Step 2: Install Software

Step 1: Unpack Contents

Start Here

Installing your Microtek ArtixScan

4020 Plus / ArtixScan

2020 Plus

Unpack your scanner package and check

for major components.

1. Document scanner

2. Power adapter

3. Power cord

4. Software CDs/DVDs

5. Hi-Speed USB cable

Important: Do not remove the yellow stickers from

your scanner until you are told to do so. You must

install software before connecting your scanner.

Always close any open programs and turn off Anti-

virus utilities before installing software.

I49-004804 B, September 2013

A. Turn on your computer.

B. Place the Microtek Software CD/DVD into a drive, and follow the on-screen

instructions to install the scanner driver and software.

C. Restart your computer at the end of all software installation.

NOTE: If the Microtek Software Installer screen does not come up automatically, double-click the

following in succession: “My Computer”; the CD/DVD-ROM icon; then cdsetup.exe to start the

installer program.

Unlocked Locked

A. Remove the yellow “Step 3” sticker from your

scanner.

B. With the scanner power off, tilt the scanner and

locate the locking switch at the bottom left

corner of the scanner. Do not turn the scanner

upside down when attempting to unlock, as this

may damage the scanner’s mechanism.

C. Push the locking switch to the position as

indicated in the graphic, with the icon on the lock

showing as “unlocked”.

NOTE: To lock the scanner (for shipping and other

purposes), turn the locking switch to the “Locked” position.

As in the unlock procedure, do not turn the scanner upside

down when locking the scanner back.

Unlock Scanner

Connect Scanner

To the power adapter

A. Remove the yellow “Step 4” sticker from your scanner.

B. Connect the power adapter to the back of the scanner.

C. Plug one end of the power cord into the power adapter, and plug the other end of the

power cord into a wall outlet or other power source.

To the Hi-Speed USB cable

D. Connect one end of the Hi-Speed

USB cable to your computer.

E. Connect the other end of the

Hi-Speed USB cable to the

scanner’s USB port.

Step 4: Connect Scanner (cont.)

F. Press the Power button at the front

panel of your scanner to turn on the

scanner; the LED (orange) lights at the

button panel.

The system will detect your scanner

automatically.

Power button

Customize the Function Buttons

The ArtixScan DI 4020 Plus/ArtixScan DI 2020 Plus is equipped with 3 programmable

function buttons (F1, F2 and F3) that can be customized to automate a number of

predefined operations, such as scanning to a file, sending an image to your printer,

scanning for OCR, etc. Customizing is done through the Save Settings to Function Button

command in the ScanWizard DI, refer to the ArtixScan DI 4020 Plus/ArtixScan DI 2020

Plus User’s Manual for more details.

3 programmable function buttons

•F1, F2, and F3: Customizes the

function buttons to perform your

preferred functions.

F1 F2 F3

Position a Stack of Documents

A stack of up to 100 documents can be fed in the Document Feed Tray of the Automatic

Document Feeder (ADF). Document sizes can range from 4.33” x 4.33” (110 mm x 110

mm) to 8.5” x 25” (215.9 mm x 635 mm).

1. Pull out the Feed Tray Extender for

better paper support if the length of the

originals exceeds 10 inches.

2. Load the stack of originals onto the

Document Feed Tray, with the side to

be scanned facing up. Push the stack

of papers into the tray until the paper's

edge touches the front edge of the

Document Feed Tray.

WARNING: The document feeder is not

designed for scanning photos; doing so may

damage your originals. Microtek accepts no

responsibility for damage that may arise

from misuse of equipment.

Document Feed Tray

Document Output Tray

Feed Tray Extender

Guide Arms

3. Align the stack of originals with the

center of the Document Feed Tray by

sliding the two Guide Arms toward the

stacked papers if the width of the

originals is less than 8.5 inches.

Scan a Stack of Documents

1. Place the stack of documents to be scanned on the Document Feed Tray of the Auto

Document Feeder (ADF).

WARNING: Do not place photo paper or fragile sheets of paper on the feed tray, as doing this

will damage the original photo or frail papers during the feeding process. Always place frail

originals on the scanner glass surface, and choose “Flatbed” as your “scan source.”

2. Launch ScanWizard DI — either as a stand-alone by clicking the program icon, or by

using the File-Import or Scan command from an application program.

3. Specify your scanning requirements in the ScanWizard DI control panel.

a) Select ADF (Simplex) or ADF (Duplex) in the Scan Source drop-down menu as

your image input device.

b) Select the appropriate image type (e.g., Black & White) in the Scan Type drop-

down menu as your image output type.

– Select RGB Color (24 bits) to scan the image in color.

– Select Grayscale (8 bits) to scan the image in grayscale.

– Select Black & White (1 bit) to scan the image in black-and-white.

c) Select a dimension in the Paper Size drop-down menu as your preview image size.

d) Select a desired resolution in the Resolution drop-down menu for your image

output resolution.

e) If “Auto-crop & Auto-deskew” is selected, the scanner automatically detects the

size of the original image, crops the full scan frame to fit the image, and removes

unwanted black borders after the scan, as well as corrects the distorted image for

proper alignment.

f) If necessary, select a level of paper thickness for the ultrasonic double-feed

detection in the Double Feed drop-down menu.

4. Select the image type (e.g., Text) in the Attribute drop-down menu as your image

type.

– Select Line Art to scan line art images (images in one color or in black-and-white,

such as logos or mechanical blueprints).

– Select Photo to scan color prints.

– Select Text to scan text.

5. If necessary, adjust image quality by using the image correction tools.

Scan frame

(enclosed by dotted

lines and labeled with

the tag “Main”)

Preview window

Preview image (the

enclosed frame

bordered in red)

Toolbar


correction

settings

Image type

Scanning

settings

Scan a Stack of Documents (cont.)

6. Click the Scan button, or click the Custom Scan button and select “Save to File” to

start multiple-sheet, automatic scanning.

NOTE: When you finish loading documents on the

Document Feed Tray, the documents remain on the tray.

When scanning is initiated, the stack of papers is moved

automatically from the Automatic Moving Tray in

preparation of the scanning process.

• If ScanWizard DI is launched from an image-editing program, the scanned image is

delivered after the scan to your application, where the image can be saved,

printed, or modified further.

• If ScanWizard DI is launched as a stand-alone program, the scanned image can be

saved after the scan to a file or opened in an image-editing program.

Alternatively, click the Quick Scan button to scan your documents directly to a PDF.

NOTE: For details on other scanning scenarios applicable to the scanner, refer to the ArtixScan DI

4020 Plus/ArtixScan DI 2020 Plus User’s Manual.

It appears only when ScanWizard DI

is launched as stand-alone program

Fixing Paper Jams

Open the ADF cover by pressing the button

on the top of the ADF.

Paper jams can occur in either of two

places: Directly under the ADF cover, or

under the Document Feed Tray.

ADF cover

Button

• If a paper jam has occurred in the

rollers under the ADF cover, pull out

the paper by using a forward-moving

direction.

ADF Cover

Document Feed Tray

• If a paper jam has occurred in the

rollers directly under the Document

Feed Tray, lift the Document Feed Tray,

then pull out the paper by using

a forward or backward motion until the

paper has been pulled free.

Problems?

The LEDs on the button panel indicates the status of the scanner.

First, make sure that you have followed Steps 1 to 4 as described in this document

(unpack, install, unlock, connect). Then if your problem is listed here, try the suggested

solution.

1. No light comes on when the scanner is turned on.

Make sure your scanner is connected to your computer and plugged into a power

source.

2. The Add/Remove Hardware Wizard appears on your screen.

Click the “Cancel” button and close the Control Panel. Disconnect the Hi-Speed USB

cable from the back of your computer, and refer to the installation instructions in this

document or the ArtixScan DI 4020 Plus/ArtixScan DI 2020 Plus User’s Manual.

3. When trying to scan, an error message appears on your screen that reads, “Can’t Find

Scanners”.

Make sure your scanner is unlocked (see Step 3).

Make sure your scanner is connected to your computer and plugged in to a power

source (see Step 4).

Uninstall and reinstall the ScanWizard DI software.

4. After clicking scan, a blank screen appears.

Make sure your scanner is unlocked (see Step 3).

Uninstall and reinstall the ScanWizard DI software.

5. When trying to scan with the ADF (Auto Document Feeder) , an error message

appears on your screen that reads, “Code -206, ADF paper jam or roller failure.”

Click OK first; then open the ADF cover, as illustrated in the “Fixing Paper Jams”

section of this document.

• If the problem is occurring from a paper jam, follow the procedures laid out in the

“Fixing Paper Jams” section of this document.

• If the problem is occurring from situations other than a paper jam, follow the

procedures laid out in the “Position a Stack of Documents” section.

Finally, close the ADF cover and restart scanning.

LEDs

On - Ready to scan

Flashing Green - Scanning

Off - Scanner is off

Do You Need Assistance?

Manuals

If you have additional questions and need further instruction or information, we provide

electronic manuals for:

1. Using your ArtixScan DI 4020 Plus/ArtixScan DI 2020 Plus

2. Using the ScanWizard DI scanning software

3. Using the bundled third-party software

To access the electronic manuals: Insert the scanner’s software CD/DVD into your

computer’s CD/DVD-ROM drive. Next, locate and click the “Manuals” option when the

software installer window appears on your screen. Finally, select and click the title of the

manual you wish to view.

Missing Items

If your package is missing items, please call the Microtek Customer Service Department.

Drivers & Software Upgrades

After you finish the installation of software, if you found that the installed drivers and

software cannot run your product or your computer system properly later, please go to

the Microtek Download Service site at ww7.microtek.com.tw/service.php to download

and install any updates you may require.

For additional information about Microtek products, please visit our website at

www.microtek.com.

ColoRescue are trademarks or registered trademarks of Microtek International,

Inc. All other trademarks or registered trademarks are the property of their

respective holders. Specifications, software and hardware bundles are subject

to change without notice. Delivery of technical support services subject to

change without notice. Not responsible for typographical errors.

Power Adapter

Use only power supplies (AC/DC adapters) listed below:

Voltage Manufacturer Model No.

100V to 240V HARD HDAD38W101

NOTE: Please make sure that the electrical outlet to where the scanner will be

connected is nearby and readily accessible.

Otros manuales para ArtixScanDI 4020 Plus

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Escáner de Microtek

Microtek

Microtek ScanMaker 3800 Manual de usuario

Microtek

Microtek ArtixScan DI 2020 Manual de usuario

Microtek

Microtek ArtixScan DI 3130c Manual de instrucciones

Microtek

Microtek ObjectScan 1600 Manual de usuario

Microtek

Microtek XT3500 Manual de usuario

Microtek

Microtek ScanMaker s430 Manual de instrucciones

Microtek

Microtek ObjectScan 1600 Manual de usuario

Microtek

Microtek ScanMaker V6UPL Manual de usuario

Microtek

Microtek LS-3700 Manual de usuario

Microtek

Microtek ScanMaker s380 Manual de instrucciones

Microtek

Microtek ScanMaker i800 Manual de usuario

Microtek

Microtek ScanMaker 1000XL Plus Manual de instrucciones

Microtek

Microtek ScanMaker 4600 Manual de usuario

Microtek

Microtek ScanMaker 6000 Manual de usuario

Microtek

Microtek ArtixScanDI 7200S Manual de usuario

Microtek

Microtek ArtixScanDI 2015c Manual de usuario

Microtek

Microtek ArtixScanDI 6240S Manual de usuario

Microtek

Microtek ArtixScan 120tf Manual de usuario

Microtek

Microtek ArtixScanDI 5240 Manual de usuario

Microtek

Microtek ArtixScanDI 3130c Manual de usuario

Microtek

Microtek Bio-5000 Plus Manual del propietario

Microtek

Microtek ScanMaker 1000XL Manual de instrucciones

Microtek

Microtek ScanMaker 4 Manual de usuario

Microtek

Microtek ScanMaker 3700 Manual de usuario

Manuales populares de Escáner de otras marcas

Plustek

Plustek Scanner Manual de usuario

Z/I Imaging

Z/I Imaging PhotoScan 2001 Manual de usuario

Renkforce

Renkforce DS100-5M Manual de usuario

Image Access

Image Access WideTEK A2 Manual de usuario

Canon

Canon imageFORMULA CR-120N Manual de usuario

Fujitsu

Fujitsu FI-4860C2 Manual de usuario

GeoSlam

GeoSlam ZEB Horizon Instrucciones de instalación

Kodak

Kodak i5800 Scanner Manual de usuario

Kodak

Kodak i7300 Manual de usuario

Revopoint

Revopoint POP Manual de usuario

Fujitsu

Fujitsu fi-4860C Manual de usuario

Eddyfi Technologies

Eddyfi Technologies Floormap X Manual de usuario

Faselase

Faselase F6 Manual de usuario

Fujitsu

Fujitsu CardMinder Manual de usuario

Uniden

Uniden BC340CRS Manual de usuario

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Manual de usuario

Mustek

Mustek PageExpress 4800 Pro Manual de usuario

Optex

Optex 750830 Manual de usuario
