Motorola ML2410 Manual de usuario

4G LTE Cellular Modem plus

AC1900 WiFi Router

Model ML2410

Quick

Start

Guide

Packaged with your ML2410

Power Adapter

2 LTE Antennas

Ethernet Cable

Para una Guía de Inicio Rápido en español, por favor vaya a

www.motorolanetwork.com/ML2410ir

Let’s get started

To use your ML2410 modem/router you need an activated

micro SIM (3FF format) which you normally receive from your

mobile broadband service provider. If instead you use a nano

SIM card (used by most phones today), you will need a SIM

Card Adapter. SIM card adapters are available from Amazon

and other retailers.

Note: If you want to provide cellular backup to an existing

cable modem or Internet connection, we recommend setting

up and testing the cellular connection first then changing the

configuration to enable cellular backup.

1First, insert the SIM card. Remove the battery cover on the

ML2410’s back panel to access the SIM slot. Using a Phillips

head screwdriver, remove the screw from the battery

cover. Remove the battery cover and insert the SIM. The

copper side of your SIM should be facing inwards and the

notch in the SIM should be facing up. Replace the battery

cover when finished.

2Next, attach the 2 LTE Antennas to the ML2410 by

screwing them finger-tight into the 2 gold connectors

located on the back of the unit.

3Now, connect the supplied power adapter between the

ML2410’s power jack and an electrical outlet. The ML2410

will power up and the power light on the front of the unit

will turn green. If the power light does not turn on, check

that the On/Off button on the back panel is On. Wait for

the Cell Status light to turn on.This may take up to 2

minutes. If the Cell Status light does not turn on, please see

the Troubleshooting Tips at the end of this Quick Start.

If you want to use the ML2410 as cellular backup continue

below, otherwise skip ahead to Connect Your Devices to

configure your wireless network.

Using the ML2410 for Cellular Backup

If you wish to use the ML2410 as a back up option for your

primary Internet connection, you should have first installed it as

a cellular modem above. Then follow these steps.

1Connect the ML2410’s yellow Ethernet cable between

the ML2410’s WAN port and the Ethernet port of a cable

modem, DSL modem, or fiber optic modem used for

Internet access.

2Switch the power off on your primary Internet

connection modem now. (For some modem/routers, this

requires you to remove a power backup battery.) After

the modem is off for at least 10 seconds, switch it back on.

(If you removed a backup battery, plug the battery back

in first.)

3To configure your ML2410 for cellular backup you will

need to access the ML2410’s configuration manager.

First, make a connection:

•For a wired connection, plug an Ethernet cable into

one of the ML2410’s LAN jacks and the other into your

computer’s Ethernet port.

•Or, for a WiFi connection, go into the WiFi setup

section for the other device, such as your phone or

computer (not the ML2410). Then enter the ML2410’s

WiFi Network Name (SSID) and WiFi Password/Key.

The unique factory-set default settings are printed on a

label on the bottom of the modem/router.

4Next, to access the ML2410’s configuration manager

open your Web browser. Type http://192.168.5.1 in the

address bar and press Enter.

•In the Login dialog box, enter the Login information

printed on the bottom label of your ML2410.

•The Basic Setup page will appear. If the Basic Setup

page doesn’t appear, please see the Troubleshooting

Tips below.

•From the dropdown menu next to Connection Type,

select the type of connection you have. Most users

should select DHCP.

•Check the box next to Enable Cellular Backup. This

will turn on cellular backup in case your primary

Internet connection goes down.

•The ML2410 should automatically detect your SIM

card and should be configured correctly.

Now you will Connect Your Devices to configure your

wireless network.

Connect Your Devices

The ML2410 allows many devices to share your Internet

connection. Devices can connect by using WiFi or by

connecting an Ethernet cable into one of the ML2410 Ethernet

ports.

WiFi Wireless

You can connect any of your WiFi devices by first going into

the WiFi setup section for the device (not the ML2410 router).

Then use the ML2410 router’s WiFi Network Name (SSID) and

WiFi Password/Key. The unique factory-set default settings

are printed on a label on the bottom of the ML2410. If you

prefer to use a different network name and password, the

MotoManage™ app is an easy way for you to change your WiFi

network name or password. For more information on our

MotoManage app see the MotoManage section below.

Wired Ethernet

You can also connect up to two smart TV/media players,

computers, game stations, or other devices with an Ethernet

cable between an Ethernet port of the device and either of the

LAN jacks on the router. Some devices have a Network Setup

section where you specify a wired Ethernet connection. If you

have a problem with a particular device, consult its user

manual.

Once you’ve set up a Wireless or Wired Ethernet connection,

try to browse the Web. If browsing works, Congratulations!

Your ML2410 is working.

If your ML2410 is NOT working, see Troubleshooting Tips and

We like to help at the end of this Quick Start.

MotoManage™

We strongly suggest that you download the MotoManage™

App from the Apple App Store or from Google Play to access

basic and advanced network control features. The app lets

you manage your network quickly and easily, and it makes it

easy to keep your network’s original wireless settings

The app includes basic and advanced features which are all

available free of charge for the first month. After that you will

be able to decide whether you’d like to just keep the free

features, or whether you’d like to also keep the advanced

features for a small monthly fee.

1Download the MotoManage app on your smartphone or

tablet.

2Open the app.

3Scan the QR code on the bottom of your ML2410 to setup

your device’s WiFi network.

4Now enjoy the app. You can easily elect to keep your

original name and password, as we recommend. Plus you

can easily monitor your Internet usage and WiFi signal

strength, get security alerts that help protect your

network, control Internet access by devices, or set up

some basic parental controls.

Your ML2410 must be online for the app to communicate with

it.

Front Panel

LIGHT

COLOR

DESCRIPTION

Power

Green

Amber

Green:

ML2410 power on

OFF:

ML2410 power off

Amber:

ML2410 running on battery

Blinking Low battery

Amber:

Cell Status

Green

Amber

Green:

Connected in LTE mode

Amber:

Connected in 3G mode

Blinking:

Off:

Sending data

Not connected

Internet

Green

Green:

ML2410 is online

OFF:

ML2410 is offline

2.4 GHz

WLAN

Green

ON:

2.4 GHz WiFi is enabled

Blinking:

Data is flowing

OFF:

WiFi is not enabled

5 GHz

WLAN

Green

ON:

5 GHz WiFi is enabled

Blinking:

Data is flowing

OFF:

WiFi is not enabled

WPS

Green

ON:

WPS connection successful;

turns off after 5 minutes

Blinking:

WPS in discovery mode

OFF:

WPS not active

Back Panel

RESET –

Resets the ML2410 to

factory defaults

WPS –

WiFi Protected Setup

ANT MAIN

– Main cellular

antenna

ANT DIV

– Diversity cellular

antenna

USB 3.0 PORT

WAN PORT –

Connect to your

modem for cellular backup

LAN PORTS

– Connect a

computer, smart TV/media

player, game station, or other

Ethernet-capable device to

either of these 2 LAN ports

ON/OFF button

POWER

– Connect the

supplied power adapter

between the power jack and an

electrical outlet

BATTERY

–

Install optional

battery to provide Internet

access when power goes out

SIM SLOT –

Located behind

the battery cover. Remove the

cover and insert a Micro (3FF)

SIM card
