Nokia Bluetooth Headset BH-500

User Guide

9249380

Issue 1 EN

HS-39W_en1.fm Page 1 Wednesday, June 14, 2006 1:16 PM

DECLARATION OF CONFORMITY

We, NOKIA CORPORATION declare under our sole responsibility that the product HS-39W is

in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of

the Declaration of Conformity can be found at http://www.nokia.com/phones/

declaration_of_conformity/.

The crossed-out wheeled bin means that within the European Union the product

must be taken to separate collection at the product end-of-life. Do not dispose of

these products as unsorted municipal waste.

Reproduction, transfer, distribution or storage of part or all of the contents in this document

in any form without the prior written permission of Nokia is prohibited.

Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other

product and company names mentioned herein may be trademarks or tradenames of their

respective owners.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Nokia operates a policy of continuous development. Nokia reserves the right to make

changes and improvements to any of the products described in this document without prior

notice.

Under no circumstances shall Nokia be responsible for any loss of data or income or any

special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by applicable law, no

warranties of any kind, either express or implied, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose, are made in relation to the

accuracy, reliability or contents of this document. Nokia reserves the right to revise this

document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with the Nokia dealer

nearest to you.

Unauthorized changes or modifications to this device may void the user's authority to

operate the equipment.

Export Controls

This device may contain commodities, technology or software subject to export laws and

regulations from the US and other countries. Diversion contrary to law is prohibited.

9249380 / Issue 1 EN

HS-39W_en1.fm Page 2 Wednesday, June 14, 2006 1:16 PM

Contents

1. Introduction ......................... 4

Bluetooth wireless technology .......... 4

Water-resistance ................................... 4

2. Get started............................ 6

Chargers ................................................... 6

Charge the battery................................ 7

Switch the headset on or off ............. 7

Pair the headset..................................... 8

Pair with a phone that has

a compatible music player

feature................................................... 8

Pair with a phone and

a music player..................................... 8

Disconnect the headset.................... 9

Reconnect the headset..................... 9

3. Basic use ............................. 10

Headphones .......................................... 10

Adjust the volume............................... 10

Call handling......................................... 10

Listen to music..................................... 11

Use the headset with

several paired devices ........................ 12

Lock or unlock the keys ..................... 12

Clear the settings or

reset the headset................................. 12

4. Battery information ........... 13

Care and maintenance ........... 14

FCC/Industry Canada notice .. 15

HS-39W_en1.fm Page 3 Wednesday, June 14, 2006 1:16 PM

Introduction

1. Introduction

You can use the Nokia Bluetooth Headset BH-500 to listen to music

with your compatible music player and make and answer calls with your

compatible mobile phone. The music player can be the music player

feature of your phone or a separate music playing device.

Read this user guide carefully before using the headset. Also read the

user guide for your phone, which provides important safety and

maintenance information, and the user guide for your music playing

device. Keep the headset out of reach of small children.

■Bluetooth wireless technology

The headset can be connected to a compatible mobile phone or music

player that supports Bluetooth wireless technology. This technology

makes it possible to connect compatible devices without cables. In a

Bluetooth connection, the headset and the other device should be

within 10 meters (30 feet) of each other. Connections can be subject to

interference from obstructions, such as walls, or other electronic

devices.

This headset is compliant with Bluetooth Specification 1.2 supporting

the following profiles: Headset Profile 1.1, Handsfree Profile 1.5,

Advanced Audio Distribution Profile 1.1, and Audio Video Remote

Control Profile 1.0. Check with the manufacturers of other devices to

determine their compatibility with this device.

There may be restrictions on using Bluetooth technology in some

locations. Check with your local authorities or service provider.

■Water-resistance

• You can use this device, with the supplied headphones, in the rain,

but do not submerge it in water. If you use alternative headphones,

then the device may not be water-resistant.

HS-39W_en1.fm Page 4 Wednesday, June 14, 2006 1:16 PM

Introduction

• If the device has been exposed to sweat or salt water, wash it

immediately with freshwater to avoid corrosion. The device must be

carefully wiped dry.

HS-39W_en1.fm Page 5 Wednesday, June 14, 2006 1:16 PM

Get started

2. Get started

The headset contains the following

parts:

• Power key (1)

• Microphone (2)

• Indicator light (3)

• Call key (4)

• Rewind key (5)

• Volume down key (6)

• Charger connector with a

protective cap (7)

• Play/pause key (8)

• Volume up key (9)

• Fast forward key (10)

• Headphone connector (11)

• Headphones with earplugs (12)

Before using the headset, you must charge the battery and pair the

headset with a compatible phone. If your phone does not have a music

player feature, you also need to pair the headset with your music player.

Note: Parts of the headset are magnetic. Metallic materials may be

attracted to the headset. Do not place credit cards or other magnetic

storage media near the headset, because information stored on them

may be erased.

■Chargers

Check the model number of any charger before use with this device.

The headset is intended for use with the AC-3, AC-4, and DC-4 chargers.

Warning: Use only chargers approved by Nokia for use with this

particular enhancement. The use of any other types may invalidate any

approval or warranty and may be dangerous.

1011

HS-39W_en1.fm Page 6 Wednesday, June 14, 2006 1:16 PM

Get started

For availability of approved enhancements, please check with your dealer. When

you disconnect the power cord of any enhancement, grasp and pull the plug, not

the cord.

■Charge the battery

This headset has an internal, nonremovable, rechargeable battery. Do

not attempt to remove the battery from the device as you may damage

the headset.

1. Connect the charger to a wall outlet.

2. Open the protective cap of the

charger connector, and connect the

charger cable to the headset.

The indicator light is yellow during

charging. If the indicator light is not

yellow, check the charger connection.

If charging does not start, disconnect

the charger, plug it in again, and

retry.

Charging the battery fully may take up to 2 hours. When the battery

is fully charged, the indicator light turns green.

3. Disconnect the charger from the headset and the wall outlet.

The fully charged battery has power for up to 8 hours of talktime, up to

200 hours of standby time, and up to 8 hours of music playing time.

However, the times may vary when used with different mobile phones or

other compatible Bluetooth devices, usage settings, usage styles, and

environments.

When the battery is running out of power, the headset beeps every 20

seconds, and the indicator light flashes red. Recharge the battery.

■Switch the headset on or off

To switch on, press and hold the power key. The headset beeps, and the

indicator light briefly flashes green. When the headset is connected to a

paired phone and is ready for use, the indicator light flashes blue slowly.

HS-39W_en1.fm Page 7 Wednesday, June 14, 2006 1:16 PM

Get started

To switch off, press and hold the power key. The headset beeps, and the

indicator light briefly flashes red.

■Pair the headset

Pair with a phone that has a compatible music player

feature

If your phone has a compatible music player feature, you can use the

headset to make and answer calls and to listen to music from the phone.

1. Switch on your phone.

2. Ensure that the headset is off. If it is on, switch it off.

3. Press and hold the power key of the headset until the indicator light

flashes blue rapidly.

4. Activate the Bluetooth feature on the phone, and set the phone to

search for Bluetooth devices. See the user guide of your phone for

instructions.

5. Select the headset (Nokia BH-500) from the list of found devices.

6. Your phone should ask for a Bluetooth passcode. Enter the passcode

(0000) on your phone. In some phones you may need to make the

Bluetooth connection separately after pairing. You only need to pair

the headset with your phone once.

If the pairing is successful and the headset is connected with your

phone, the indicator light of the headset flashes blue.

Pair with a phone and a music player

If your phone does not have a compatible music player feature, you can

separately pair the headset with your phone and a compatible music

player. After pairing and connecting the headset with your phone, do as

follows:

1. Switch off the headset.

2. Switch on the music player.

HS-39W_en1.fm Page 8 Wednesday, June 14, 2006 1:16 PM

Get started

3. Press and hold the power key of the headset until the indicator light

flashes blue rapidly.

4. Follow the pairing instructions in the user guide for your music

player. When the music player asks for a device to pair, select Nokia

BH-500 from the list. If you are asked for a Bluetooth passcode, enter

0000 on the music player.

If your music player does not have a keypad, the device may use the

Bluetooth passcode 0000 by default. If this is not the case, see the

user guide of your music player to change the default Bluetooth

passcode to 0000.

If the pairing is successful and the headset is connected with your music

player, the indicator light of the headset flashes blue.

Disconnect the headset

To disconnect the headset from your phone or music player, switch off

the headset, or follow the instructions in the user guide for your phone

or music player. You do not need to delete the pairing with the headset

to disconnect it.

Reconnect the headset

To connect the headset to your phone, switch on the headset, or make

the connection in the Bluetooth menu of your phone. To connect the

headset to your music player, press and hold the play/pause key.

If you have a Nokia phone, you can set it to connect with the headset

automatically when the headset is switched on. On your Nokia phone,

change your paired device settings in the Bluetooth menu.

HS-39W_en1.fm Page 9 Wednesday, June 14, 2006 1:16 PM

Basic use

3. Basic use

■Headphones

The headset comes with a pair of

headphones and three pairs of

earpads. Select the earpads that fit

best for your ears, and push them

onto the earplugs, with the wider

end first.

Plug the headphones into the

headphone connector. Ensure that

the headphone plug is fully inserted into the connector. Slide the

earloops behind your ears, and insert the earplugs into your ears. Attach

the headset to your clothing with the clip behind the headset, as close

to your mouth as possible for optimal audio quality.

Warning: When using the headset your ability to hear outside sounds

may be affected. Do not use the headset where it can endanger your

safety.

■Adjust the volume

Press the volume up key to increase or the volume down key to decrease

the volume during a call or while listening to music.

■Call handling

To make a call when the headset is connected to the phone, use your

phone in the normal way.

If your phone supports last number redialing with this device, press the

call key twice briefly while no call is in progress.

If your phone supports voice dialing with this device, press and hold the

call key when no call is in progress, and proceed as instructed in the user

guide of your phone.

HS-39W_en1.fm Page 10 Wednesday, June 14, 2006 1:16 PM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Auriculares de Nokia

Nokia

Nokia BH-203 Manual de usuario

Nokia

Nokia BH-609 Manual de usuario

Nokia

Nokia BH-700 Manual de usuario

Nokia

Nokia BH-207 Manual de usuario

Nokia

Nokia BH-108 Manual de usuario

Nokia

Nokia BH-106 Black Manual de usuario

Nokia

Nokia BH-606 Manual de usuario

Nokia

Nokia BH 212 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia Comm Band Pro Manual de usuario

Nokia

Nokia BH-803 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia WH 600 - Headset - Binaural Manual de usuario

Nokia

Nokia WH 600 - Headset - Binaural Manual de usuario

Nokia

Nokia BH-606 Manual de usuario

Nokia

Nokia BH 213 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia BH-118 Manual de usuario

Nokia

Nokia BH-703 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia BH 103 - Headset - In-ear ear-bud Manual de usuario

Nokia

Nokia HS-37W Manual de usuario

Nokia

Nokia BH-806 Manual de usuario

Nokia

Nokia Comm Band + CB-201 Manual de usuario

Nokia

Nokia Hs-45 - And Ad-57 Xpressmusic Stereo Headset 5310 3.5mm... Manual de usuario

Nokia

Nokia BH-500 Manual de usuario

Nokia

Nokia BH 604 - Headset - Binaural Manual de usuario

Nokia

Nokia BH-501 Manual de usuario

Manuales populares de Auriculares de otras marcas

Sena

Sena SMH10 Manual de usuario

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manual de usuario

Sennheiser

Sennheiser EPOS ADAPT 230 Manual de usuario

Doro

Doro Flexus HS2005 Manual de usuario

GE 98971 Manual de usuario

Hama

Hama 00184070 Manual de usuario

Plantronics

Plantronics Blackwire 3200 Series Manual de usuario

Blue Tiger

Blue Tiger Advantage PLUS Manual de usuario

Jawbone

Jawbone Icon Manual de usuario

Jabra

Jabra FR 20 Manual de usuario

Roxcore

Roxcore Flow A+ Manual de usuario

Turtle Beach

Turtle Beach XP 510 Manual de usuario

Philips

Philips SHB6101 Manual de usuario

Jabra

Jabra PRO 9460 Duo Manual de usuario

HyperX

HyperX HyperX Cloud Flight Manual de usuario

Bose

Bose MIE2 Mobile Manual de usuario

Jabra

Jabra Steel Manual de usuario

HyperX

HyperX cloud ii Manual de usuario
