Nokia Bluetooth Headset BH-607

9218881/1.1

9218881_EN-US_1.fm Page 1 Wednesday, November 25, 2009 8:37 PM

9218881_EN-US_1.fm Page 2 Friday, September 11, 2009 6:01 PM

ENGLISH

DECLARATION OF CONFORMITY

Hereby, NOKIA CORPORATION declares that

this BH-607 product is in compliance with

the essential requirements and other

relevant provisions of Directive 1999/5/EC.

A copy of the Declaration of Conformity can

be found at http://www.nokia.com/phones/

declaration_of_conformity/.

Bluetooth is a registered trademark of

Bluetooth SIG, Inc.

Introduction

With the Nokia Bluetooth Headset

BH-607, you can make and answer

calls hands-free with your compatible

mobile device. The headset is provided

with wind noise reduction and noise

cancellation that helps you handle

calls in noisy environments.

Read this user guide carefully before

using the headset. Also, read the user

guide for the device that you connect

to the headset.

Note: The surface of this

device does not contain

nickel in the platings.

The surface of this device contains

stainless steel.

My own key

The headset has a shortcut key that

you can set to perform different

functions on a compatible Nokia

device using the Nokia Accessory

Setup Application.

With the application, you can also

view headset information and define

headset settings when the headset is

connected to your device. For details,

9218881_EN-US_1.fm Page 3 Friday, September 11, 2009 6:01 PM

ENGLISH

read the built-in help of the

application.

If the application is not already

installed in your mobile device, check

the availability of the application for

your device from the support pages

of this headset at www.nokia.com/

support or your local Nokia website.

If the application is not available for

your Nokia device, you can use the

shortcut key to mute the microphone

during a call.

Bluetooth compatibility

The headset is compliant with the

Bluetooth Specification 2.1 + EDR

supporting the Headset Profile 1.1 and

Hands-Free Profile 1.5. Check with the

manufacturers of other devices to

determine their compatibility with

this device.

Get started

The headset contains the following

parts shown on the title page:

power key (1), volume key (2), My own

key (3), answer/end key (4),

microphones (5), indicator light (6),

charger connector (7), earloop (8),

and earpiece (9).

Before using the headset, you must

charge the battery and pair the

headset with a compatible device.

Compatible chargers

This device is intended for use when

supplied with power from the

following chargers: AC-3, AC-4, AC-5,

and DC-4. The exact charger model

number may vary depending on the

type of plug. The plug variant is

identified by one of the following:

E, EB, X, AR, U, A, C, or UB.

9218881_EN-US_1.fm Page 4 Friday, September 11, 2009 6:01 PM

ENGLISH

Charge the battery

1. Connect the charger to a wall

outlet.

2. Connect the charger cable to the

charger connector. The red

indicator light is displayed during

charging.

Charging the battery fully may take

up to 1 hour. Charging the battery

with the AC-5 charger for

15 minutes provides up to 5 hours

of talk time.

3. When the battery is fully charged,

the green indicator light is

displayed. Disconnect the charger

from the headset, then from the

wall outlet.

The fully charged battery has power

for up to 7 hours of talk time or up to

160 hours of standby time.

To check the battery charge when the

headset is not connected to a charger,

press the power key when the headset

is connected to a mobile device. If the

indicator light is green, the charge

level is sufficient. If the light is yellow,

you may need to recharge the battery

soon. If the light is red, recharge

the battery.

When the battery charge is low, the

headset beeps every 5 minutes and

the red indicator light flashes.

Switch on or off

To switch on, press and hold the power

key for about 2 seconds. The headset

beeps, and the green indicator light

flashes slowly while the headset tries

to connect to one or two last

connected devices. When the headset

is connected to at least one device and

is ready for use, the blue indicator

light flashes slowly. If the headset has

not been paired with a device, it

automatically enters pairing mode.

9218881_EN-US_1.fm Page 5 Friday, September 11, 2009 6:01 PM

ENGLISH

To switch off, press and hold the

power key for about 2 seconds. The

headset beeps, and the red indicator

light is briefly displayed. If the headset

is not connected to a device within

about 30 minutes, it switches off

automatically.

Pair and connect the headset

Before using the headset, you must

pair and connect it to a compatible

device.

You can pair the headset with up to

eight devices, but you can connect it

to only up to two devices at a time.

1. Ensure that your mobile device is

switched on and the headset is off.

2. If the headset has not been

previously paired with a device,

switch on the headset. The headset

enters pairing mode, and the blue

indicator light starts to flash

quickly.

If the headset has been previously

paired with a device, ensure that

the headset is switched off, and

press and hold the power key for

about 5 seconds until the blue

indicator light starts to flash

quickly.

3. Within about 3 minutes, activate

the Bluetooth feature on your

device, and set it to search for

Bluetooth devices. For details, see

the user guide of your mobile

device.

4. Select the headset from the list of

found devices.

5. If necessary, enter the passcode

0000 to pair and connect the

headset to your device.

In some devices, you may need to

make the connection separately

after pairing.

9218881_EN-US_1.fm Page 6 Friday, September 11, 2009 6:01 PM

ENGLISH

When the headset is connected to at

least one device and is ready for use,

the blue indicator light flashes slowly.

To manually connect the headset to

one or two last used devices, press and

hold the answer/end key for about

2 seconds (when no devices are

connected), or make the connection in

the Bluetooth menu of the desired

device. If you have a device connected

to the headset and want to connect

a second device, make the connection

in the Bluetooth menu of the device.

You may be able to set your device so

that the headset connects to it

automatically. To activate this feature

in a Nokia device, change the paired

device settings in the Bluetooth menu.

Basic use

Change the earpad

The headset may be provided with

different sized earpads. Select the

earpad that fits the best and is the

most comfortable for your ear.

To change the earpad, pull the current

earpad from the earpiece, and push

the new earpad into place (13).

Place the headset on the ear

Gently push the earpiece against

your ear.

You can rotate the earpad to keep the

headset securely in the ear (14). For

example, if you use the headset on the

right ear, you may need to rotate the

earpad to the right for the best fit. If

you wear an earring, ensure that it is

not accidentally attached to the

earpad.

9218881_EN-US_1.fm Page 7 Friday, September 11, 2009 6:01 PM

ENGLISH

To use the headset with the earloop,

attach the earloop to it (12). To detach

the earloop, gently pull it from the

headset. Slide the earloop behind your

ear (10), and point the headset toward

your mouth (11). Push or pull the

earloop to set its length.

Adjust volume

The headset automatically adjusts the

volume according to ambient noise. To

manually adjust the volume, slide the

volume key up or down. To adjust the

volume quickly, slide and hold the key.

The selected volume level is saved for

the device that you currently use with

the headset.

Calls

To make a call, use your mobile device

in the normal way when the headset is

connected to it.

To redial the number you last called

(if your mobile device supports this

feature with the headset), when no

call is in progress, press the answer/

end key twice.

To activate voice dialing (if your

mobile device supports this feature

with the headset), when no call is in

progress, press and hold the answer/

end key for about 2 seconds. Proceed

as described in the user guide of the

mobile device.

To answer or end a call, press the

answer/end key. To reject a call, press

this key twice.

To mute or unmute the microphone

during a call, press the volume key. The

headset beeps, and a related icon is

displayed on your device (if supported

by the device).

To switch a call between the headset

and a compatible connected device,

press and hold the answer/end key for

about 2 seconds.

9218881_EN-US_1.fm Page 8 Friday, September 11, 2009 6:01 PM

ENGLISH

Manage two calls

To manage two calls at the same time,

your mobile device must support the

Bluetooth Hands-Free Profile 1.5, and

call waiting must be activated in the

device. Call waiting is a network

service and is available when the

headset is connected to only one

device.

To answer a waiting call and end the

active call, press the answer/end key.

To answer a waiting call and put the

active call on hold, press and hold the

answer/end key for about 2 seconds.

To end the active call and make the

call on hold active, press the answer/

end key.

To switch between the active call and

the call on hold, press and hold the

answer/end key for about 2 seconds.

Turn lights on or off

By default, the indicator lights are

shown in all situations. To turn the

lights off in some situations (for

example, during a call or when the

headset is connected to a cell phone)

or back on, press and hold the answer/

end key and the volume key for about

5 seconds when the headset is

connected to a device. The yellow

indicator light flashes once.

To turn the lights back on, press and

hold the answer/end key, and slide and

hold the volume key up for about

5 seconds. The yellow indicator light

flashes once.

Allow connection to two

devices

You can have the headset connected

to two devices at the same time.

By default, the headset can only be

connected to one device at a time.

9218881_EN-US_1.fm Page 9 Friday, September 11, 2009 6:01 PM

ENGLISH

To allow the headset to connect to

two devices, switch off the headset,

and press and hold the power key, and

slide and hold the volume key up for

about 5 seconds. The green indicator

light flashes once.

To allow the headset to connect to

two devices, switch off the headset,

and press and hold the power key, and

slide and hold the volume key up for

about 5 seconds. The yellow indicator

light flashes once.

If the headset can connect to two

devices at the same time and you use

redialing or voice dialing, the call is

made on the device that you last used

to make a call when the headset was

connected to it.

Clear settings or reset

To clear all the settings from the

headset (including settings you have

defined with the Nokia Accessory

Setup Application), switch off the

headset, and press and hold the power

key and the answer/end key at the

same time for about 8 seconds. The

headset beeps twice, and the red and

green indicator lights alternate. After

the settings are cleared, the headset

enters pairing mode.

To reset the headset if it stops

functioning, even though it is charged,

connect the headset to a charger

while you press and hold the

power key.

Troubleshooting

If you cannot connect the headset to

your compatible device, check that

the headset is charged, switched on,

and paired with the device.

9218881_EN-US_1.fm Page 10 Friday, September 11, 2009 6:01 PM

Otros manuales para BH-607

Tabla de contenidos

Idiomas:

Otros manuales de Auriculares de Nokia

Nokia

Nokia hs-13w - Wireless Image Headset Manual de usuario

Nokia

Nokia DAB Manual de usuario

Nokia

Nokia BH 300 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia BH-200 Manual de usuario

Nokia

Nokia BH-222 Manual de usuario

Nokia

Nokia HS 11W Manual de usuario

Nokia

Nokia BH 103 - Headset - In-ear ear-bud Manual de usuario

Nokia

Nokia HS 26W - Headset - Over-the-ear Manual de usuario

Nokia

Nokia BH-500 Manual de usuario

Nokia

Nokia BH-209 Manual de usuario

Nokia

Nokia BH-111 Manual de usuario

Nokia

Nokia BH 301 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia BH-302 Manual de usuario

Nokia

Nokia HS-12W Manual de usuario

Nokia

Nokia BH-200 Manual de usuario

Nokia

Nokia BH-500 Manual de usuario

Nokia

Nokia 9232254 Manual de usuario

Nokia

Nokia BH 604 - Headset - Binaural Manual de usuario

Nokia

Nokia BH-607 Manual de usuario

Nokia

Nokia BH 600 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia BH-703 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia BH-902 Manual de usuario

Nokia

Nokia BH 104 - Headset - Over-the-ear Manual de usuario

Nokia

Nokia HS 11W Manual de usuario

Manuales populares de Auriculares de otras marcas

Sena

Sena SMH10 Manual de usuario

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manual de usuario

Sennheiser

Sennheiser EPOS ADAPT 230 Manual de usuario

Doro

Doro Flexus HS2005 Manual de usuario

GE 98971 Manual de usuario

Hama

Hama 00184070 Manual de usuario

Plantronics

Plantronics Blackwire 3200 Series Manual de usuario

Blue Tiger

Blue Tiger Advantage PLUS Manual de usuario

Jawbone

Jawbone Icon Manual de usuario

Jabra

Jabra FR 20 Manual de usuario

Roxcore

Roxcore Flow A+ Manual de usuario

Turtle Beach

Turtle Beach XP 510 Manual de usuario

Philips

Philips SHB6101 Manual de usuario

Jabra

Jabra PRO 9460 Duo Manual de usuario

HyperX

HyperX HyperX Cloud Flight Manual de usuario

Bose

Bose MIE2 Mobile Manual de usuario

Jabra

Jabra Steel Manual de usuario

HyperX

HyperX cloud ii Manual de usuario
