Moxa Technologies EtherDevice Manual

Moxa EtherDevice Server

Hardware Installation Guide

Fourth Edition, June 2008

Reproduction without permission is prohibited.

Moxa EtherDevice Server (EDS)

Hardware Installation Guide

The software described in this manual is furnished under a license agreement and may be used only in

accordance with the terms of that agreement.

Reproduction without permission is prohibited.

Trademarks

MOXA is a registered trademark of Moxa Inc.

All other trademarks or registered marks in this manual belong to their respective manufacturers.

Disclaimer

Information in this document is subject to change without notice and does not represent a

commitment on the part of Moxa.

Moxa provides this document “as is,” without warranty of any kind, either expressed or implied,

including, but not limited to, its particular purpose. Moxa reserves the right to make improvements

and/or changes to this manual, or to the products and/or the programs described in this manual, at any

time.

Information provided in this manual is intended to be accurate and reliable. However, Moxa

Technologies assumes no responsibility for its use, or for any infringements on the rights of third

parties that may result from its use.

This product might include unintentional technical or typographical errors. Changes are periodically

made to the information herein to correct such errors, and these changes are incorporated into new

editions of the publication.

Technical Support Contact Information

www.moxa.com/support

Moxa Americas:

Toll-free: 1-888-669-2872

Tel: +1-714-528-6777

Fax: +1-714-528-6778

Moxa China (Shanghai office):

Toll-free: 800-820-5036

Tel: +86-21-5258-9955

Fax: +86-10-6872-3958

Moxa Europe:

Tel: +49-89-3 70 03 99-0

Fax: +49-89-3 70 03 99-99

Moxa Asia-Pacific:

Tel: +886-2-8919-1230

Fax: +886-2-8919-1231

Table of Contents

1. Introduction.................................................................................. 1-1

Inside the Future of IndustrialEthernet Technology......................... 1-2

Moxa EtherDevice Server™........................................................ 1-2

Package Checklist....................................................................... 1-4

Features ...................................................................................... 1-5

Specifications............................................................................... 1-6

Top/Front/Rear Panel Views of ED6008...................................... 1-9

Top/Front/Rear Panel Views of ED6008-M-SC........................... 1-10

Top/Front/Rear Panel Views of ED6008-S-SC............................ 1-11

Top/Front/Rear Panel Views of ED6008-MM-SC........................ 1-12

Top/Front/Rear Panel Views of ED6008-SS-SC ......................... 1-13

2. Installing Moxa EtherDevice Server........................................... 2-1

Mounting Dimensions.................................................................. 2-2

DIN-Rail Mounting....................................................................... 2-3

Wall Mounting.............................................................................. 2-4

3. Wiring Moxa EtherDevice Server ............................................... 3-1

Wiring Requirements................................................................... 3-2

Grounding Moxa EtherDevice Server.......................................... 3-4

Wiring the Alarm Contact............................................................. 3-5

Wiring the Redundant Power Inputs............................................ 3-5

Communication Connections ...................................................... 3-8

RS-232 Connection............................................................... 3-9

10/100BaseTx Ethernet Port Connection............................. 3-11

100BaseFx Ethernet Port Connection.................................. 3-14

4. Hardware Overview ......................................................................4-1

Redundant Power Inputs..............................................................4-2

Alarm Contact...............................................................................4-2

LED Indicators..............................................................................4-3

Auto MDI/MDI-X Connection........................................................4-4

Fiber Ports....................................................................................4-5

Dual Speed Functionality and Switching......................................4-6

Switching, Filtering, and Forwarding............................................4-6

Switching and Address Learning..................................................4-7

Auto-Negotiation and Speed Sensing..........................................4-7

1 Introduction

Welcome to Moxa EtherDevice Server™, the redundant and

intelligent 8-port Industrial Ethernet Switch.

The following topics are covered in this chapter:

Inside the Future of Industrial Ethernet Technology

Moxa EtherDevice Server™

Package Checklist

Features

Specifications

Top/Front/Rear Panel Views of ED6008

Top/Front/Rear Panel Views of ED6008-M-SC

Top/Front/Rear Panel Views of ED6008-S-SC

Top/Front/Rear Panel Views of ED6008-MM-SC

Top/Front/Rear Panel Views of ED6008-SS-SC

Inside the Future of Industrial Ethernet Technology

The trend in industrial communications and automation

applications

As the world’s network and information technology becomes

more mature, the trend is to use Ethernet as the major

communications interface in many industrial communications

and automation applications. In fact, a whole new industry has

sprung up to provide Ethernet products that comply with the

requirements of demanding industrial applications.

Industrial vs. Commercial

Users have found that when moving Ethernet from the

comfortable office environment to the harsh and less

predictable industrial environment, the commercial Ethernet

equipment available in today’s market simply cannot meet the

high reliability requirements demanded by industrial applications.

This means that a more robust type of network equipment,

commonly referred to as industrial Ethernet equipment, is

required for these applications.

Informative vs. Passive

Since industrial Ethernet devices are often located at the

endpoints of a system, such devices cannot always know

what’s happening elsewhere on the network. This means that

industrial Ethernet communication equipment that connects

these devices must take responsibility for providing system

maintainers with real-time alarm messages.

Moxa EtherDevice Server™

MOXA EtherDevice Server Hardware Installation Guide

1-2

Introduction

Moxa EtherDevice Server comes with a suite of useful

maintenance and monitoring functions, and is designed to provide

smooth and reliable operation in harsh industrial environments.

You will find that Moxa EtherDevice Server establishes a new

industrial Ethernet benchmark. It is excellent for keeping

automation systems running continuously, is ideal for sending

status reports to help prevent system damages and losses, is a

great tool for mastering your industrial Ethernet networks, and is

well-suited for use with industrial device control networks.

These products have a wide operating temperature range, from -40

to 75°C, and are designed to withstand a high degree of vibration

and shock. The rugged hardware design makes ED6008 Series

perfect for ensuring that your Ethernet equipment can withstand

critical industrial applications, such as in hazardous locations

(Class 1 Division 2/ Zone 2), and complies with FCC, TÜV, UL, and

CE Standards.

NOTE Throughout this User’s Manual, we often use EDS as an

abbreviation for Moxa EtherDevice Server:

EDS = Moxa EtherDevice Server

MOXA EtherDevice Server Hardware Installation Guide 1-3

Package Checklist

Moxa EtherDevice Server is shipped with the following items. If any

of these items is missing or damaged, please contact your

customer service representative for assistance.

Moxa EtherDevice Server

Hardware Installation Guide and User’s Manual

Moxa Product Warranty booklet

Panel mounting kit

Console port cable (RJ45 to DB9)

Protective caps for unused ports

MOXA EtherDevice Server Hardware Installation Guide

1-4

Introduction

Features

Excellent for keeping automation systems running continuously

zLine-Swap fast recovery (patent pending)

zRedundant Ethernet Ring capability

zRedundant power inputs

zHardened design for harsh environments

Operating temperature ranges from 0 to 60°C, or extended

operting temperature from –40 to 75°C for (-T) models

IP 30, rugged high-strength case

Fanless design

DIN-Rail or panel mounting ability

zWatch-dog self-saver™

Dynamically know the status of networked industrial devices

zAutomatically sends warning e-mail when an exception is

detected

zAutomatically sends warning e-mail when Ethernet traffic builds

zSignals the system administrator via a Digital Output (DO) line

when a malfunction occurs

Key management functions let you easily master your industrial

Ethernet network

zSet up a mirror port for better online data monitoring

zAssign IP addresses to connected devices

zSend ping commands to identify network segment integrity

zEasily test cable wiring

MOXA EtherDevice Server Hardware Installation Guide 1-5
