Netum W9 Manual de usuario
△ USB wired 1D & 2D Plug &Play Barcode Scanner
△ Supports Windows XP, Win7/8/10,MAC etc.
Packing list:
Quick Start Setup Guide x1 pc
Barcode scanner x 1 pc
Quick Setup Guide V5.30
CONTENTS
English
Deutsch
Français
Italiano
Español
1-7
8-14
15-21
22-28
29-35
--------------
--------------
--------------
--------------
--------------
English
(1)
Programming Code
Netum barcode scanners are factory programmed for the most common
terminal and communications settings. If you need to change these settings,
programming is accomplished by scanning the bar codes in this guide. An
asterisk (**) next to an option indicates the default setting.
Quick Setup Guide
Important Notes:
All configurations need to go through below steps except Factory Defaults.
Scan “Enter Setup” → “Programming Code” →”Exit Setup”
If scanner has exited the setup mode, none programming codes can be read.
Enter Setup ** Exit Setup
Factory Defaults
Factory Defaults
Configures the scanner to revert all settings to factory defaults.
Get Started: Connect scanner with your device via USB cable. If you use US
keyboard, it's plug and play. If you use other type of keyboard , please refer to
"keyboard language" to set the keyboard language before use it.
(2)
Keyboard Language
If you use French Keyboard, scan “Enter Setup” → “ French Keyboard” →
Exit Setup. After that locate the cursor on the place where you want to
output the data then you can start to scan.
American Keyboard was set by default, if you use US keyboard you can
just ignore this setup.
*US UK
France Germany
Italy Turkey Q
(3)
Enable All Symbologies
If all symbologies feature is enabled, scanner can decode all types of
non-programmed barcodes.
Enable All Symbologies
Portugal Spain
Japan Czech Republic
Brazil Russia
(4)
USB Interface (Optional)
USB HID-KBW
By default, the scanner is in HID mode as a Keyboard device. It works on a
Plug and Play basis and no driver is required.
** USB HID-KBW
USB COM Port Emulation
USB COM Port Emulation
If you connect the scanner to the Host via a USB connection, the USB COM
Port Emulation feature allows the host to receive data in the way as a serial
port does.
** Trigger Mode
Scan Mode
Trigger Mode
Scanning this bar code will enable the scanner to enter manual trigger mode.
(5)
Sense Mode
Auto Sense Mode
Scanning this bar code will enable the scanner to enter auto sense mode.
Continuous Mode
Continuous Mode
This mode enables the scanner to scan/capture, decode and transmit over
and over again.
Terminator
The scanner provides a shortcut for setting the terminating character suffix to
CR or TAB and enabling it by scanning the appropriate barcode below.
No terminator **CR/ENTER
(6)
TAB
Symbologies
QR Code
Scan below command code for QR Code to be outputed on Notepad or Excel.
Code Outputed on Notepad or Excel
Scan below command code for QR Code to be outputed on word or wechat.
Code Outputed on Word or Wechat
(7)
Support
If you have any inquiries please do not hesitate to contact us.
Contact Information
Tel.: +0086 20-3222-8813
Whatsapp: +86 136 222 33 974
Email: [email protected]
Addr.:Room 301, 6th Floor and full 3rd Floor, Building 1, No. 51
Xiangshan Avenue, Ningxi Street, Zengcheng District,
Guangzhou, Guangdong, China/ 511356
Website: https://www.netum.net/
EU Name：Apex CE Specialists GmbH
Add: Habichtweg 1 41468 Neuss Germany
UK Name：APEX CE SPECIALISTS LIMITED
Add: 89 Princess Street,Manchester,M1 4HT,UK
Made in China
FAQ
Question:Is there any barcodes for apply or remove suffix ?
Yes, you may go to our official website” https://www.netum.net/” to download
the complete manual and refer to the part of “ prefix and suffix” or turn to
customer service for help.
Question:How to solve the messy code problem encountered while using other
foreign languages?
Solution:The default keyboard language is English. If you use other types of
keyboard please refer to “Keyboard language”.
Problem: Some barcodes cannot be read.
Solution:
a. Dirty or unclear barcodes might not be read.
b. The possible reason is that setting for some barcode types are not commonly
used is off by default. You need to activate a specific barcode type to get it to
work. Please contact us for further support.
c. Clean scanner’s window.
