GETTING STARTED GUIDE

PXIe-4480/4481

6-Channel, 24-bit, 1.25 MS/s DSA Analog Input

This document explains how to install, configure, and set up the PXIe-4480 and PXIe-4481

Dynamic Signal Acquisition (DSA) analog input modules. Driver support for these modules was

first available in NI-DAQmx 16.1. For a list of devices supported by a specific release, refer to

the NI-DAQmx Readme, available on the version-specific download page or installation media.

Contents

Electromagnetic Compatibility Guidelines .............................................................................. 1

Unpacking the Kit..................................................................................................................... 2

Preparing the Environment.......................................................................................................3

Verifying the Kit Contents ....................................................................................................... 3

Other Equipment............................................................................................................... 3

Installing the Software.............................................................................................................. 4

Installing the Hardware ............................................................................................................ 4

Configuring the Hardware in MAX.......................................................................................... 7

Connecting Signals ................................................................................................................... 8

Connecting RJ50 Cables................................................................................................... 9

Connecting BNC Cables................................................................................................... 9

Connecting mXLR Cables................................................................................................ 10

Environmental Management..................................................................................................... 10

Worldwide Support and Services ............................................................................................. 11

Electromagnetic Compatibility Guidelines

This product was tested and complies with the regulatory requirements and limits for

electromagnetic compatibility (EMC) stated in the product specifications. These requirements

and limits provide reasonable protection against harmful interference when the product is

operated in the intended operational electromagnetic environment.

This product is intended for use in locations with a controlled electromagnetic environment.

However, harmful interference may occur in some installations, when the product is connected

to a peripheral device or test object, or if the product is used in residential or commercial areas.

To minimize interference with radio and television reception and prevent unacceptable

performance degradation, install and use this product in strict accordance with the instructions

in the product documentation.

Furthermore, any modifications to the product not expressly approved by National Instruments

could void your authority to operate it under your local regulatory rules.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2|ni.com |PXIe-4480/4481 Getting Started Guide

Caution To ensure the specified EMC performance, operate this product only with

shielded cables and accessories.

Caution To ensure the specified EMC performance, the length of all mini-XLR

cables must be no longer than 3 m (10 ft).

Caution Electromagnetic interference can adversely affect the measurement

accuracy of this product when used with BNC cables. The construction of a BNC

coaxial cable is inherently unbalanced in that the outer conductor (LO) is used as a

shield for the inner conductor (HI). However, for functional reasons, there is no input

configuration of the PXIe-4480/4481 that directly connects the LO terminal to the

chassis ground. Without a direct connection to chassis ground, the outer conductor

does not act as a shield for unwanted noise and may act as an antenna for coupling

noise into the module inputs. For single-ended measurements, the noise immunity for

the system can be improved by directly connecting the outer conductor to the chassis

or earth ground at the load end of the cable. For differential measurements, where

such a connection is inherently not possible, the BNC cable can alternatively be

wrapped in a separate grounded shield. In addition, you might need to use snap-on

ferrite beads or other remedial measures to improve electromagnetic compatibility.

Unpacking the Kit

The PXIe-4480/4481 module ships in an antistatic package to prevent electrostatic discharge

from damaging module components.

Caution To prevent electrostatic discharge from damaging the device, ground

yourself using a grounding strap or by holding a grounded object, such as your

computer chassis.

1. Touch the antistatic package to a metal part of the grounded object before removing the

module from package.

2. Remove the module from the package and inspect the module for loose components or any

other sign of damage.

Caution Never touch the exposed pins of connectors.

Store the device in the antistatic package when the device is not in use. Notify NI if the module

appears damaged in any way; do not install a damaged device.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PXIe-4480/4481 Getting Started Guide |© National Instruments |3

Preparing the Environment

Ensure that the environment in which you are using the PXIe-4480/4481 meets the following

specifications.

Operating ambient temperature ........................ 0 °C to 55 °C

(IEC 60068-2-1, IEC 60068-2-2)

Operating relative humidity.............................. 10% to 90%, noncondensing

(IEC 60068-2-56)

Altitude ............................................................. 2,000 m (800 mbar)

(at 25 °C ambient temperature)

Pollution Degree ............................................... 2

Indoor use only.

Caution Clean the hardware with a soft, nonmetallic brush. Make sure that the

hardware is completely dry and free from contaminants before returning it to service.

Note Refer to the PXIe-4480/4481 Specifications at ni.com/manuals for

complete specifications.

Verifying the Kit Contents

The following items are necessary to set up and use the PXIe-4480/4481:

• PXIe-4480/4481 analog input module

• NI-DAQmx installation media

•PXIe-4480/4481 Getting Started Guide

Note You can download any needed documents from ni.com/manuals.

Other Equipment

Several additional items that are not included in the module kit are necessary to install or operate

the PXIe-4480/4481.

Required Items

• PXI Express chassis and chassis documentation. For more information about compatible

chassis options, refer to ni.com.

• PXI Express embedded controller or MXI-Express (card or built-in) that meets the system

requirements specified in this guide and controller documentation.

• One of the following shielded InfiniBand 12x cables:

– SHB12X-6BNC

– SHB12X-6MXLRM

– SHB12X-6RJ50

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4|ni.com |PXIe-4480/4481 Getting Started Guide

Note Cables may be shipped with a protective covering on the InfiniBand

connector. Any protective covering or obstruction should be removed before

attempting to secure connection to the PXIe-4480/4481.

Optional Items

•NILabVIEW

Note For the list of LabVIEW versions supported by a specific version of

NI-DAQmx, refer to the NI-DAQmx Readme, available on the version-specific

download page at ni.com/downloads or on the installation media.

Installing the Software

Software support for the PXIe-4480/4481 is provided by NI-DAQmx. For detailed NI software

version support, refer to the NI-DAQmx Readme.

You must be an Administrator to install NI software on your computer.

1. (Optional) If you are developing an NI-DAQmx application, install an ADE, such as

LabVIEW or LabWindows™/CVI™.

2. Install the latest service packs for your operating system.

3. Insert a compatible version of NI-DAQmx. To download the NI-DAQmx driver, visit

ni.com/info and enter the Info Code daqmx.

4. Follow the instructions in the installation prompts.

Note Windows users may see access and security messages during installation.

Accept the prompts to complete the installation. For troubleshooting information,

refer to the Worldwide Support and Services section.

5. When installation completes, select Restart in the dialog box that asks if you want to

restart, shut down, or restart later.

Installing the Hardware

You must install the software before using the hardware.

Caution To prevent damage to the device caused by ESD or contamination, handle

the device using the edges or the metal bracket.

Before you install the hardware, refer to the guidelines in the Maintain Forced-Air Cooling Note

to Users to maintain forced air cooling in the PXI Express system. This document is available at

ni.com/manuals.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PXIe-4480/4481 Getting Started Guide |© National Instruments |5

1. Ensure the AC power source is connected to the chassis before installing the module. The

AC power cord grounds the chassis and protects it from electrical damage while you install

the module.

2. Make sure the chassis is powered off.

Caution To protect yourself, the chassis, and the module from electrical hazards,

leave the chassis powered off until you finish installing the module.

3. Inspect the slot pins on the chassis backplane for any bends or damage prior to installation.

Do not install a module if the backplane is damaged.

4. Remove the protective plastic covers from all the captive screws on the module front panel.

5. Identify a supported slot in the chassis. The PXIe-4480/4481 module can be placed only in

the supported slot types identified in Table 1. Figure 1 shows the slot type symbols of the

various slot types. Refer to your chassis documentation for more details

Figure 1. PXI/PXIe Chassis Slot Type Symbol Location

6. Touch any metal part on the chassis to discharge any static electricity.

7. Ensure that the injector/ejector handle is in the unlatched (downward) position.

8. Place the module edges into the module guides at the top and bottom of the chassis. Slide

the module into the slot until it is fully inserted.

1 Slot Type Symbols Locations

Table 1. PXIe-4480/4481 Supported Slot Types

PXI Chassis Slot Type Symbol Supported Slot Type Description

PXI Express Peripheral

PXI/PXI Express Hybrid Peripheral

PXI Express System Timing or Peripheral

NI PXIe-1062Q

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6|ni.com |PXIe-4480/4481 Getting Started Guide

Caution When installing the module, make sure both edges are positioned inside

the guides and that the module components do not come into contact with adjacent

modules.

Figure 2. Sliding the PXIe-4480/4481 into the Chassis

9. Latch the module in place by pulling up on the ejector handle.

10. Secure the module front panel to the chassis using the front-panel mounting screws.

Note Tightening the top and bottom mounting screws increases mechanical

stability and also electrically connects the front panel to the chassis, which can

improve the signal quality and electromagnetic performance.

11. Cover all empty slots using filler panels or slot blockers to maximize cooling air flow.

12. Power on the chassis.

1Chassis

2 Hardware Module

3 Injector/Ejector Handle in Down (Unlatched) Position

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

PXIe-4480/4481 Getting Started Guide |© National Instruments |7

Configuring the Hardware in MAX

Use NI Measurement & Automation Explorer (MAX) to configure your National Instruments

hardware. MAX informs other programs about which modules reside in the system and how they

are configured. MAX is automatically installed with NI-DAQmx.

1. Launch MAX.

2. In the Configuration pane, expand Devices and Interfaces to see a list of installed modules.

Installed modules appear under the name of their associated chassis.

Note If you are using the PXIe-4480/4481 with the LabVIEW Real-Time Module,

expand Remote Systems. Find your target IP address or name, expand it, and then

expand Devices and Interfaces.

3. Expand your Chassis tree item. MAX lists all modules installed in the chassis. Your default

module names may vary.

Note If you do not see your hardware listed, press <F5> to refresh the list of

installed modules. If the module is still not listed, power off the system, ensure

the module is correctly installed, and restart.

4. Record the device identifier MAX assigns to the hardware. Use this identifier when

programming the PXIe-4480/4481.

5. Right-click the device and select Self-Test to perform a basic verification of hardware

resources.

6. (Optional) Right-click the device and select Configure to add accessory information and

configure the device.

7. Right-click the device and select Test Panels to test device functionality.

Click Start to test the device functions, and then Stop and Close to exit the test panel.

If the test panel displays an error message, refer to ni.com/support.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8|ni.com |PXIe-4480/4481 Getting Started Guide

Connecting Signals

The PXIe-4480/4481 front panel has one 73-pin 12x InfiniBand connector. Connect analog input

signals using a shielded InfiniBand 12x cable, as described in the Other Equipment section.

Secure the cable to the module front panel using the cable connector jackscrews.

Note Tightening the top and bottom jackscrews on the InfiniBand connector

increases mechanical stability and improves signal quality and electromagnetic

performance.

Figure 3 shows the front panel connections of the PXIe-4480 and PXIe-4481 modules.

Figure 3. PXIe-4480/4481 Front Panel

1 Top Module

Mounting Screw

2LEDs

3PFI

4 Chassis Ground

5AI0-5

6 Bottom Module

Mounting Screw

PXIe-4481

DSA 6 Ch AI

ACCESS ACTIVE

PFI 0

AI 0–5

PXIe-4480

DSA 6 Ch AI

ACCESS ACTIVE

PFI 0

AI 0–5

G10

G11

G12

G13

G14

G15

G16

G17

G18

G19

G20

G21

G22

G23

G24

G25

AI 0 +

AI 0 –

AI 1 +

AI 1 –

AI 2 +

AI 2 –

AI 3+

AI 3–

AI 4 +

AI 4 –

AI 5 +

AI 5 –

S7S8

S9S10

S11S12

S13

S14

S15

S16

S17

S18

S19

S20

S21

S22

S23

S24

S25

S26

S27

S28

S29

S30

S31

S32

S33

S34

S35

S36

S37

S38

S39

S40

S41

S42

S43

S44

S45

S46

S47

S48

EX 0 +

EX 2 +

EX 3+

EX 4 +

EX 5 +

EX 1 +

EX 0 GND

EX 1 GND

EX 2 GND

EX 3GND

EX 4 GND

EX 5 GND

RESERVED

RESERVEDRESERVED

GND– –

GND

– –

GND– –

G10

G11

G12

G13

G14

G15

G16

G17

G18

G19

G20

G21

G22

G23

G24

G25

AI 0 +

AI 0 –

AI 1 +

AI 1 –

AI 2 +

AI 2 –

AI 3+

AI 3–

AI 4 +

AI 4 –

AI 5 +

AI 5 –

S7S8

S9S10

S11

S12

S13

S14

S15

S16

S17

S18

S19

S20

S21

S22

S23

S24

S25

S26

S27

S28

S29

S30

S31

S32

S33

S34

S35

S36

S37

S38

S39

S40

S41

S42

S43

S44

S45

S46

S47

S48

RESERVED

RESERVEDRESERVED

GND– –

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Note Refer to the PXIe-4480/4481 Specifications for information about the

operating input range and overvoltage protection.

Connecting RJ50 Cables

The SHB12X-6RJ50 shielded InfiniBand 12x cable provides six RJ50 (10-pin) inputs. Refer to

Table 2 for signal names and descriptions, and the correlation to the pin numbers of the RJ50

modular plug.

Connecting BNC Cables

The SHB12X-6BNC shielded InfiniBand 12x cable provides six BNC inputs. Refer to Table for

signal names and descriptions, and the correlation to the pin numbers of the BNC plug.

Table 2. RJ50 Connector Pin Assignments

RJ50 Modular Plug

Pin Number Diagram Pin Signal Name Signal Description

1NC No connect

2AI+ Positive analog input signal (0 to 5)

3AI- Negative analog input signal (0 to 5)

4NC —

5NC —

6EX+ Positive excitation (0 to 5)

7EX GND Excitation ground (0 to 5)

8NC —

9GND Ground

10 NC —

Shell GND Ground

Table 3. BNC Connector Pin Assignments

BNC Connector Pin

Diagram Pin Signal Name Signal Description

1AI+ Positive analog input signal (0 to 5)

2AI- Negative analog input signal (0 to 5)

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Otros manuales para PXIe-4480

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de E/S de National Instruments

National Instruments

National Instruments VXI-MIO Series Manual de usuario

National Instruments

National Instruments Isolated Analog Output Module SCC-AO10 Manual de usuario

National Instruments

National Instruments NI 9208E Manual de usuario

National Instruments

National Instruments PXI-6289 Manual de usuario

National Instruments

National Instruments 653 Series Manual de usuario

National Instruments

National Instruments DAQ M Series Manual de usuario

National Instruments

National Instruments R Series Intelligent DAQ PCI/PXI-783xR Manual de usuario

National Instruments

National Instruments 9232 Manual

National Instruments

National Instruments NI-9228 Manual

National Instruments

National Instruments USB-6501 Manual de usuario

National Instruments

National Instruments SCC-68 Manual de usuario

National Instruments

National Instruments PXIe-7822R Manual de usuario

National Instruments

National Instruments FD-11634 Manual de usuario

National Instruments

National Instruments NI 9205 Manual de usuario

National Instruments

National Instruments 9225E Manual de usuario

National Instruments

National Instruments NI USB-9229 Manual de usuario

National Instruments

National Instruments PXIe-7865 Manual

National Instruments

National Instruments AT E Series Manual de usuario

National Instruments

National Instruments 6711 Manual de usuario

National Instruments

National Instruments R Series Manual de usuario

National Instruments

National Instruments 9262 Manual de usuario

National Instruments

National Instruments NI USB-9219 Manual de usuario

National Instruments

National Instruments TBX-68 Manual de usuario

National Instruments

National Instruments NI 9209 Manual de usuario

Manuales populares de Sistema de E/S de otras marcas

WAGO

WAGO 750-344 Manual de usuario

Teknim

Teknim TWM-1887 Manual de instrucciones

Intelligent Appliance

Intelligent Appliance IA-2662-E Manual de usuario

BERGHOF

BERGHOF ECC DIO 16/16 Manual de instrucciones

Advantech

Advantech PCM-27J3AU Manual de instalación y operación

Festo

Festo CP-E08-M12-CL Manual de usuario

Measurement Computing

Measurement Computing PCI-DAS64/M1/16 Manual de usuario

Hitachi

Hitachi HX-RIO3 Series Manual de usuario

NUUO

NUUO SCB-A08 Manual de usuario

M-system

M-system R3Y-RS8 Manual de usuario

jablotron

jablotron JB-110N Manual de usuario

Omron

Omron SYSMAC C200H Manual de usuario

DOLD

DOLD SAFEMASTER M Manual de usuario

ABB

ABB OPT-MF-001 Manual de usuario

Omron

Omron SYSMAC C2000H Manual de usuario

Helmholz

Helmholz TB20 Manual de usuario

ICP DAS USA

ICP DAS USA tM-AD2 Manual de usuario

Automationdirect.com

Automationdirect.com DL305 Manual de usuario
