SELF TESTING MAINTAINED EMERGENCY LUMINARIES

GENERAL

These luminaires are used indoors (ta 40 C)

where emergency light is needed.

Each lum inaire m ust be pe rmanent ly

connected to mains power supply. In normal

operation the illumination LEDs are lit as well

as the green indicating charge LEDs when

the battery is charging. In case of a mains

power supply failure the luminaire will light

the led strip automatically in emergency

mode. When the mains power supply is

re s to r ed t he d ev i ce t u r n s to n or m al

operation.

INSTALLATION

To install the luminaire follow the installation

instructions on page 3.

Battery Charging

The battery charging is completely

controlled. Thereby, the best possible battery

maintenance is achieved, as well as the

elongation of its duration. When the battery

has completely charged, it charges with a

maintenance current.

Battery Cut-off

The luminaire enters in this operation when

the mains power supply fails and battery has

lost all its energy. During this operation the

luminaire enters the idle state and battery

consumption is negligible, in order to be

protected from deep discharge.

Manual Operational Test

This test can be done by pressing the test

button. The light source and the emergency

circuit of the device is monitored for 3 sec.

The manual test can be conducted only if the

mains power supply and the battery is

connected. During this test period all

indication LEDs are OFF.

Automatic Operational Test

This test includes all the operations that

provide the manual test and is conducted

automatically every 15 days. In order to be

performed, the mains power supply and the

battery should be connected.

Automatic Autonomous Test

The Automatic Autonomous Test is conducted

and measures the device’s back up operation

and emergency duration. This test is

conducted automatically every 6 months. In

order to be performed, the mains power

Thank you for your trust in our products

Olympia Electronics - European manufacturer

220-240V AC/50-60Hz

3 h

24 h

IP30

3.6V/1.5Ah (Ni-Cd)

3.4W / 3.6VA

EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3

5 to 40 C

up to 95%

ABS/PC,PC

532gr.453gr.

292 x 111 x 54 mm

110lm / 110lm

12 White LEDs

TECHNICAL CHARACTERISTICS (for LED MODULE Specs. see page 3)

OPERATION TEMPERATURE RANGE

RELATIVE HUMIDITY

EXTERNAL DIMENSIONS

CONSTRUCTION MATERIALS

TYPICAL WEIGHT

GUARANTEE

OPERATION VOLTAGE

MAXIMUM POWER CONSUMPTION

BATTERY

CHARGING TIME

INDICATIONS - CONTROLS

MINIMUM AUTONOMOUS DURATION

DEGREES OF COVER PROTECTION

PRODUCED IN ACCORDANCE WITH

ILLUMINATION (230V AC / emergency)

VIEWING DISTANCE 22m

ILLUMINATION SOURCE

Battery charge Fault indication LEDs, TEST button

3 years (1 year for the battery)

1.5 h

16 h

3.6V/600mAh(Ni-Cd)

GR-2100/ST GR-2110/ST

923211004_09_004

Page 2 from 4

supply and the battery should be connected

and fully charged. If the battery is not fully

charged, the test is postponed until the

battery is completely charged. If during this

test, the autonomy is less than nominal then

the battery fault led turned on continuously

and the battery must be replaced.

Back Up Operation

The autonomous duration of battery during

emergency mode is at least 180 minutes.

During emergency mode, a light source test

is also performed.

Resetting Errors

Push the Test button for more than 5

seconds, to delete all the indicated LED

errors. Then the device enters regular

operation mode.

Indication LED status (with connected

mains power supply).

Charge (Green LED)

On: Good charge condition.

Οff: No battery (No charging current

or disconnected battery).

Fault (Red LED)

Οn : Faulty LED strip (must be replaced) or

emergency circuit (must be checked by an

authorized personnel).

Blink (With Charge LED ON): Autonomy or

low battery problem (the battery must be

replaced).

Οff: LED strip and battery ok.

ΑΤΤΕΝΤΙΟΝ!!!

1. Operations for installation, maintainance

or testing must be done by authorized

personnel only.

2. The device must be connected to the

ma i n s p o w er s u p p l y t h r o u g h a f u s e

dependent by the total amount of the line’s

power load.

3. In case of inactive use for a period greater

than 2 months, disconnect the battery by

pulling out the battery’s connector.

4. I s not allowed to discard batteries in to

common trash bins, they must be

discarded only

t i

in battery recycling

points. Do not incinerate.

NOTE: LED= Light Emitting Diode

LABELING EXPLANATION:

X: Self contained

1: Maintained (*)

A: Including test device

G: Internally illuminated

90: 1.5 hour duration

180: 3 hours duration

NOTE!! The installer should fill in, on the

specification label, the letter G if the luminaire is

used as a safety sign.

(*) Maintained operation: The luminaire lights

its illumination source, when it is powered by

the mains power supply or not.

Non Maintained operation: The luminaire

lights its illumination source, only in power

supply’s failure.

Battery replacement.

It can be done only by a competent person

and after the mains interruption.

1. Dismantle the device (step 1 of the

installation instructions).

2. Disconnect the connector and remove the

old battery.

3. Connect the new battery with the same

type (step 4 of the installation instructions)

and place it in the position of the old one.

4. Follow the step 6 of the installation

procedure and power the device.

The light source contained in this luminaire shall only be replaced by the manufacturer, or his

agent, or a similar qualified person.

NOTE! The light source is non-user replaceable.

X19 0A

923211004_09_004

Page 3 from 4

Figure 1 2

Figure 2

1. To instal the device you have to dismantle carefully the

device with a flat screwdriver as shown on figure 1.

2. Pass the mains cables through the hole

(point 1 on figure 2). The luminaire must be connected to

a permanent electrical installation to ensure the

immobilization of the cable.

3. Mount the base plastic on the wall by using the included

mounting accessories in points 2 and 3 on figure 2.

4. Connect the battery`s cable with the appropriate terminal

(figure 3).

5. Connect the mains cables to the respective detachable

terminal block. Ν for neutral, L for live wire and L1 for the

maintained operation. The L1 wire can be connected to an

external switch to control the maintained or non maintained

operation of the luminaire. For permanent maintained

operation use two wires to power the luminaire, Ν for neutral

and L for live wire, and link the L and L1.

6. Refit with care the removed plastic parts and power on

the luminaire.

External

switch

Link

Controled operation

of the illumination source

Permanent

operation of the illumination source

N N

LL L1L1

NOTE!!

After finishing the installation you must power the luminaire at least for 24 hours for

battery charging to perform the nominal autonomy.

INSTALLATION INSTRUCTIONS

Figure 3

LED MODULE CHARACTERISTICS

Manufacturer

Model Number

Voltage Range

Connections

Nominal Power

Temperature (tc)

Olympia Electronics S.A

45 °C max. across the board

Non reversible connection between main pcb and led module

8.7-10.8VDC

780mW

3105165

GR-2110/STGR-2100/ST

923211004_09_004

Page 4 from 4

WARRANTY

Olympia Electronics guarantees the quality, condition and operation of the goods. The period of

warranty is specified in the official catalogue of Olympia Electronics and also in the technical leaflet,

which accompanies each product. This warranty ceases to exist if the buyer does not follow the

technical instructions included in official documents given by Olympia Electronics or if the buyer

modifies the goods provided or has any repairs or re-setting done by a third party, unless Olympia

Electronics has fully agreed to them in writing. Products that have been damaged can be returned to

the premises of our company for repair or replacement, as long as the warranty period is valid.

Olympia Electronics reserves the right to repair or to replace the returned goods and to or not charge

the buyer depending on the reason of defection. Olympia Electronics reserves the right to charge or

not the buyer the transportation cost.

HEAD OFFICE

72nd km. O.N.R. Thessaloniki-Katerini

P.C. 60300 P.O. Box 06 Εginio Pierias Greece

www.olympia-electronics.gr

[email protected]
