Lorex LW1012 Series Manual de usuario

BUSINESS AND HOME SECURITY

COLOR WIRELESS SURVEILLANCE SYSTEM

WITH 2 INDOOR/OUTDOOR NIGHT VISION CAMERAS

‘EWT’ Eliminates Interference From Most Household Devices

Fast & Easy Installation - Plug Into any AC Outlet

Receiver Connects to any TV/VCR/DVD Recorder

Indoor / Outdoor Night Vision Camera

Built-in Microphone for Listening Ability

Camera Can be Battery Operated for True Portable Wireless Operation

Up to 300ft Wireless Transmission Range*

Night Vision Allows for Low Light Viewing up to 23ft (7m) from Cameras**

Receiver Automatically Switches View Between Cameras

Desktop, Wall and Ceiling Mountable

FEATURES

www.lorexcctv.com

LW1012 Series

*Maximum open space transmission range. Actual range dependent upon building materials and other obstructions in

path of wireless signal.

**IR illumination range of 23ft (7m) under ideal conditions. Objects at or beyond this range may be partially or completely

obscured, depending on the camera application.

This product broadcasts over public airways and its video and audio signals may be intercepted without your consent.

CONNECTS TO ANY TV

BUSINESS AND HOME SECURITY

COLOR WIRELESS SURVEILLANCE SYSTEM

WITH 2 INDOOR/OUTDOOR NIGHT VISION CAMERAS

As our product is subject to continuous improvement, Lorex Technology & subsidiaries reserve

the right to modify product design, specifications & prices without notice and without incurring

any obligation. E&OE

3700 Koppers Street

Baltimore, Maryland 21227,

USA.

Lorex Technology Inc.

300 Alden Road, Markham,

Ontario L3R 4C1

Canada. 2-18062008

PRODUCT INFORMATION

UPC: LW1012 - 7-78597-10120-1

LW1012F - 7-78597-10121-8

Package Weight: 1.3kg / 2.8lbs

Package Dimensions: 298mm/11.73”(w) x

81mm/3.19”(d) x 235mm/9.25”(h)

Package Cube: 0.005cbm / 0.20cft

LW1012/LW1012F 1 x Wireless Receiver

2 x Wireless Camera

3 x 9V DC Power Adapters

1 x RCA Video Output Cable

2 x Camera Battery Adapter Cable

CONTENTS

SPECIFICATIONS

Imaging Sensor: 1/3” CMOS

CMOS Total Pixels: 510 x 492 (NTSC)

View Angle: 62° Diagonal

Minimum Illumination: 3.0 Lux F1.5 (IR off) / 0 Lux (IR on)

Transmission Frequency: 910 MHz - CH1, 920 MHz - CH2 (2CH)

Transmission Power: 10 dBm

Modulation Type: FM

Bandwidth: 6.0 MHz

Power Source: + 9V (DC)

Unobstructed Effective Range: 330 ft. / 100 meters

Night Vision Range: Up to 26 ft. / 8 meters

Dimensions: 45x115x160mm / 1.8x4.6x6.3”

Weight: 0.3lbs / 140 g

Operating Temperature Range: 14° F ~ 104° F -10° C ~ 40° C

Receiving Frequency: 910-920 MHz - 2CH

Intermediate Frequency: 32 MHz

Demodulation Type: FM

Receiving Sensitivity: -85 dBm

Power Supply: 9V (DC)

Consumption Current: 180 mA

Unobstructed Effective Range: Up to 330 ft. / 100 m

Dimensions: 70x120x83mm / 2.8x4.7x3.3”

Weight: 0.3lbs / 120 g

Operating Temperature: 14 F to 104 F /- 10 C to 40 C

Operating Humidity: 85% RH

Camera

Receiver
