Motorola W220 Manual de usuario

motorola W220

Getting to Know Your Phone

Earpiece

Volume Keys

End Key

Navigation Key

Right Soft KeyLeft Soft Key

Send Key

Menu Key

Battery Door

Lanyard Attachment

Power Connector

Headset Jack

Microphone

Note:

Your phone may not appear exactly as the phone image

above, however, all key locations, sequences, and functions

remain the same.

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.

Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally,

certain features may not be activated by your service provider, and/or the provider’s network settings may limit the feature’s

functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other

product specifications, as well as the information contained in this tutorial, are based on the latest available information and

believed to be accurate at the time of publication. Motorola reserves the right to change or modify any information or specifications

without notice or obligation.

Speaker

RADIO MESSAGE

6/1/2006 11:35 am

motorola W220

Make, End, and Answer Calls

To end a call, press

. To answer a call, press

Tip

: To answer a call by pressing any key,

press

then scroll to

Settings

In-Call

Setup

and set

Anykey Answer

12 3

From the home screen, enter a number and

press

Tip:

Press

DELETE

to delete the last

number. Press and hold

DELETE

erase all numbers. Press

, and then

select

SAVE

to add the number to your

Phonebook.

RADIO MESSAGE

6/1/2006 11:35am

OPTIONS DELETE

Entering:

motorola W220

Add Contacts to Your Phonebook

From the home screen, press

Scroll to

Phonebook

, then press

SELECT

Scroll to

New Entry

, then press

.Select whether to store contact information

SIM

card or phone.

Scroll to name and enter the Name of your

contact.

Scroll to the remaining fields (Number Type,

Number, Category, Note type, and Note) and

enter the information.

1 2 3

When you are finished, press

SAVE

RADIO MESSAGE

6/1/2006 11:35am

SELECT EXIT

Phonebook

OPTIONS BACK

Phonebook

[New Entry]

SAVE BACK

New

Memory

SIM

Name:

OPTIONS DELETE

New

Name:

Simon

Number Type

General

SAVE BACK

New

Number Type

General

Number:

motorola W220

Send a Text Message

From the home screen, press

Scroll to

Messages

, then press

SELECT

Scroll to

Create Message

, then press

. Scroll to

New Short Msg

, then press

Enter your message and press

Scroll to

New Number

then press

enter the recipient’s number or select the

recipient(s) from the list and then press

Press

SEND

to send the message.

RADIO MESSAGE

6/1/2006 11:35am

OPTIONS BACK

Message Centre

Create Message

Message Inbox

Outbox

SELECT EXIT

Messages

Drafts

SELECT BACK

Create Message

New Short Msg

New Multimedia Msg

MMS Templates

OPTIONS DELETE

Msg

Hello?

Hello Hello. Hello?

OK BACK

[New Number]

Mark

Simon

SEND BACK

Recipients

motorola W220

Add a Datebook Event

From the home screen, press

Scroll to

Tools

and press

SELECT

Scroll to

Calendar

and press

SELECT

Scroll to the day on which you want to

schedule an event and press

, then scroll

Add New

and press

SELECT

Enter a starting time for the event. Scroll

to other fields to enter information such as:

note type, content, name, phone number,

circulation type, and set an alarm for the

event.

When you are finished, press

SAVE

123

RADIO MESSAGE

6/1/2006 11:35am

SAVE DELETE

Calendar

Time:

12:00

Note type

SELECT EXIT

Tools

OPTIONS EXIT SELECT EXIT

7/10/2006

[Add New]

Appointment

SELECT BACK

7/10/2006

PM 12:00 Appointment

[Add New]

SFTWTMS

motorola W220

Use the FM Radio

Insert the earpiece into the phone.

The earpiece acts as an antenna and must

be inserted for the FM radio to function.

From the home screen, press

Scroll to

Multimedia

and press

SELECT

Scroll to

FM Radio

and press

SELECT

Note

: The FM radio automatically tunes in

to the lowest available frequency when you

use it for the first time. After that, it tunes in

to the frequency last used.

Press

left or right to increase or

decrease the frequency. Press and hold

left or right to scan to the next usable

frequency. To save the channel, press

scroll to

Save Channel

, press

SELECT

and then press

To turn the radio off, press

on the

Radio screen, scroll to

FM Radio Off

, and

then press

SELECT

RADIO MESSAGE

6/1/2006 11:35am

SELECT BACK

FM Radio

Save Channel

Set Frequency

Channel List

Speaker On

SELECT EXIT

Multimedia

MUTE HIDE

MHz

OK BACK

Save Channel

1 100.7MHz

2 87.5MHz

3 87.5MHz

4 87.5MHz

SELECT BACK

FM Radio

Set Frequency

Channel List

Speaker On

FM Radio Off

motorola W220

FM Radio Tips

To play FM radio through the speaker,

press

on the FM Radio screen, scroll to

Speaker On

, and then press

SELECT

To set presets, tune in the desired frequency

by pressing

left or right. Press and

hold

to save that number as the

preset. Select a preset by pressing the

corresponding radio preset

To assign a name to the preset, press

on the

FM Radio screen, scroll to

Channel List

, and

press

SELECT

. Select the channel for which you

want to assign a name, and press

. Enter the

name of the channel and then press

to save

the name.

MUTE HIDE

MHz

MUTE HIDE

MHz

MUTE HIDE

MHz

Jazz

EDIT BACK

Channel List

1 100.7MHz [Jazz]

2 87.5MHz

3 87.5MHz

4 87.5MHz

SELECT BACK

FM Radio

Save Channel

Set Frequency

Channel List

Speaker On
