Mini Gadgets HCPanel Manual de usuario

WALL PANEL HIDDEN

CAMERA

SKU: HCPanel

THANK YOU FOR PURCHASING THE WALL PANEL HIDDEN

CAMERA

Please read this manual before operating the wall panel hidden

camera and keep it handy.

Sometimes the easiest way to hide something is right in front of

everyone. Our newest hidden camera resides within a wall plate,

easily hiding it away while sitting in plain view. With its ability to

record high definition color video as well as its motion activation

feature you'll be sure to catch every detail from the moment

someone enters the room. It's built in rechargeable battery

eliminates the need to constantly replace batteries and it's Micro SD

card storage allows you to adjust the capacity to your needs.

Your purchase should include:

1 x Wall Panel Hidden Camera

1 x USB Cord

1 x Instruction booklet

GET FAMILIAR WITH YOUR WALL PANEL HIDDEN CAMERA

MicroSD

Card Slot

USB Port Mode

Switch

Camera

Lens

Audio

Reset

Power

Indicator

Light

OPERATING THE WALL PANEL HIDDEN CAMERA

IMPORTANT NOTICE: Allow the device to charge 4 – 6 hours before

using.

HOW TO CHARGE THE DEVICE

1. Insert the USB cable into the USB port on the device

2. Insert the USB cable into the USB port on your computer

 The blue indicator light will turn on

HOW TO TURN THE DEVICE ON/OFF

1. Press the Power button located inside the device to turn the

device on

 The blue indicator light will turn on

o The device is now ON and in standby mode

2. Press and hold the Power button again to turn the device off

 The indicator light will turn off

o The device is now OFF

HOW TO RECORD VIDEO MANUALLY

1. Turn the device ON

2. Press the Power button again

 The blue indicator light will flash twice times and then

turn off

o The device is now recording

3. Press the Power button again to stop and save your recording

 The blue indicator light will flash twice and then stay

o The device is now in standby mode

HOW TO RECORD VIDEO USING MOTION DETECTION

1. Turn the device ON

2. Move the Mode Switch to the RIGHT to enter Motion

Detection Mode

 The green indicator light will flash twice and then turn

off

TIP: Hold the edges

of the face plate and

gently press up and

out on the front of

the face plate to

release the backing

 When motion is detected the green light will flash

three times and then turn off

 The device will automatically record and save video

when motion is detected

3. Press the Power button to stop recording

 The blue indicator light will flash twice and then stay

o The device is now in standby mode

HOW TO RECORD VIDEO USING AUDIO DETECTION

1. Turn the device ON

2. Move the Mode Switch to the LEFT

3. Press the Audio button

 The blue and green indicator lights will both flash twice

and then turn off

 When audio is detected the blue and green indicator

lights will both flash and then turn off

 The device will automatically record and save video

when audio is detected

4. Press the Power button to stop recording

 The blue indicator light will flash twice and then stay

o The device is now in standby mode

RETRIEVE THE FILES TO YOUR PC

1. Plug the device into your PC using the USB cable

2. Locate “Removable Disk” inside the (My) Computer folder

 AutoPlay Removable Disk > Open folder to view files

Or…

 Go to Start > Computer > Removable Disk

3. Open the Removable Disk drive

4. Open the DCIM folder

5. Double click the file you want to view

 VLC Player is recommended for watching videos

TROUBLESHOOTING

THE DEVICE WON’T TURN ON

 Charge the device for at least 4 hours before the first use

 Make sure the charging cable is securely inserted into the

device and into the power source

THE DEVICE ISN’T CHARGING

 Replace the battery or charging cable

 If you are charging via a wall power source, you may need to

charge via your PC. The AC adapter might be bad

THE DEVICE HAS CRASHED

 You need to reset the device

MY COMPUTER DOESN’T RECOGNIZE THE DEVICE

 Unplug the device from your PC and reboot the device

 Unplug the device from your PC and reboot your PC

 Try using a different USB slot on your PC

 Replace the USB cable

THE SOUND OR VIDEO IS UNCLEAR

 The device needs charging

OTHER PROBLEMS

 Call our technical support at 770–694–6923

SPECIFICATIONS

Video Resolution

1280x720

Video Format

AVI

Frames per Second

Motion Detection

Yes

Water Resistant

Battery Life

400 minutes

Type of Memory

MicroSD Card

Memory Capacity

32GB

Recording Capacity

2GB ≈ 1 hour

4GB ≈ 2 hours

8GB ≈ 4 hours

16GB ≈ 8 hours

32GB ≈ 16 hours

USB Interface

2.0 USB

Player Software

VLC recommended

Operating Systems Windows 2000 – Windows 8

Mac OSX

Linux
