Lorex SG19LD80 Series Instrucciones de funcionamiento

19” LCD / 8 CHANNEL DVR

COMBO WITH 160GB HDD

& 4 CAMERAS

Troubleshooting the

Remote Control

MODEL:

SG19LD80 Series

www.lorexcctv.com

The Remote Has Stopped Working

The remote control has been working properly, however it has suddenly stopped functioning.

Outlined below are several techniques to help diagnose the problem:

1. Point your remote control at one of your cameras, and press and hold the RETURN button.

The camera is able to detect the Infrared signal from the Remote Control, and will display on the

Observation Screen as a flashing light.

If the remote control light does not FLASH onscreen, then the batteries in the Remote Control will

need to be replaced.

2. The remote control has the ability to control several Observation Systems at one time with the

push of a button. This is useful if you have several SG19LD800 Series systems installed at one

location - each system can be set to a different ID.

By default, the SG19LD800 Series Observation System is set to System ID #1. If the remote is

NOT set to control System ID #1, it will not function with the unit. To reset the remote control:

I. Confirm that the R is white on the bottom onscreen status bar. If the Ris blue, please proceed

to Step II.

II. Press the REMOTE ID button (see next page for Remote Control diagram). The status bar will

display a GEAR symbol indicating that the remote is in Program Mode.

III. Press the number 1 button on the remote control.

IV. Press the ENTER button on the remote control.

V. Press the RETURN button on the remote control.

For advanced setup of multiple systems, please refer to the Users’ Manual provided with your

product.

• Indicates the remote is active

with the System

• Indicates the remote is not

active with the System.

Remote Control

Listed below is a quick reference for the Remote Control.

CHANNEL BUTTONS -

Press to select a

specific camera by

number

RETURN BUTTON -

Returns to the previous

selection in Menu Mode.

Exits the Menu Setup

when in the Main Menu.

DISP BUTTON -

Changes the Screen

Mode to Single, Quad, 6

or 8 camera views.

SEQUENCE -

Turns camera

Sequence Mode ON/

OFF.

POWER BUTTON -

Turns the system power

ON/OFF

SETUP BUTTON -

Opens the Main Menu

(system setup)

ENTER BUTTON -

Applies a configuration

change in Menu Mode.

SEARCH BUTTON -

Enters the Search

Menu.

ZOOM -

Zooms in on the current


NAVIGATION AND

PLAYBACK -

Controls the playback of

video.

Navigates in MENU and

SEARCH mode.

Adjusts the zoomed

area in ZOOM mode.

NOTE: All Buttons described above function the same as the Front Panel buttons - see pages

10-13 of the Observation System Manual for detailed information. Buttons without descriptions do

not provide functionality to this unit.

REMOTE ID* -

Configure when using

multiple systems.*

* If the REMOTE ID button is set incorrectly, the remote will not function. To reset the

Remote ID (when using only one system), Press the ID button, and then select the number

1. Press ENTER to reset the remote, and press RETURN to exit the ID Screen.

AUDIO SELECT -

Press to select an audio

channel. Press the

Audio select button,

then a channel 1~4.

VOLUME +

VOLUME -

PTZ -

Controls PTZ Cameras

It’s all on the web

Product Information

User Manuals

Quick Start Guides

Specification Sheets

Software Upgrades

Firmware Upgrades

Lorex Technology Inc.

VISIT

www.lorexcctv.com
