INSTALLATION INSTR CTIONS FOR PART 99-8903B

APPLICATIONS

S BAR

LEGACY & O TBACK

2010-11

(FOR NON-NAVIGATION RADIOS ONLY)

KIT FEATURES

• DIN ra io provision with pocket

• ISO ra io provision with pocket

• Painte scratch resistant matte black

A) Ra io Housing B) ISO Brackets C) Trim plate

KIT COMPONENTS

TOOLS REQUIRED:

• Small Flat Bla e Screw river • Phillips Screw river

• Panel Removal Tool • Socket Wrench

1-800-221-0932

www.me raonline.com

99-8903B

METRA. THE WORLD’S BEST KITS.™

WIRING AND ANTENNA CONNECTIONS (Sold Separately)

Wirin Harness:

• 70-8901 Subaru Harness 1990-Up

• 70-7552 Nissan Harness 2007-Up

Antenna Adapter:

• 40-SB10 Subaru Antenna Adapter 2005-Up

Da h Di a embly

- 2010-11 Subaru Legacy . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . .

- 2010-11 Subaru Outback . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . .

Kit A embly

- DIN Head Unit Provi ion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

- ISO DIN Head Unit Provi ion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

TABLE OF CONTENTS

99-8903B

*Note:

Refer also to the instructions included with the aftermarket radio.

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP certified

technicians.

99-8903B DASH DISASSEMBLY

2010-11 S BAR LEGACY / O TBACK

Disconnect the negative battery ter-

minal to prevent an acci ental short

circuit.

Unclip an remove the ra io trim panel

inclu ing the a/c vents. (

Figure A)

Remove (4) Phillips screws securing

the factory ra io.

99-8903B KIT ASSEMBLY

Locate the factory wiring harness in

the ash. Metra recommen s using

the proper mating a apter from Metra

or AXXESS. Re-connect the negative

battery terminal an test the unit for

proper operation.

Sli e the DIN cage into the Ra io

Housing an secure by ben ing the

metal locking tabs own. (Figure A)

Sli e the aftermarket hea unit into

the cage an secure. (Figure B)

Reassemble ash in reverse or er of

isassembly.

2010-11 S BAR LEGACY / O TBACK

DIN HEAD NIT PROVISION

99-8903B KIT ASSEMBLY

Locate the factory wiring harness in

the ash. Metra recommen s using

the proper mating a apter from Metra

or AXXESS. Re-connect the negative

battery terminal an test the unit for

proper operation.

Mount the ISO Brackets to the hea

unit with the screws supplie with

the unit. (Figure A)

Sli e the hea unit into the ra io

opening until the si e clips engage.

(Figure B)

Snap the Trim plate into the Ra io

Housing. (Figure B)

Reassemble ash in reverse or er of

isassembly.

2010-11 S BAR LEGACY / O TBACK

ISO DIN HEAD NIT PROVISION

NOTES

99-8903B

NOTES

99-8903B

306

INSTR CTIONS

1-800-221-0932

www.me raonline.com

99-8903B INSTR CTIONS

METRA. THE WORLD’S BEST KITS.™
