TN-5510-2GLSX-ODC

Hardware Installation Guide

Moxa ToughNet Switch

Second Edition, August 2013

- 2 -

Overview

The ToughNet TN-5510-2GLSX-ODC series M12 managed Ethernet

switches are designed for industrial applications in harsh environments.

The TN series switches use M12 connectors to ensure tight, robust

connections, and guarantee reliable operation against environmental

disturbances, such as vibration and shock. The switch supports a power

input range 12/24/36/48 VDC.

TN-5510-2GLSX-ODC switches provide up to 8 Fast Ethernet M12 ports,

and 2 Gigabit Fiber ports on the bottom panel which allow cable lengths

up to 2 km. The TN-5510 Ethernet switch is compliant with the essential

sections of EN 50155 (railway applications), making it suitable for a

variety of industrial applications.

Package Checklist

Your ToughNet TN-5510-2GLSX-ODC switch is shipped with the following

items. If any of these items is missing or damaged, please contact your

customer service representative for assistance.

•1 Moxa ToughNet switch.

•Hardware installation guide.

•CD-ROM with user’s manual, Windows utility, and SNMP MIB file.

•Moxa product warranty statement.

•M12 to DB9 console port cable.

•2 protective caps for console and relay output ports.

•Panel mounting kit.

Features

Anti-Vibration Circular Connectors for Robust Links

•M12 D-coding 4 pins female connectors for Fast Ethernet

10/100BaseT(X) ports.

•Fiber-optic ODC connectors with embedded 2 km Gigabit Ethernet

1000BaseLSX.

•M12 A-coding 5 pins male connectors for console and relay output.

•M23 6 pins male connector for power input.

Dual Power Inputs

•Supports 12/24/36/48 VDC (8.4–60 VDC).

High Performance Network Switching Technology

•IEEE 1588 PTP (Precision Time Protocol) for precise time

synchronization of networks.

•DHCP Option 82 for IP address assignment with different policies.

•Modbus/TCP industrial Ethernet protocol.

•Turbo Ring, Turbo Chain,and RSTP/STP (IEEE802.1w/D).

•IGMP Snooping and GMRP for filtering multicast traffic from industrial

Ethernet protocols.

•Port-based VLAN, IEEE802.1Q VLAN, and GVRP protocol to ease

network planning.

•QoS (IEEE802.1p/1Q and TOS/DiffServ) to increase determinism.

•802.3ad, LACP for optimum bandwidth utilization.

•IEEE802.1X and https/SSL to enhance network security.

•SNMP v1/v2c/v3 for different levels of network management.

•RMON for efficient network monitoring and proactive capability.

•Bandwidth management prevents unpredictable network status.

- 3 -

•Lock port allows access by only authorized MAC addresses.

•Port mirroring for online debugging.

•Automatic warning by exception through email, relay output.

•Automatic recovery of connected device’s IP addresses.

•Line-swap fast recovery.

•LLDP for automatic topology discovery in network management

software.

•Configurable through Web browser, Telnet/Serial console, and

Windows utility.

Designed for Industrial-Specific Applications

•Three rotary switches for setting the last 3 digits of the IP address

makes maintenance even easier.

•Compliant with essential sections of EN 50155 (railway applications)

•-40 to 75°C operating temperature range.

•IP54, rugged high-strength case.

•Panel mounting or DIN-Rail mounting installation capability.

Recommended Optional Accessories

•CBL-M23(FF6P)Open-BK-100-IP67: 1-meter M23 to 6-pin power

cable with IP67-rated female 6-pin M23 connector.

•CBL-M12D(MM4P)/RJ45-100 IP67: 1-meter M12-to-RJ45 Cat-5E UTP

Ethernet cable with IP67-rated male 4-pin M12 D-coded connector.

•CBL-M12(FF5P)/OPEN-100 IP67: 1-meter M12-to-5-pin power cable

with IP67-rated female 5-pin M12 A-coded connector.

•M12D-4P-IP68: Field-installable M12 D-coded screw-in connector,

male 4-pin, IP68-rated.

•M12A-5P-IP68: Field-installable M12 A-coded screw-in connector,

female 5-pin, IP68-rated.

•CAP-M12F-M: Metal cap for M12 female connector.

•DK-DC50131: DIN-Rail mounting kit, 50 x 131 mm.

•PLG-WPRJ-02: Field-installable circular connector kit for RJ45

twisted-pair cable, IP67-rated.

- 4 -

TN-5510-2GLSX-ODC Panel Layouts

1. 3 Rotary switches and protective cover with Model name.

2. Screw holes for panel mounting kit.

3. Console port.

4. Grounding screw.

5. Relay output port.

6. Power input voltage range indication.

7. Power input port (male 6-pin shielded M23 connector).

- 5 -

8. PWR1 LED: for power input 1.

9. PWR2 LED: for power input 2.

10.

FAULT LED.

11.

MSTR/HEAD LED: for ring master or chain head.

12.

CPLR/TAIL LED: for ring coupler or chain tail.

13.

TP port’s 10/100 Mbps LED.

14.

10/100BaseT(X) port (female 4-

pin shielded M12 connector with D

coding).

15.

Waterproof vent.

16.

Product label.

17.

12 Screw holes for DIN-Rail mounting kit.

18.

E2 LED: Down-side E2 Gigabit port's 1000 Mbps LED.

19.

E1 LED: Down-side E1 Gigabit port's 1000 Mbps LED.

20.

Gigabit Fiber port E1 (corresponding to port 9 in the TN-

5510 User's

Manual).

21.

Gigabit Fiber port E2 (corresponding to port 10 in the TN-5510

User's Manual).

ATTENTION

Please DO NOT open or remove vent

15. The warranty will be

invalid if the seal is removed.

All exposed connectors, including

3, 5, 7, and 14, should be

tightly covered by protective caps when they are not in use to

ensure for

IP54 protection.

After setting rotary switch

, the protective cover must be fixed

properly to ensure IP54 protection.

- 6 -

Mounting Dimensions (unit = mm)

TN-5510-2GLSX-ODC Series

- 7 -

Panel/Wall Mounting

STEP 1:

Mounting the TN-5510 to a wall requires 4 screws. Use the ToughNet

switch as a guide to mark the correct positions of the 4 screws.

STEP 2:

Use the 4 screws in the panel mounting kit. If you

would like to use your own screws, make sure the

screw head is between 6.0 mm and 7.0 mm in

diameter and the shaft is less than 4.0 mm in

diameter, as shown at the right.

Do not screw the screws in all the way—leave a

space of about 2 mm to allow room for sliding the ToughNet switch

between the wall and the screws.

NOTE

Before tightening the screws into the wall, make sure the screw

head and shaft size are suitable by inserting the screw through

one of the keyhole-shaped apertures of the ToughNet switch.

STEP 3:

Once the screws are fixed in the wall, hang the ToughNet switch on the 4

screws through the large opening of the keyhole-shaped apertures, and

then slide the switch downwards. Tighten the four screws for added

stability.

NOTE

To provide greater protection from vibrations and shocks, use

screws with shaft diameter between 6.0 mm and 7.0 mm, and fix

the ToughNet switch onto the wall directly through the large

opening of the keyhole-shaped apertures.

- 8 -

DIN-Rail Mounting (optional)

Use a pair of optional DK

-DC50131

DIN

-Rail mounting kits (must be

purchase

d separately) to mount the

-5510 on a 35 mm DIN-Rail.

STEP 1:

Use 12 screws (6 screws per plate) to

attach the two DIN

-Rail attachment

plates to the rear panel of the switch

STEP 2:

If the spring-loaded bracket is locked in place, push the recessed button

to release it. Once released, you should feel some resistance from the

spring as you slide the bracket up and down a few millimeters in each

direction.

STEP 3:

Insert the top of the DIN

-Rail into

the top slot of the DIN

-Rail

attachment plates.

STEP

The DIN

Rail attachment plates will

snap into position, as shown in the

figure below.

To remove the Moxa ToughNet Switch from the DIN-Rail, use a

screwdriver to pull down the bottom parts of the two spring-loaded

brackets until they are fixed in the “locked” position, and then reverse

Steps 3 and 4 above.

- 9 -

Wiring Requirements

WARNING

Turn the power off before disconnecting modules or wires. The

correct power supply voltage is listed on the product label. Check

the voltage of your power source to make sure you are using the

correct voltage. Do NOT use a voltage greater than what is

specified on the product label.

These devices must be supplied by a SELV source as defined in

the Low Voltage Directive 2006/95/EC and 2004/108/EC.

ATTENTION

Safety First!

Observe all electrical codes dictating the

maximum current

allowable for each wire size. If the current

goes above the

maximum ratings, the wiring could overheat,

causing serious

damage to your equipment.

ATTENTION

Safety First!

Be sure to disconnect the power cord before installing and/or

wiring your Moxa switch.

This device has UL508 approval. Use copper conductors only,

60/75°C, and tighten to 4.5 poun

d-inches. For use in pollution

degree 2 environments.

Please read and follow these guidelines:

•Use separate paths to route wiring for power and devices. If power

wiring and device wiring paths must cross, make sure the wires are

perpendicular at the intersection point.

NOTE

Do not run signal or communications wiring and power wiring

through the same wire conduit. To avoid interference, wires with

different signal characteristics should be routed separately.

•You can use the type of signal transmitted through a wire to

determine which wires should be kept separate. The rule of thumb is

that wiring that shares similar electrical characteristics can be

bundled together.

•Keep input wiring and output wiring separated.

•It is strongly advised that you label wiring for all devices in the system

when necessary.

Grounding the ToughNet Switch

Grounding and wire routing help limit the effects of noise due to

electromagnetic interference (EMI). Run the ground connection from the

grounding screw to the grounding surface prior to connecting devices.

- 10 -

ATTENTION

This product is intended to be mounted to a well-grounded

mounting surface such as a metal panel.

Connecting the Power Supplies

The ToughNet TN-5510 switches support two sets of power

supplies—power input 1 and power input 2.The M23 6-pin male connector

on the TN-5510’s front panel is used for the dual power inputs. Use a

power cord with an M23 6-pin female connector to connect the power

inputs to the switch.

Pinouts for the power input port on the TN-5510

Pinouts for the power input port on the TN-5510.

Description

Usage

PWR1 Live / DC +

Connect “PWR1 Live / DC +” to the Live

terminal when using an AC power source

or to the positive (+) terminal when using

a DC power source.

PWR1 Neutral / DC -

Connect “PWR1 Neutral / DC –“to the

Neutral terminal when using an AC power

source or to the negative (-) terminal

when using a DC power source.

Chassis Ground

Connect the “Chassis Ground” to the

safety ground terminal for AC inputs or to

the equipment ground bus for DC inputs.

PWR2 Neutral / DC -

Connect “PWR2 Neutral / DC –”to the

Neutral terminal when using an AC power

source or to the negative (-) terminal

when using a DC power source.

PWR2 Live / DC +

Connect “PWR2 Live / DC +” to the (Live)

termi

nal when using an AC power source

or to the positive (+) terminal when using

a DC power source.

Tabla de contenidos

Otros manuales de Cambiar de Moxa Technologies

Moxa Technologies

Moxa Technologies EtherDevice EDS-4012 Series Manual de usuario

Moxa Technologies

Moxa Technologies ICS-G7526 Series Manual

Moxa Technologies

Moxa Technologies EDS-G2008-EL Series Manual de usuario

Moxa Technologies

Moxa Technologies MDS-G4000-L3-4XGS Series Manual de usuario

Moxa Technologies

Moxa Technologies EtherDevice EDS-405A/408A Series Manual

Moxa Technologies

Moxa Technologies EtherDevice EDS-518A-T Manual

Moxa Technologies

Moxa Technologies PT-7710 Series Manual

Moxa Technologies

Moxa Technologies PT-7728 Series Manual de usuario

Moxa Technologies

Moxa Technologies PowerTrans PT-7728-PTP Manual

Moxa Technologies

Moxa Technologies PT-7324 Series Manual de usuario

Moxa Technologies

Moxa Technologies EtherDevice EDS-510A Series Manual de usuario

Moxa Technologies

Moxa Technologies EtherDevice EDS-G508E-T Manual

Moxa Technologies

Moxa Technologies TN-4516A non-PoE series Manual de usuario

Moxa Technologies

Moxa Technologies EDS-316 Series Manual de usuario

Moxa Technologies

Moxa Technologies NSwitch Outdoors Manual de usuario

Moxa Technologies

Moxa Technologies ICS-G7 Series Manual de usuario

Moxa Technologies

Moxa Technologies EDS-505A Series Manual

Moxa Technologies

Moxa Technologies EDS-600 Series Manual de usuario

Moxa Technologies

Moxa Technologies EDS-G205-1GTXSFP-T Manual

Moxa Technologies

Moxa Technologies TN-5308-LV Manual de usuario

Moxa Technologies

Moxa Technologies NPort S8458 Series Manual de usuario

Moxa Technologies

Moxa Technologies EtherDevice EDS-508 Series Manual de usuario

Moxa Technologies

Moxa Technologies EDS-208 series Manual de usuario

Moxa Technologies

Moxa Technologies EDS-516A Series Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
