End-User Installation Manual

Spray Height Controller

Improving the competitiveness of Industry and

Agriculture through Precision Measurement

Printed in Canada

Reorder P/N: UC4+BC+HD3-INSTE Rev B (Hardi OEM)

NOTICE

NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without the requirement to update

products sold previously. Every effort has been made to ensure the accuracy of the information contained in this manual. The technical information in

this manual was reviewed at the time of approval for publication.

1 INTRODUCTION

Congratulations on your purchase of the NORAC UC4+ Spray Height Controller. This system is

manufactured with top quality components and is engineered using the latest technology to provide

operating features and reliability unmatched for years to come.

When properly used the system can provide protection from sprayer boom damage, improve sprayer

efficiency, and ensure chemicals are applied correctly.

Please take the time to read this manual completely before attempting to install the system. A thorough

understanding of this manual will ensure that you receive the maximum benefit from the system.

YOUR INPUT CAN HELP MAKE US BETTER! If you find issues or have suggestions regarding

the parts list or the installation procedure, please don’t hesitate to contact us via the information

given below:

Phone: 1-800-667-3921 Canada (Toll Free)

1-866-306-6722 United States (Toll Free)

0-800-404-8389 United Kingdom (Toll Free)

1-306-664-6711 all other regions

E-mail: [email protected]

Website: www.norac.ca

2 PARTS LISTS

The parts that come with your UC4+ Sprayer Boom System are listed below. The item number on the left

side of this table references each part.

Table Item Part Number Name Quantity

C10* 44650-35 CABLE POWER GENERIC PULL-TYPE 1

E01* 4461BC+HD UC4 PLUS BOOM CONTROL PANEL HARDI 1

M01 446BC+MAN7 OPERATOR MANUAL UC4+ SPRAY HEIGHT CONTROL 1

M13* UC4+BC+HD3-INSTE MANUAL INSTALLATION END-USER HARDI 1

ROP

3 INSTALLATION

1. Install the UC4+ Control Panel (E01) in the

cab of the sprayer. Mount the panel where it

will be clearly visible and within easy reach

of the operator.

A good spot to mount the UC4+ control

panel is on the right hand side of the cab to

the Roll Over Protection Bar (ROP). Four

pilot holes for the screws provided need to be

drilled to facilitate the control panel

mounting.

Another option is to purchase an adapter for

the flexible panel mount that has a 3/8" NC

threaded stud on the end to bolt through an

existing mount. You can find these at your

local outdoor store as a RAM mount part

number RAM-B-236. (See

http://www.ram-mount.com/)

Figure 1 – Control Panel Mounting

ROP

Figure 2 – Cable Configurations: C10 and C11

2. Connect the power cable (C10) to the UC4+

Control Panel in the sprayer cab. Ensure that

both plugs (P16A and P4) are connected to

the panel (Figure 2).

Ensure that the UC4+ Control Panel is

OFF for the remaining installation

(Bottom of switch pressed IN). Use

caution when handling the 12V power

line of the sprayer wiring.

3. Connect the 3-pin AMP connector (P3) on

the C10 cable to an auxiliary power

connection inside the sprayer cab. If an

appropriate connector(s) cannot be found it

may be necessary to cut off the connector(s)

and splice into the existing wiring.

4. Route the free end (R16) of C10 to the

exterior of the cab, to the vicinity of the

tractor hitch. This connector will provide

your hitch connection. Route the cable

accordingly and connect it to P16 on the

sprayer. The procedure for the installation of

the UC4+ system is now complete.

5. For optimal performance of the UC4 system,

there should be very little play at the hitch

clevis. The addition of polymer washers can

help tighten up this connection (Figure 3).

Figure 3 – Hitch Point

6. Power on the UC4+ panel, if “HD3” shows

up as your sprayer type, you can start the

ReTune process as per the UC4+ Operator

Manual. This will tune the UC4+ hydraulic

parameters to your tractor hydraulic system.

7. If no type is selected yet, start the Install as

per the UC4+ Operator Manual.

Canada

NORAC Systems International Inc.

CALL TOLL FREE: 1-800-667-3921

(306)664-6711

SHIPPING ADDRESS:

3702 Kinnear Place

Saskatoon, SK

S7P 0A6

United States

Norac, Inc.

CALL TOLL FREE: 1-866-306-6722

(763)786-3080

SHIPPING ADDRESS:

1290 Osborne Rd NE, Suite F

Fridley, MN

55432-2892

www.norac.ca
