Marshall M-CT7 Camera-Top Monitor Owner’s Manual

M-CT7

Camera-Top Monitor

Owner’s Manual

Marshall M-CT7 Camera-Top Monitor Owner’s Manual

Thank you for purchasing a Marshall M-CT7 camera-top monitor. The

M-CT7 is a great tool for focusing, composing, and viewing images/video

clips directly from your digital camera/video camera. It is conveniently sized

for easy transportation, and it is perfect for difﬁcult shooting situations.

To obtain the best results with your new M-CT7, please take the time to

read this manual.

CAUTION

• Please use the supplied power sources.

• Do not expose this product to excessive heat or humidity.

• Avoid subjecting the unit to physical shock wherever possible.

• Do not use chemical solutions to clean this unit. Simply wipe with a

clean soft cloth to remove ﬁngerprints or smudges.

Marshall M-CT7 Camera-Top Monitor Owner’s Manual

CONTENTS

PRODUCT OVERVIEW .....................3-4

MONITOR.............................3

REMOTE CONTROL ......................4

CABLES..............................4

MENU OPERATION ...................... 5-8

SPECIFICATIONS..........................9

INCLUDED ACCESSORIES .................. 10

TROUBLESHOOTING ...................... 10

BATTERY COMPATIBILITY .................. 11

MONITOR

1. Volume UP/DOWN / Adjust value of setting function

2. Activate OSD menu

3. Selection key / adjust phase directly

4. Selection key / adjust the brightness directly

5. Input selection switch

6. Power ON/OFF

7. Indicator light

8. Infrared receiving window

9. 3.5mm AV input jack

10. VGA input jack

11. HDMI input jack

12. Power input jack

1 2 5 6 7 83 4

Marshall M-CT7 Camera-Top Monitor Owner’s Manual

REMOTE CONTROL

CABLES

HDMI cable

mini HDMI-to-HDMI

AV Cable

MUTE

Power ON / OFF

Activate OSD menu

Volume UP / adjust value of setting function

Volume DOWN / adjust value of setting function

Selection key / adjust brightness directly

Selection key / adjust phase directly

Aspect ratio switch (4:3/16:9)

UP / DOWN

LEFT / RIGHT

Input Selection

1. Yellow RCA jack for VIDEO 1 input

2. White RCA jack for AUDIO input

3. Yellow RCA jack for VIDEO 2 input

Marshall M-CT7 Camera-Top Monitor Owner’s Manual

MENU OPERATION

After connecting power, the unit will be in standby mode, which is indicated

by a red light. Press "POWER"on the unit or on the remote control, and

the buttons on the unit will illuminate in blue when the unit is operational.

Pressing the same button again will return the unit to STANDBY mode.

Push "PC/AV"on the unit or the remote control to select the signal input.

OSD in HDMI / PC Mode

OSD in AV Mode

You can press or on the unit or on the remote control to select the

items: COLOR ADJUST MENU FUNCTION SOUND

and conﬁrm by pressing on the unit or on the remote control, then

push again to adjust the items. Push to exit the OSD after your

adjustments are complete.

Marshall M-CT7 Camera-Top Monitor Owner’s Manual

Color temperature within the OSD is adjustable also. Press on the

unit or on the remote controller to select "Color Temp,"then choose to set

color temperature to: 9300 K, 6500 K, or USER or by pressing .

RED, GREEN and BLUE may then be adjusted with to obtain any

custom settings you may require.

Note: when you select “USER,” a mini box will appear in the right bottom corner of

the OSD (

as pictured above

After selecting "Color"mode on the OSD, use to select and then

push to adjust.

1. Brightness: adjusts the brightness of the image

2. Contrast: adjusts the contrast of image

3. Color Temp: adjusts the color temperature of the image

4. Custom Color Adjustment mode

COLOR (HDMI / PC MODE)

Marshall M-CT7 Camera-Top Monitor Owner’s Manual

ADJUST (PC MODE)

OSD (ALL MODES)

1. Auto Conﬁg: adjusts settings automatically

2. H Position: adjusts the picture horizontally

3. V Position: adjusts the picture vertically

4. Phase: adjusts the phase

5. Clock: adjusts the clock, make ﬁeld, and line synchronization

1. Language: sets the displayed language

2. H Position: adjusts the OSD window horizontally

3. V Position: adjusts the OSD window vertically

4. OSD Timeout: adjusts the timeout for the OSD shut-off

5. Transparent: switches between a translucent and opaque OSD

Language window

Marshall M-CT7 Camera-Top Monitor Owner’s Manual

FUNCTION (ALL MODES)

SOUND (ALL MODES)

1. Reset: resets the monitor to the original factory settings

2. Zoom: changes the aspect ration from 4:3 to 16:9 (4:3 is default)

3. LR: ﬂip image horizontally (Mirror image)

4. UD: ﬂip image vertically (up / down)

1. Volume: adjusts the monitor volume

Marshall M-CT7 Camera-Top Monitor Owner’s Manual

SPECIFICATIONS

Display Panel 7-inch TFT LCD (1,152,000 pixels)

Resolution 800x480 (VGA)

Upscaled Resolution 1920x1440 (VGA)

Brightness 400 cd/m2

Contrast 500:1

Viewing Angles 75°/75° (Left/Right) 50°/70° (Up/Down)

Video Signal Input 0.7 ~ 1.4Vp-p / 75Ω

VGA Signal Input Horizontal: 30~60KHz Vertical: 60~75Hz

Speaker ≥2.5W/8Ω

Color System NTSC: 3.58 / PAL: 4.43

Voltage DC: 12V ± 10﹪

Signal Inputs PC (VGA), AV1, AV2

Power Consumption ≤8w

Working Temperature -10 -75°C

Store Temperature -30-75°C

Size 182mm (L) x 127mm (W) x 32mm (H)

Weight 14 oz. (without battery)

Marshall M-CT7 Camera-Top Monitor Owner’s Manual

10|

INCLUDED ACCESSORIES

TROUBLESHOOTING

• Power AC adapter

• Car power adapter

• AV cable

• HDMI-to-HDMI cable

• Mini HDMI-to-HDMI cable

• Remote control

• Camera mount

• Battery

• Battery charger

• Operation manual

• Soft pouch

Image is only showing black and white:

Make sure the level of color saturation and brightness is correct.

The power is on but there is no picture:

Make sure the AV or VGA cable is tightly connected from the video out

connector or VGA signal output connector. Make sure you are using the

standard power adapter supplied with the monitor.

The colors are incorrect or abnormal:

If any color is missing, check the cables to make sure they are securely

connected. Broken or loose pins in the cable connector can cause a

bad connection.

The remote control does not work:

Check the battery to make sure the battery is installed properly.

If you are still experiencing problems, contact Marshall Electronics

technical support at:

(800) 800-6608 or +1 (310) 333-0606
