NetComm NB14WN Manual de usuario
1
Modem Conguration Guide
Netcomm Wireless N150 NB14WN
Conguring in Layer2 PPPoE for Windows XP and 2000
IMPORTANT MESSAGE
Your modem has been pre-configured, you do not need to
follow each step of the set-up guide but should retain this
document in case you need to manually configure your
equipment.
To configure your PC/Laptop with your wireless password
please proceed to step 4d. To change your wireless
password please proceed to step 4.
Contents
1. Physical Connection
2. Network Configuration
3. Configuring Internet Connection in Layer 2 PPPoE
4. Configuring Wireless
5. IPTV
6. Change of Password
1. PHYSICAL CONNECTION
Please refer to diagram CASE2 in the Quick Reference Guide.
PLEASE NOTE: Have your router powered on and connected directly to your PC via Ethernet Cable before you begin, as
these instructions are based on wired Ethernet connection
2. NETWORK CONFIGURATION
PPPoE connection does not require you to have an IP address or DNS settings manually encoded on your network card.
PPPoE connection uses authentication to establish the Internet connection and its after doing this that your router is assigned
an IP and DNS settings from TPG.
To begin, your PC needs to receive a private IP address from the router. Most ADSL routers have DHCP enabled by default
that will take care of this.
Netcomm N150 NB14WN
2
Modem Conguration Guide Netcomm N150 NB14WN
To ensure your Network Card is ready for this please follow the
following steps:
A. Click on Start -> Settings -> Control Panel -> Network
Connections
B. Right click on Local Area Connection and select Properties
C. Double click on Internet Protocol TCP/IP
D. Ensure “Obtain an IP address automatically” is selected
E. Ensure “Obtain DNS server address automatically” is selected
F. Click on OK
3
3. CONFIGURE LAYER 2 PPPOE
A. Open your browser and in the address bar type
http://192.168.1.1 and press enter
B. Enter admin for both the username and password and
click on OK. If you have changed the login credentials,
please enter the current username and password for your
router interface.
C. You should now see the site map screen.
D. You can use Quick Start to setup the router’s ADSL
connection with ease. Click Quick Start to get into the
quick setup procedures.
E. Click RUN WIZARD to start up this procedure.
Modem Conguration Guide Netcomm N150 NB14WN
4
Modem Conguration Guide
F. You may change the password by entering in a
new password. Click NEXT to continue.
G. Select the appropriate time zone for your
location. Click NEXT to continue.
H. In the ISP Connection Type screen,
choose PPPoE/PPPoA. Click NEXT to continue.
Netcomm N150 NB14WN
5
Modem Conguration Guide
I. Enter the following connection information into
relevant field, Click NEXT to continue.
Username: can be found in the ADSL
Configuration Details letter
Password: the password you nominated at the
time of registration
VPI: 8
VCI: 35
Connection Type: PPPoE LLC
J. Please click NEXT to confirm your changes.
K. Please click CLOSE to exit the Quick Start
Wizard.
Netcomm N150 NB14WN
6
4. CONFIGURING WIRELESS
Things you need to know before you begin:
By default the NB14WN that you purchased from TPG is
configured with the following wireless security settings:
SSID (name for the wireless connection):
Netcomm Wireless (router default)
Authentication Type: WPA-PSK/WPA2-PSK
Encryption: TKIP/AES
Pre Shared Key: initially configured to be the same as
your TPG password. You can enter your own text as an
option.
To use Wireless be sure that you already have set up your
wireless adapter.
To begin your wireless setup please connect your
computer to your router via Ethernet cable.
A. If you are still logged into your router, click on
“Wireless” in the top menu. If you are not logged in
anymore use your browser to go to 192.168.1.1 and
login with admin as the username and admin as your
password.
B. Go to Interface -> Wireless to setup the wireless
parameters.
Modem Conguration Guide Netcomm N150 NB14WN
7
C. Ensure that the following is selected:
SSID: Netcomm Wireless (router default)
Note: SSID is the name of your wireless network. You
can change the SSID. Only devices with the same
SSID can interconnect.
Authentication Type: WPA-PSK/WPA2-PSK
Encryption: TKIP/AES
Pre Shared Key: initially configured to be the same
as your TPG password.
Note: Pre Shared Key is the password of your
wireless network. You can enter your own password
as an option.
D. Click on Save
E. To connect using wireless, go to Start -> Control Panel
F. Double click on ‘Network Connections’
G. Right click on your wireless adapter and go to ‘View
Available Wireless Networks’
Modem Conguration Guide Netcomm N150 NB14WN
8
H. Find the SSID (network name) of your router and click
on Connect. By default, the network name should be
Netcomm Wireless.
However if you have changed the network name in
step 4c, please select your personal wireless network
name.
I. You will now be prompted to enter your WAP Key /
wireless password. This is the same as your TPG password if you did not change it on the router.
J. Click on Connect.
K. You should now see your status as ‘Connected’.
5. IPTV
Your Netcomm NB14NW modem is pre configured with the TPG IPTV settings. Should you require further assistance please
contact the TPG helpdesk on 13 14 23 (option 2)
6. CHANGE OF PASSWORD
For security purposes we highly recommend that you change your password if you are using your default or if you believe
your password security has been compromised.
To change your password, first please visit
https://cyberstore.tpg.com.au/your_account/?function=changepassword. Your new password will take approximately 10-15
minutes to take effect, after which you must reconfigure your new password in your router.
To update the password in your router, please follow Step 3 of this guide (Configure Layer 2 PPPoE).
Modem Conguration Guide Netcomm N150 NB14WN
13 14 23tpg.com.au/support
PLEASE NOTE:
ADSL routers will by default be capable of automatic authentication. This means your router will use your credentials you have
provided to make the Internet connection. Each time your router is powered on, it will initialize this automated authentication
process after which your router will receive a public IP address (fi xed or dynamic depending on your plan) and DNS settings
from TPG.
