Mini Gadgets HS580 Manual de usuario

5.8GHZ WIRELESS

CAMERA SYSTEM

SKU: HS580

THANK YOU FOR PURCHASING THE HS580

Please read this manual before operating the 5.8 GHz wireless camera

system and keep it handy.

Our latest wireless camera features 5.8 GHz technology to help

eliminate interference from today’s saturated 2.4 GHz band. It's

perfect whether you need a nanny camera, home or business

surveillance, or automobile security.

5.8 GHz circuitry ensures no lost video due to external wireless

devices, such as Wi-Fi and cellular. The transmitter uses the 5800

MHz (5.8 GHz) channels to help eliminate interference from devices

such as wireless routers. The range is up to 50 meters. Setting up the

camera could not more painless. Simply connect the included AC

adapter to the camera, then attach the wireless receiver to the VCR

or television. That's all there is to it. Covert video surveillance has

never been easier. Its tiny size makes hiding this camera no problem.

Hide in a plant, a book, a video case, air vent, automobile, the only

requirement is to make sure the small lens is facing the video

surveillance target. When properly placed, the wide camera angle will

give you a complete view of a normal size room.

Your purchase should include:

1 x 5.8 GHz Wireless Camera System

1 x Perfectly Matched 5.8GHz Wireless Receiver

1 x Video Cable for Receiver to VCR/TV Hook Up

2 x AC Adapters (1 for camera, 1 for receiver)

1 x 9V Adapter (for camera)

1 x Instruction Booklet

GET FAMILIAR WITH YOUR HS580

OPERATING THE HS580

SET UP

RECEIVER

1. Insert the DC Power Adapter into the DC Input Port on the

Radio AV Receiver

2. Plug the DC Power Adapter into a power source

 The red indicator light will turn on

3. Insert the yellow AV cable into the Video Out Port

4. Insert the white AV cable into the Audio Out Port

5. Insert the other yellow AV cable into the Video In Port of your

TV monitor

6. Insert the other white AV cable into the Audio In Port of your

TV monitor

7. Open and adjust the Antenna

TIP: The camera and receiver should be set up between 50-100m

apart

CAMERA

1. Insert the DC Power Adapter into the DC Input cable of the

Camera

2. Plug the DC Power Adapter into a power source

3. Point the Camera in the direction you want to monitor

TIP: If the video or audio is not working adjust the channel switch on

the Radio AV Receiver

IMPORTANT NOTICE: To prevent interference do not place more

than one camera with the same frequency within the same 50-100m

area

Antenna

Video

Out Port

Audio

Out Port

Indicator

Light

DC Input

Port

Channel

Switch

Camera

Mic

DC Input

Cable

TROUBLESHOOTING

THE DEVICE WON’T TURN ON

 Charge the device for at least 4 hours before the first use

 Make sure the charging cable is securely inserted into the

device and into the power source

THE DEVICE ISN’T CHARGING

 Replace the battery or charging cable

 If you are charging via a wall power source, you may need to

charge via your PC. The AC adapter might be bad

THE SOUND OR VIDEO IS UNCLEAR

 Adjust the channel switch

 Ensure all the cables are inserted completely

OTHER PROBLEMS

 Call our technical support at 770–694–6923
