NGS WILD DUB ZERO Manual de usuario

www.ngs.eu

ENGLISH I FRANÇAIS I ESPAÑOL I DEUTSCH I ITALIANO I PORTUGUÊS

POLSKI I NEDERLANDS I ČEŠTINA I SLOVENČINA I ΕΛΛΗΝΙΚΑ I MAGYAR

NORSK I SUOMI I SVENSKA I DANSK I LIETUVIŲ

USER’S MANUAL

CONTROL BUTTONS

TOP PANEL DESCRIPTION

USB input

Microphone input / Guitar input

SD card input

Microphone volume

Control the microphone volume in all modes, from CV00

to CV16. In TWS mode, this function is not available.

Volume +/–

Control volume in all modes, from VL00 to VL32

Treble +/–

Adjust the treble, from –9 to 9

Bass +/–

Adjust the bass, from –9 to 9

Pevious

In USB / SD / Bluetooth modes, tap to skip back to the

previous song

Equaliser / Mega Bass

Tap the equaliser to browse through diﬀerent styles of

music: NOR, rock, jazz, classical, pop, country

Press and hold: Select on / oﬀ for mega bass function

715

11910 12813

16 17 18

ENGLISH

AC IN

For connecting the AC cable to get power supply

AUX OUT

To connect more speakers togheter

AUX-IN

For connecting the external device under AUX-IN mode

BACK PANEL DESCRIPTION10

Play / Pause

Under USB / SD modes, this button is play/pause

In BT mode, tap to play / pause

In TWS mode, press and hold to connect and disconnect

the TWS (5 seconds)

Under AUX-IN mode, this button has no function

Mode

Press shortly to skip to Wireless BT / AUX-IN / USB / SD

modes

In BT mode, press and hold to disconnect Bluetooth (3

seconds)

Under USB / SD / BT modes, tap to skip forward to the

next song

On / Oﬀ

Press to switch on / Press and hold for 2 seconds to

switch oﬀ

Echo

Press and adjust the value with the multifunction from

EC00 to EC30

Guitar volume

Control the guitar volume under guitar-input mode

Note:

To fully disconnect the electrical cable, please disconnect

the plug from the electrical power point it is connected to.

The base of the power point should be easy to access.

USER’S MANUAL

USING THE REMOTE CONTROL

Installing the batteries

Remove the battery cover from

the back of the remote control

as shown and insert 2xAAA

size batteries ensuring correct

polarity.

Note: Please point at the LED screen when you are using the

remote controller

Mute

Press this button, sound oﬀ. Press again, sound on

Under USB / SD / Bluetooth mode, press shortly for

previous sound source

112

ENGLISH

MODE

Press shortly to skip to Wireless BT / AUX-IN / USB (with

USB card plug in) / SD (with SD card plug in) mode

In BT mode, press and hold to disconnect Bluetooth (3

seconds)

REC

Under any mode, press “REC” button to record sound

with connected microphone and record in USB stick /

SD card

LIGHT

The color changes from red, green, blue, purple four color

automatically

BASS +/–

Adjust the bass

M. VOL +/–

Control the microphone volume

Play / Pause

Under USB / SD / BT modes, this button is play/pause

Under AUX-IN mode, this button has no function

Oﬀ

Press to switch the device oﬀ. The device only switches

on from the button on the top panel as an energy saving

measure

Under USB / SD / BT modes, press shortly for next song

VOICE

Remove the original voice

This feature is disabled in AUX mode

REPEAT

Repeat one, repeat all, RAMDOM (only available under

USB / SD modes)

REC PLAY

Play the recorded ﬁles into USB / SD

Press and hold to delete recorded ﬁles

M-PRI

Gives priority to mic voice against music

TREBLE +/–

Adjust the treble

Equalizer to browse through diﬀerent music styles: NOR,

rock, jazz, classical, pop, country

VOL +/–

Control the volume

0-9 keys

Under USB / SD modes to select songs

For other modes, number buttons have no function

USER’S MANUAL

To switch from one mode to another press the MODE button.

If the device is not connected to a USB stick or an SD card,

these modes will be omitted.

1. AUX IN

With the attached audio cable, you can connect the device

with the external multimedia audio sources through the

port “AUX”. After connection, just set the mode to AUX by

pressing the MODE button on the device. At this time, the

AUX indicator will be displayed on the screen, suggesting the

device can play the audio ﬁles from multimedia sources like

PC, mobile phone, MP3 and MP4, etc.

Note: In AUX IN mode, the forward and rewind song functions

will not operate. They must be accessed through the auxiliary

device directly.

2. USB/SD CARD PLAYING

Insert the SD card or a USB Flash memory stick into the

corresponding slot. The device will automatically play any

music in MP3 format on the card.

3. BLUETOOTH MODE

A. Press the MODE button until the word “BLUE” appears

on the screen. The icon will start to ﬂash. In Bluetooth

mode the device goes into searching / paring / reconnect

mode for pair.

B. Now, turn ON the Bluetooth function on your mobile phone.

C. Search for “NGS WILDDUB” and select it to pair (for

ﬁrst time pairing or pairing a new mobile device). Once

connected, the icon will stop ﬂashing.

D. The Bluetooth speaker will be reconnecting automatically

if your mobile phone has been paired (Depend on the

of mobile phone’s type and conﬁguration, manual

reconnection may require on some devices).

AUX IN, USBSD, BLUETOOTH

ENGLISH

BUILTIN RECORDING FUNCTION

1. Plug in a microphone to the MIC IN input

2. Insert USB/SD card into the corresponding port, press

MODE button and select USB/SD mode.

3. If the USB/SD card is plugged into the speaker for the ﬁrst

time, the system will automatically create a folder named

RECORD to save recorded ﬁles (FAT32 USB ﬁle system is

supported).

4. When you are ready to record, press REC button to go to

recording mode. The current sound output will stop and

the MICRO mode will be activated, the screen shows the

recording time. The device starts recording when the

screen shows 00:01 and users can use the microphone to

record.

4. TWS

A. Change the two speaker in the BT mode, then press the

PLAY/PAUSE button on one speaker for 5 seconds.

B. You will hear a beep on both speakers.

C. Search your mobile device for NGS WILDDUB and it will

hook up.

USER’S MANUAL

TECHNICAL SPECIFICATIONS

TWS

USB / SD / BT / AUX inputs

Microphone input

Guitar input

LED screen

LED lights

AUX output

Input voltage: AC 100V-240V 50/60Hz

Frequency range: 20Hz ~ 20kHz

WILDDUB1

WILDDUB ZERO

Output power

(Peak power): 300W 120W

Bluetooth operation frequency: 2402-2480 MHz 2402-2480 MHz

Max RF output power: 6.58 dBm 6.58 dBm

Woofersize: 2 x 8” 1 x 8”

Tweeter size: 2 x 3” 2 x 3”

RMS power: 80W 20W

Battery: 11.1V/5.2A 11.1V/2.2A

Battery life:

At 100% volume 3 hours 3 hours

At 70% volume 7 hours 4.5 hours

At 50% volume 12 hours 7 hours

1. Put the switch on the back to battery position.

2. Switch on the speaker by pressing the STANDBY button.

BATTERY MODE

1. Connect one end of the power cable to the speaker and the

other end to the electricity supply.

2. A red LED will appear on the screen while it is charging.

3. When the battery is fully charged the red LED will

disappear and a green LED will appear.

CHARGING THE BATTERY

ENGLISH

If at any time in the future you should need to dispose of

this product please note that:

Waste electrical products should not be disposed of with

household waste. Please recycle where facilities exist.

Check with your Local Authority or retailer for recycling

advice.

(Waste Electrical and Electronic Equipment Directive)

MANUEL DE L’UTILISATEUR

BOUTONS DE COMMANDE

TOP PANEL DESCRIPTION

Entrée USB

Entrée du microphone / entrée guitare

Entrée de carte SD

Volume du microphone

Contrôle le volume du microphone dans tous les modes,

de CV00 à CV16. En mode TWS, cette fonction n’est pas

disponible.

Volume +/–

Contrôle du volume dans tous les modes, du VL00 au

VL32

Aigus +/–

Ajuste les aigus, de –9 à 9

Basses +/–

Ajuste les basses, de –9 à 9

En mode USB / SD / Bluetooth, appuyez brièvement pour

aller à la chanson précédente

Equalizer / Méga basses

Appuyez brièvement sur : égaliseur pour naviguer dans

diﬀérents styles de musique : NOR, rock, jazz, classique,

pop, country

Appuyez et maintenez enfoncé : active / désactive la

fonction méga basses

715

11910 12813

16 17 18
