Nokia HS HS 4W Manual de usuario

User Guide for the Wireless Boom

Headset (HS-4W)

9231046

Issue 1

HS-4W_EN_1st_tab.fm Page 1 Monday, August 15, 2005 11 47 AM

DECLARATION OF CONFORMITY

We, NOKIA CORPORATION declare under our sole responsibility that the product HS-4W is in conformity with

the provisions of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be

found at http://www.nokia.com/phones/declaration_of_conformity/.

Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form

without the prior written permission of Nokia is prohibited.

Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other product and

company names mentioned herein may be trademarks or tradenames of their respective owners.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Nokia operates a policy of continuous development. Nokia reserves the right to make changes and

improvements to any of the products described in this document without prior notice.

Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental,

consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by applicable law, no warranties of any

kind, either express or implied, including, but not limited to, the implied warranties of merchantability and

fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document.

Nokia reserves the right to revise this document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you.

In some countries there may be restrictions in using Bluetooth devices. Check with your local authorities.

9231046

Issue 1

HS-4W_EN_1st_tab.fm Page 2 Monday, August 15, 2005 11 47 AM

Contents

EnglishEnglish

Contents

Introduction.............................. 4

Bluetooth wireless technology.......... 4

Bluetooth passcode............................... 5

1. Getting started ..................... 6

Overview .................................................. 6

Chargers and batteries......................... 8

Charging the battery ............................ 9

When the battery charge falls

low........................................................ 10

Pairing the headset with

a compatible phone............................ 10

Disconnecting the headset from

the phone ........................................... 11

Reconnecting the paired headset

to the compatible phone ............... 12

Troubleshooting ................................... 12

2. Using the headset .............. 14

Switching the headset on or off ..... 14

Placing the headset over the ear. 15

Call functions........................................ 15

Answering and ending a call ........ 16

Automatic answer............................ 16

Rejecting a call ................................. 16

Redialling the last dialled

number................................................ 16

Muting an ongoing call.................. 16

Voice dialling..................................... 17

Adjusting the earphone volume ...... 17

Switching the call between phone

and headset........................................... 17

Using the headset with several

paired phones ....................................... 17

Resetting the headset ........................ 18

3. Battery information ........... 19

Charging and Discharging................. 19

Care and maintenance........... 21

HS-4W_EN_1st_tab.fm Page 3 Monday, August 15, 2005 11 47 AM

Introduction

The Wireless Boom Headset HS-4W can be connected to a compatible phone that

supports Bluetooth technology. This allows you freedom to make and receive calls

while on the move or in the office.

Read this user guide carefully before using the headset. In addition to this Wireless

Boom Headset HS-4W user guide, read also the phone’s user guide, which provides

important safety and maintenance information. Keep the headset out of reach of

small children.

■Bluetooth wireless technology

The Wireless Boom Headset HS-4W is specially designed for compatible Nokia

phones that support Bluetooth technology. The headset can, however, be used with

any compatible Bluetooth devices that support the compatible Handsfree or

Headset profiles. (A profile is a set of Bluetooth commands that the phone uses to

control the headset).

The Bluetooth technology makes it possible to connect compatible communication

devices without using cables. A Bluetooth connection does not require that the

phone and the headset be in line of sight, but both devices should be within 10

HS-4W_EN_1st_tab.fm Page 4 Monday, August 15, 2005 11 47 AM

Introduction

English

metres of each other. Connections can be subject to interference from

obstructions, such as walls, or other electronic devices.

The Wireless Boom Headset HS-4W is compliant with and adopts the Bluetooth

Specification 1.1. However, interoperability between the Wireless Boom Headset

HS-4W and other Bluetooth-enabled products is not guaranteed because it

depends on compatibility. For more information on the compatibility between

the Wireless Boom Headset HS-4W and other Bluetooth-enabled products,

please check with your dealer.

■Bluetooth passcode

You need a Bluetooth passcode for pairing the headset with a compatible phone.

The passcode is 0000.

HS-4W_EN_1st_tab.fm Page 5 Monday, August 15, 2005 11 47 AM

Getting started

1. Getting started

Note: The use of wireless devices may be restricted in some situations.

Observe any restrictions and obey all signs and instructions concerning

use of wireless devices.

■Overview

HS-4W_EN_1st_tab.fm Page 6 Monday, August 15, 2005 11 47 AM

Getting started

English

The headset contains the following parts, as shown in Figure 1.

1 - Power key: Switches the headset on and off, or mutes the ongoing call.

2 - Speaker: Relays the caller’s voice.

3 - Indicator light: Displays the current status of the headset. The indicator

light can be yellow, green or red. If the light is yellow, a Bluetooth connection is

active. The green and red lights indicate the status of a call and charging.

4 - Volume control key: Increases/decreases the earphone volume during a call.

5 - Microphone: Picks up your voice.

6 - Answer/end key: Answers or ends the call. This key can also be used for voice

dialling, redialling and switching an active call between the headset and the

compatible phone.

7 - Charger connector

Before you can start using the headset, you must:

• Charge the battery

•Pair a compatible phone with the headset

HS-4W_EN_1st_tab.fm Page 7 Monday, August 15, 2005 11 47 AM

Getting started

■Chargers and batteries

Check the model number of any charger before using it with this device. The

Wireless Boom Headset HS-4W is intended for use with the following chargers:

AC-1, ACP-7, ACP-8, ACP-9, ACP-12, and LCH-12.

HS-4W_EN_1st_tab.fm Page 8 Monday, August 15, 2005 11 47 AM

Getting started

English

Warning! Use only batteries and chargers approved by Nokia for use

with this particular enhancement. The use of any other types will

invalidate any approval or warranty applying to the enhancement, and

may be dangerous.

For availability of approved batteries and chargers, please check with your local

dealer.

When you disconnect the power cord of any enhancement, grasp and pull the

plug, not the cord.

■Charging the battery

1. Connect the charger cable to the headset as shown in Figure 2. Before

connecting the charger cable to the headset, open the flap.

2. Connect the charger to an AC wall outlet. The red indicator light is displayed

during charging. Charging the battery fully may take up to 2 hours 45

minutes depending on the charger.

3. When the battery is fully charged, the green indicator light is displayed.

Disconnect the charger from the AC wall outlet and the headset.

HS-4W_EN_1st_tab.fm Page 9 Monday, August 15, 2005 11 47 AM

Getting started

When the battery charge falls low

Fully charged batteries last up to 6 hours of talk-time and up to 160 hours of

standby time. However, talk and standby times may vary when used with different

handsets, other Bluetooth enabled-products, battery condition, usage settings,

usage style and environments. (In standby mode the headset is switched on but no

call is in progress.)

When the battery is running out of power, the headset beeps. Charge the battery as

described above.

■Pairing the headset with a compatible phone

1. Make sure that the compatible phone is switched on.

2. Switch on the headset. Make sure that the headset is charged.

3. Activate the Bluetooth connection from the phone. For more information, see

the user guide of the phone.

4. Set the phone to search for Bluetooth devices as instructed in the user guide of

the phone.

5. Select the Nokia HS-4W from the list.

6. Enter the generic passcode 0000 to associate ("pair") and connect the headset

to the phone.

HS-4W_EN_1st_tab.fm Page 10 Monday, August 15, 2005 11 47 AM
