NetComm N3GS003

3G Serial Modem

The perfect 3G Telemetry device

The NetComm N3GS003 is a 3G modem with serial port access designed for

telemetry applications such as the remote monitoring, access and troubleshooting

of industrial and commercial equipment over a 3G or NextG network. Designed by

NetComm’s engineers here in Australia, the N3GS003 is ideally suited to Australian

environmental conditions.

The N3GS003 can be used in Supervisory Control and Data Acquisition (SCADA)

scenarios to monitor, control or collect data from remote devices such as farm

machinery, water monitoring devices or industrial equipment.

It can also be used for any variety of unmanned devices that are required to report

data back to a central source.

In addition to data reporting, the N3GS003 is also a valuable tool for remote

troubleshooting. By using the N3GS003 with a remote device, you can dial

directly into the device to troubleshoot problems as they occur.

The N3GS003 uses an easily available 3G SIM card and works anywhere a 3G

signal is available.

NetComm N3GS003

3G Serial Modem

TECHNICAL SPECIFICATIONS

PACKAGE CONTENTS

•N3G003S 3G Dial Up modem

•12V DC 1Amp Power Pack

•Driver / Manual CD

•850MHz/2100MHz wireless Antenna

Features

• UMTS (HSDPA): 850 and 2100 MHz

• EDGE/GPRS/GSM: 850/900 MHz

• Supports third generation (3G) digital cellular standards

• RS 232 serial connection

• AT Command interface

LED Indicators

Function Color Definition

Power Off Power is Off

Green Power is on and the device operates normally.

Signal Slow Blink Unit is searching for a carrier.

Flashing Blink Unit is connected to the network and transmitting or receiving data.

Solid Red Unit is Connected to network but not transmitting or receiving data

NETCOMM LIMITED ABN 85 002 490 486 PO Box 1200, Lane Cove NSW 2066 Australia

P: 02 9424 2070 F: 02 9424 2010 E: [email protected] W: www.netcomm.com.au

Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Speciﬁcations are subject to change without notice. Images shown may vary slightly from the actual product.

• 850/2100MHz WCDMA, Power class 3 (+24dBm)

• 850/900 MHz GSM/GPRS/EDGE GSM Power Class

4/EDGE E2

• GSM Power Class 1

• Supports third generation (3G) digital cellular standards.

• Sierra Wireless MC8775V (MSM6280 QUALCOMM

chipset) module

• RS 232 serial connection for dial up connection

• Supported speed: 1200, 2400, 4800, 9600, 14400,

28800, 38400, 57600, 115200 (default), 230400

• AT Command interface (V250, 3GPP TS 27.007 (partial))

• SMS capabilities via AT command (3GPP TS 27.005

(partial))

OPERATION:

• Operating Temperature: -20 to +60° C

• Storage Temperature: -30 to +85° C

CONNECTOR:

• RS232 connector (DB9 Female)

• JST VH connector (requires VHR-2N mating plug)

• Antenna (SMA) connector type.

POWER REQUIREMENT:

8VDC to 56VDC at 10W (supplied with 12VDC 1A)
