Milwaukee C65 Manual de usuario

ISTRC65R2 05/03

C65 and C66

Waterproof EC meters

USER MANUAL

SPECIFICATIONS

Range

C65 0 to 1999 µS/cm

C66 0.00 to 10.00 mS/cm

Resolution

C65 1 µS/cm

C66 0.01 mS/cm

Accuracy(@20°C)

±2% F.S.

Typical EMC

±2% F.S.

Deviation

Temperature

Automatic,

Compensation

0 to50°C with β=2%/°C

Calibration

Manual, at 1 point

throughtrimmer

Probe

C65 MA73075 (replaceable)

C66 MA73076 (replaceable) or

MA73076-S (replaceable)

Environment

0to 50°C;100% RH

Batterytype

3 x 1.5V, alkaline

Batterylife

approx.250hoursof

continuoususe

Dimensions

165 x 30 x 30 mm

Weight

80g

This meter is in compliance with the CE directives.

ACCESSORIES

MA73075 ReplaceableConductivity

probe,LR

MA73076 ReplaceableConductivity

probe,HR

MA73076-S ReplaceableConductivity

longprobe,HR

M10031B 1413µS/cmcalibration

solution, 20 mL (25 pcs)

CALIBRATION:

• Immerse the meter in 1413 µS/

cm (M10031) calibration solution.

• Unscrew the battery compartment

cap on the top of the meter.

• Allow the reading to stabilize and

with a small screwdriver turn the

calibration trimmer inside the bat-

tery compartment until the dis-

play shows "1413" for C65 or

“1.41” for C66.

• Replace the battery compartment

cap.

The calibration is now complete.

OPERATION:

• Remove the protective cap.

• Turn the meter on by pressing

the ON key.

• Immerse the probe in the solu-

tion to be tested.

• Stir gently and wait for the read-

ing to stabilize.

• After use, rinse the electrode

with water to minimize contami-

nation.

• Always replace the protective

cap after use.

Note: if the reading is over-

range, the display will

show “1”.

PROBE REPLACEMENT:

The probe can be easily replaced in the

following way:

• Remove the protective cap.

• Unscrew the plastic ring on

the top of the probe.

• Pull out the MA73075 (or

MA73076 or MA73076-S)

probe and replace it with a

new one (aligning the colored

pin towards the LCD side).

• Make sure the gaskets are in

place before screwing back the plastic

ring.

BATTERY REPLACEMENT:

The meter is supplied with BEPS (Battery

Error Preventing System) which avoids any

erroneous reading due to low battery level,

by switching the meter off. To replace the

batteries unscrew the battery compartment

cap and replace all three 1.5V batteries

while paying attention to their polarity. Make

sure the gasket is in place before screwing

back the cap.

Batteries should only be replaced in a non-

hazardous area using the battery type speci-

fied in this instruction manual.

WARRANTY:

These instruments are warranted from all defects in materi-

als and manufacturing for a period of two years from the

date of purchase. The probes are warranted for a period

of one year.

If during this period, the repair or replacement of parts is

required, where the damage is not due to negligence or

erroneous operation by the user, please return the parts to

either dealer or our office and the repair will be effected

free of charge.
