry Bag

U.S. Standard 115V Power Cord
