NetComm NB3 Manual de usuario

ADSL

Your essential high-speed ADSL connection for home or office

Now you can enjoy ADSL (Asymmetric Digital Subscriber Line) technology to access the Internet

at speeds up to 150 times faster than a 56K dial up – quickly and easily.

This is the essential ADSL modem and router that you need to activate and operate a broadband

ADSL Internet service. Containing everything you need to get up and running with one computer,

the NetComm NB3is an indispensable part of broadband success.

EASY INSTALL & SET-UP

You can install the NetComm NB3in minutes, using NetComm’s set up that has been specially

developed for Australian ISPs.

You can use your NB3to establish an ADSL connection on a single PC simply by using the USB

port. Or you can connect to your ADSL connection by using the NB3’s built in Ethernet port.

The NB3 employs the latest protocols and has been thoroughly tested for full compliance with

Australian conditions. And you can rest easy that you have bought another reliable product from

NetComm, Australia’s only data communications company. Since 1981, Australians have relied

on NetComm to meet their data communication needs.

MICRO

FILTER

INSIDE

Connect via

Ethernet or USB

Easy install for

Australian ISPs

NB3

Ethernet/USB ADSL Modem Router

My ADSL Modem

Fully functional ADSL Modem

10/100 Ethernet and USB port for easy connection to a single PC

NETCOMM LIMITED

ABN 85 002 490 486

2-6 Orion Road

LA E COVE

SW 2066

phone 02 9424 2070

fax 02 9424 2010

email [email protected]

For more information,

please visit

www.netcomm.com.au

Australia connects with

NB3

Your Netcomm dealer: NetComm is Australia’s dynamic data communications and

networking solutions provider. For more information on this and

other NetComm products, please visit www.netcomm.com.au

etComm Limited AB 85 002 490 486

PO Box 1200, Lane Cove SW 2066 Australia.

HONE (02) 9424 2070 • FAX (02) 9424 2010

www.netcomm.com.au • EMAIL [email protected]

Trademarks and registered trademarks are the property of etComm

Limited or their respective owners. Specifications are subject to change

without notice. Images shown may vary slightly from the product.

Compliant with ADSL standards Full-rate

A SI T1.413 Issue 2, ITU 992.2 (G-lite) and

ITU 992.1 (G.dmt)

Supports RFC1483 (Ethernet over ATM),

RFC2364 (PPP over ATM), RFC2516 (PPP

over Ethernet), and RFC1577 (Classical IP

over ATM) data encapsulation formats

DMT modulation and demodulation

Full-rate adaptive modem

MAX DOW STREAM rate 8Mbps

MAX UPSTREAM rate 800Kbps

USB interface

Compliant with USB 1.1 specification

Ethernet interface

Compliant with IEEE 802.3 standard

10BaseT/100BaseTX, 10/100 Mbps

Auto-selection of which host interface

is active

H web-based management access via S MP,

http and CLI (over Telnet and RS-232)

DSL-aware ATM shaper supports UBR, GFR,

CBR and VBR traffic

Embedded AT firewall and IP filtering

FEATURES

Windows®98/98SE/2000/ME/XP

Windows®T (Ethernet port only)

Mac OS 9.x/10.x (Ethernet port only)

B3 ADSL Ethernet/USB Modem

Cat-5RJ45 straight-through

Ethernet Cable

RJ11 Line Cord

USB Cable

EM1100 MicroFilter

605 to RJ11 Line Adaptor

Power Pack 12V DC

Driver/Manual/Utility Software CD

Installation Guide

Dimensions

139mm x 114mm x 27mm

LEDs

PW power

LK solid when ADSL in show-time;

flashing when ADSL establishing

show-time

Ethernet LI K/ACT LEDs: Green 100M

Yellow 10M

Interface

RJ-11 One standard RJ-11 connector for

ADSL line-in

RJ-45 One standard RJ-45 connector to

connect to PC (integrates

10/100M LI K/ACT LEDs)

USB One standard USB connector to

connect to PC

Reset Push to reset to factory defaults

Power One power connector 12V DC

Environmental

• Operating temperature 0~50° C

• Humidity 10~90% non-condensing

ower requirements

12V DC

1year warranty out of the box.

Extra 2years FREE with online

registration at www.netcomm.com.au

*Conditional upon registration online.

3 YEAR WARRANTY *

SPECIFICATIONS

Your essential high-speed ADSL connection for home or office

RJ45 for

10/100 Ethernet

LAN connection

Power jack

for

AC power

adaptor

RJ11 for ADSL

connection to

telephone line USB

data port

Reset/

factory

defaults

PAC AGE CONTENTS

OPERATING SYSTEM SUPPORT

N367

NB3

My ADSL Modem
