Nokia BH-803 - Headset - Over-the-ear Manual de usuario
Nokia Bluetooth Headset BH-803
User Guide
Issue 1
2
© 2007 Nokia. All rights reserved.
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this HS-89W product is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/
EC. A copy of the Declaration of Conformity can be found at
http://www.nokia.com/phones/declaration_of_conformity/.
© 2007 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in
any form without the prior written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other
product and company names mentioned herein may be trademarks or tradenames of their
respective owners.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and
improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with the Nokia dealer
nearest to you.
Unauthorized changes or modifications to this device may void the user's authority to operate
the equipment.
© 2007 Nokia. All rights reserved.
3
Export Controls
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
Issue 1
Contents
4
© 2007 Nokia. All rights reserved.
Contents
1. Introduction ......................... 5
Bluetooth wireless technology.......... 5
2. Get started ........................... 7
Overview .................................................. 7
Chargers................................................... 7
Charge the battery................................ 8
Switch the headset on or off ............. 9
Pair the headset..................................... 9
Disconnect the headset.................. 10
Reconnect the headset................... 10
Troubleshooting ................................... 11
3. Basic use ............................. 12
Place the headset on the ear ........... 12
Call handling......................................... 13
Adjust the headset volume ............... 14
Mute or unmute the microphone ... 14
Switch the call between headset
and mobile device ............................... 15
Clear settings or reset ........................ 15
4. Battery information ........... 16
Care and maintenance........... 17
Introduction
© 2007 Nokia. All rights reserved.
5
1. Introduction
With the Nokia Bluetooth Headset BH-803 you can make and receive
calls while on the move and use your mobile device hands free. You can
use the headset with compatible devices that support Bluetooth wireless
technology.
Read this user guide carefully before using the headset. Also read the user
guide for your mobile device, which provides important safety and
maintenance information. Keep the headset and its accessories out of
reach of small children.
■Bluetooth wireless technology
Bluetooth wireless technology allows you
to connect compatible devices without
cables. A Bluetooth connection does not
require that the mobile device and the
headset be in line of sight, but the
maximum distance between the devices
is 10 meters (33 feet). The closer the
mobile device and the headset are to
each other, the better is the performance.
The optimal operating range is shown in
dark grey in the picture. The connection is
subject to interference from distance and obstructions (shown in light
grey) or other electronic devices.
<10m
Introduction
6
© 2007 Nokia. All rights reserved.
The headset is compliant with the Bluetooth Specification 2.0 + EDR
supporting the following profiles: Headset Profile 1.1 and Hands-Free
Profile 1.5. Check with the manufacturers of other devices to determine
their compatibility with this device.
There may be restrictions on using Bluetooth technology in some
locations. Check with your local authorities or service provider.
Get started
© 2007 Nokia. All rights reserved.
7
2. Get started
■Overview
The headset contains the following parts:
• Earpiece (1)
• Indicator light (2)
• Charger connector (3)
• Multifunction key (4)
• Touch sensitive area for
volume adjustment (5)
• Earloop (6)
• Microphone (7)
Before you can start using the headset, you must charge the battery and
pair the headset with a compatible device.
Parts of the headset are magnetic. Metallic materials may be attracted to
the headset. Do not place credit cards or other magnetic storage media
near the headset, because information stored on them may be erased.
■Chargers
Check the model number of any charger before using it with this headset.
The headset is intended for use with the AC-6 and DC-6 chargers.
1
2
3
4
5
7
6
Get started
8
© 2007 Nokia. All rights reserved.
Warning: Use only chargers approved by Nokia for use with this
particular enhancement. The use of any other types may invalidate any
approval or warranty, and may be dangerous.
When you disconnect the power cord of any enhancement, grasp and pull
the plug, not the cord.
■Charge the battery
The headset has an internal, nonremovable, rechargeable battery. Do not
attempt to remove the battery from the headset, as you may damage the
headset.
1. Connect the charger to a wall outlet.
2. Connect the charger cable to the
charger connector. The indicator light is
red while charging. It may take a while
before charging starts. If charging does
not start, disconnect the charger, plug it
in again, and retry. Charging the battery
fully may take up to 1 hour with the AC-6 or DC-6 charger.
3. When the battery is fully charged, the indicator light turns green.
Disconnect the charger from the headset and the wall outlet.
The battery can also be charged through the USB port of a compatible PC
using the Nokia Connectivity Cable CA-101 (sold separately). Connect one
end of the cable to the charger connector and the other end to the USB
port on the PC.
Get started
© 2007 Nokia. All rights reserved.
9
The fully charged battery has power for up to 6 hours of talk time or up to
160 hours of standby time. However, the talk and standby times may vary
when used with different compatible Bluetooth devices, usage settings,
usage styles, and environments.
When battery power is low, the headset beeps at regular intervals, and the
indicator light slowly flashes red.
■Switch the headset on or off
To switch on, press and hold the multifunction key until the headset beeps
and the indicator light turns on. When the headset can be connected to a
paired device, the indicator light slowly flashes green. When the headset
is connected to a paired device and is ready for use, the indicator light
slowly flashes blue. If the headset has not been paired with a device, it
automatically enters the pairing mode (see “Pair the headset,” p. 9).
To switch off, press and hold the multifunction key for at least 4 seconds
until the indicator light turns red. If the headset is not connected to a
paired device within about 30 minutes, it switches off automatically.
■Pair the headset
1. Ensure that your mobile device is switched on.
2. To pair the headset if it has not been previously paired with a device,
switch on the headset. The headset enters the pairing mode, and the
indicator light starts to flash blue quickly.
Get started
10
© 2007 Nokia. All rights reserved.
To pair the headset if it has been previously paired with another
device, ensure that the headset is switched off, and press and hold the
multifunction key until the indicator light starts to flash blue quickly.
3. Activate the Bluetooth feature on the mobile device, and set it to
search for Bluetooth devices. See the user guide of your device for
instructions.
4. Select the headset (Nokia BH-803) from the list of found devices.
5. Enter the passcode 0000 to pair and connect the headset to your
device. In some mobile devices, you may need to make the connection
separately after pairing. See the user guide of your device for details.
You only need to pair the headset with your device once.
If pairing is successful, the headset appears in the menu of the mobile
device where you can view the currently paired Bluetooth devices.
Disconnect the headset
To disconnect the headset from your mobile device, switch off the
headset, or disconnect it in the Bluetooth menu of your device.
You do not need to delete pairing with the headset to disconnect it.
Reconnect the headset
To connect the headset to your paired mobile device, switch on the
headset, and make the connection in the Bluetooth menu of your device,
or press and hold the multifunction key until you hear a short beep.
