Nokia WH-500 Manual de usuario
Nokia Stereo Headset WH-500
1
8
2
34
56
7
English
2 © 2009 Nokia. All rights reserved.
© 2009 Nokia. All rights reserved.
Nokia, Nokia Connecting People and the Nokia Original Accessories logo
are trademarks or registered trademarks of Nokia Corporation.
Introduction
With the Nokia Stereo Headset WH-500, you can make and answer calls
and listen to music from a compatible device.
This product may contain small parts. Keep them out of the reach of small
children. The headband hinges of this device may contain a small amount
of nickel. Persons who are sensitised to nickel may have symptoms from
prolonged contact with the hinges.
© 2009 Nokia. All rights reserved. 3
English
Parts of the device are magnetic. Metallic materials may be attracted to
the device. Do not place credit cards or other magnetic storage media
near the device, because information stored on them may be erased.
Warning: When you use the headset, your ability to hear
outside sounds may be affected. Do not use the headset
where it can endanger your safety.
Get started
Gently unfold the headset, turn the speaker pads (part 1 shown on the
title page) so that they point towards each other, and connect the headset
to a compatible device.
To connect the headset to a compatible Nokia device that has the Nokia
3.5 mm AV connector, insert the headset plug (8) into the AV connector.
For details, see the user guide of your device.
English
4 © 2009 Nokia. All rights reserved.
To connect the headset to a compatible Nokia device that has the Nokia
2.5 mm AV connector, connect the supplied AD-52 adapter to the headset
plug and then the adapter to the device.
To connect the headset to a compatible device (such as a music player)
that has the standard 3.5 mm audio connector, connect the supplied
AD-63 adapter to the headset plug and then the adapter to the device.
When you use this adapter, you can only use the headset to listen to
music.
Place the headset over your head so that the speaker pads rest
comfortably on your ears. Place the pad indicated with L on the left ear
and the pad with R on the right ear. Wear the headset so that the
microphone (5) is near to your mouth. The headset is now ready for use.
Adjust the volume
To adjust the volume, press the volume key (4) up or down.
© 2009 Nokia. All rights reserved. 5
English
Calls
To make a call, use your mobile device in the normal way when the
headset is connected to your mobile device. During the call, speak into the
microphone of the headset.
If your mobile device supports voice dialling, press and hold the answer/
end key (2), and proceed as described in the user guide of your mobile
device.
To answer or end a call, press the answer/end key. To reject a call, press
the answer/end key twice.
Listen to music
You can use the headset to listen to music on your compatible device.
Warning: Listen to music at a moderate level. Continuous
exposure to high volume may damage your hearing.
English
6 © 2009 Nokia. All rights reserved.
To play a song, select the song in the music player, and press the play/
pause key (7). For details, see the user guide of your device.
To select the next song, press the fast forward key (6). To select the
previous song, press the rewind key (3). To scroll through the songs
quickly during playback, press and hold either key. To pause or restart the
music player, press the play/pause key.
Listen to radio
To listen to the radio, start the FM radio feature on your compatible
device. For details, see the user guide of your device. To search for a
previously saved radio channel, press the fast forward or rewind key
repeatedly.
© 2009 Nokia. All rights reserved. 7
English
Care and maintenance
Your device is a product of superior design and craftsmanship and should
be treated with care. The following suggestions will help you protect your
warranty coverage.
• Keep the device dry. Precipitation, humidity, and all types of liquids
or moisture can contain minerals that will corrode electronic
circuits. If your device does get wet, allow it to dry completely.
• Do not use or store the device in dusty, dirty areas. Its moving parts
and electronic components can be damaged.
• Do not store the device in hot areas. High temperatures can shorten
the life of electronic devices, damage batteries, and warp or melt
certain plastics.
• Do not store the device in cold areas. When the device returns to its
normal temperature, moisture can form inside the device and
damage electronic circuit boards.
English
8 © 2009 Nokia. All rights reserved.
• Do not attempt to open the device.
• Do not drop, knock, or shake the device. Rough handling can break
internal circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents
to clean the device.
• Do not paint the device. Paint can clog the moving parts and prevent
proper operation.
If the product is not working properly, take it to the nearest authorised
service facility for service.
