Moxa Technologies EtherDevice Manual de usuario

MOXA EtherDevice Server

User’s Manual

Fourth Edition, February 2004

Moxa Technologies Co., Ltd.

Tel: +886-2-8919-1230

Fax: +886-2-8919-1231

www.moxa.com

[email protected] (Worldwide)

support@moxa.com (Americas)

MOXA EtherDevice Server (EDS)

User’s Manual

The software described in this manual is furnished under a license agreement and

may be used only in accordance with the terms of that agreement.

Reproduction without permission is prohibited.

Trademarks

MOXA is a registered trademark of Moxa Technologies Co., Ltd.

All other trademarks or registered marks in this manual belong to

their respective manufacturers.

Disclaimer

Information in this document is subject to change without notice and does not

represent a commitment on the part of Moxa.

Moxa provides this document “as is,” without warranty of any kind, either

expressed or implied, including, but not limited to, its particular purpose. Moxa

reserves the right to make improvements and/or changes to this manual, or to the

products and/or the programs described in this manual, at any time.

Information provided in this manual is intended to be accurate and reliable.

However, Moxa Technologies assumes no responsibility for its use, or for any

infringements on the rights of third parties that may result from its use.

This product might include unintentional technical or typographical errors.

Changes are periodically made to the information herein to correct such errors,

and these changes are incorporated into new editions of the publication.

Table of Contents

1Introduction ............................................................ 1-1

Inside the Future of Industrial Ethernet Technology.....1-2

MOXA EtherDevice Server™ ......................................1-3

Package Checklist .........................................................1-3

Features .........................................................................1-4

Specifications ................................................................1-5

2How To Use MOXA EtherDevice Server ................ 2-1

Basic Switching Function .............................................2-2

Redundant Ethernet Ring Setup ....................................2-4

Basic Device Management............................................2-5

Advanced Device Management ....................................2-6

DHCP Server Configuration....................................2-7

3Featured Functions ................................................ 3-1

Startup Procedure ..........................................................3-3

RS-232 Console (115200, None, 8, 1, VT100)........3-3

Telnet Console .........................................................3-8

Web Configuration................................................. 3-11

Monitor........................................................................3-14

Console Monitor ....................................................3-14

Web Browser Monitor ...........................................3-16

Auto Warning ..............................................................3-19

Email Warning .......................................................3-19

Relay Warning .......................................................3-26

Line-Swap Fast Recovery........................................... 3-32

Communication Redundancy...................................... 3-33

Spanning Tree Protocol (802.1D).......................... 3-35

Turbo Ring............................................................. 3-42

Assigning IP Addresses to Connected Devices .......... 3-52

Mirror Port .................................................................. 3-55

Segment Integrity........................................................ 3-58

Cable Tester ................................................................ 3-59

Advanced Settings ...................................................... 3-61

Server..................................................................... 3-61

Port ........................................................................ 3-65

Network ................................................................. 3-67

Factory Default...................................................... 3-69

Upgrade Firmware by Console.............................. 3-70

Activate Settings.................................................... 3-73

4EDS Configurator GUI ............................................4-1

Starting EDS Configurator............................................ 4-2

Broadcast Search........................................................... 4-3

Search by IP address ..................................................... 4-4

Upgrade Firmware ........................................................ 4-5

Modify IP Address ........................................................ 4-6

Export Configuration .................................................... 4-7

Import Configuration .................................................... 4-8

Unlock Server ............................................................. 4-10

A SNMP Agents with MIB II........................................A-1

Supported SNMP Variables ......................................... A-2

MIB Value Descriptions ............................................... A-6

B Service Information...................................................B-1

MOXA Internet Services.............................................. B-2

Problem Report Form................................................... B-3

Return Procedure.......................................................... B-4

Revision History........................................................... B-5

1 Introduction

Welcome to MOXA EtherDevice Server™, the world’s first intelligent

Ethernet Device Server specially designed for connecting

Ethernet-enabled devices in industrial field applications.

The following topics are covered in this chapter:

 Inside the Future of Industrial Ethernet Technology

 MOXA EtherDevice Server™

 Package Checklist

 Features

 Specifications

MOXA EtherDevice Server User’s Manual

1-2

Inside the Future of Industrial Ethernet Technology

The trend in industrial communications and

automation applications

As the world’s network and information technology becomes more

mature, the trend is to use Ethernet as the major communications interface

in many industrial communications and automation applications. In fact, a

whole new industry has sprung up to provide Ethernet products that

comply with the requirements of demanding industrial applications.

Industrial vs. Commercial

Users have found that when moving Ethernet from the comfortable office

environment to the harsh and less predictable industrial environment, the

commercial Ethernet equipment available in today’s market simply

cannot meet the high reliability requirements demanded by industrial

applications. This means that a more robust type of network equipment,

commonly referred to as industrial Ethernet equipment, is required for

these applications.

Informative vs. Passive

Since industrial Ethernet devices are often located at the endpoints of a

system, such devices cannot always know what’s happening elsewhere on

the network. This means that industrial Ethernet communication

equipment that connects these devices must take responsibility for

providing system maintainers with real-time alarm messages.

Introduction

MOXA EtherDevice Server User’s Manual 1-3

MOXA EtherDevice Server™

MOXA EtherDevice Server comes with a suite of useful maintenance and

monitoring functions, and is designed to provide smooth and reliable

operation in harsh industrial environments. You will find that MOXA

EtherDevice Server establishes a new industrial Ethernet benchmark. It is

excellent for keeping automation systems running continuously, is ideal

for sending status reports to help prevent system damages and losses, is a

great tool for mastering your industrial Ethernet networks, and is

well-suited for use with industrial device control networks.

NOTE Throughout this User’s Manual, we often use EDS as an

abbreviation for MOXA EtherDevice Server:

EDS = MOXA EtherDevice Server

Package Checklist

MOXA EtherDevice Server is shipped with the following items. If any of

these items is missing or damaged, please contact your customer service

representative for assistance.

 MOXA EtherDevice Server

 User’s Manual

 MOXA Product Warranty booklet

 Panel mounting kit

 Console port cable (RJ45 to DB9)

 Protective caps for unused ports

MOXA EtherDevice Server User’s Manual

1-4

Features

Excellent for keeping automation systems running continuously

 Line-Swap fast recovery (patent pending)

 Redundant Ethernet Ring capability

 Redundant power inputs

 Hardened design for harsh environments

 0℃to 60℃for cold and hot climates

 IP 30, rugged high-strength case

 Fanless design

 DIN-Rail or panel mounting ability

 Watch-dog self-saver™

Dynamically know the status of networked industrial devices

 Automatically sends warning e-mail when an exception is detected

 Automatically sends warning e-mail when Ethernet traffic builds up

 Signals the system administrator via a Digital Output (DO) line when

a malfunction occurs

Key management functions let you easily master your industrial

Ethernet network

 Set up a mirror port for better online data monitoring

 Assign IP addresses to connected devices

 Send ping commands to identify network segment integrity

 Easily test cable wiring
