Lorex SG4230 Manual de usuario

2.4 GHz Black & White Video Security System with 1 Camera

QUICK SET UP GUIDE

1. Unpack the system contents from the gift box

(a) Mount the camera to a wall or desktop using the supplied

mounting bracket, screws and anchors

(b) Connect power to the camera using the 9V DC 500mA

adapter (or use the optional 4 “AA” batteries*, not included)

(c) Turn the camera “ON”

*Note: The battery power will last 7-8 hours. This option is

only intended for use in the event of a power failure.

3. Set up the monitor

4. Adjust for Optimum Clarity

Camera

Mounting

Bracket Screws & Anchors

9V DC Power Adapter

(for camera) Monitor

(a) Place the monitor in the desired viewing location

(b) Connect power to the monitor using the 13.8V DC 1000mA

adapter

(c) Turn the monitor “ON” (the Power switch is located on the

right side of monitor)

Now that both the camera and monitor are powered and

turned “ON”, you should be seeing the image from the

camera.

Adjust the antenna to ensure clear picture reception. If

there’s still interference, then change the channel on both

the camera and monitor between 1-4. The camera and

monitor must be set to the same channel.

2. Connect the Wireless Video Camera

FOR MORE INFORMATION

www.strategicvista.com

Antenna

RCA Cable

13.8V DC Power Adapter

(for monitor)
