Logitech G920 Driving Force Manual de usuario

G920 Driving Force Racing Wheel FAQs 1

G920 Driving Force Racing Wheel - Xbox

INDEX

GETTING STARTED

●User guide

○What’s in the box

○Installation

○Mounting clamps

○Buttons

○Connections and mount points

○Force feedback

○Pedal unit

SPECIFICATIONS

●Product information

●Product dimensions

●General product specifications

●Wheel specifications

●Pedal specifications

FAQs

●The force feedback on my wheel has changed and I can no longer use the center

spring force setting in G HUB to adjust the strength

G920 Driving Force Racing Wheel FAQs 2

●Why don't I feel the center spring on the steering wheel when I tab away or close a

game?

●Troubleshooting G920 for power/connection issues - Xbox

●How to set up your Logitech Wheel G923, G29, G920 on Assetto Corsa Competizione

●Troubleshoot G923/G29/G920 for connection Issues

●Racing Wheel Not Recognized For ACC – Xbox One – SOLUTION

●Device does not appear in G HUB

●G HUB freezes while loading and logo animation loops

●Audio device not recognized

●Create and scan for profiles with Logitech Gaming Software

○Scan for new games

○Create new profiles

●View current profiles in Logitech Gaming Software

●Digital signature error when Logitech Gaming Software is installed on Windows 7

computers

●Blue screen after G920 racing wheel is attached to USB port or G25/G27 is not

recognized

●Import racing wheel profiles using Logitech Gaming Software

○Scan for new games (Automatic)

○Import/Export (Manual)

●Set racing wheel profiles to Persistent or Default using Logitech Gaming Software

○Set a Default Profile

○Set a Persistent Profile

●View racing wheel profiles using Logitech Gaming Software

●G920 racing wheel does not respond when connected to Xbox One

●Create and edit racing wheel profiles using Logitech Gaming Software

○Create a new profile

○Edit an existing profile

○Delete a profile

●Program buttons on the G920 racing wheels with Logitech Gaming Software

○Default Button Layouts

○Customizing Buttons

○Game-Specific Profile Commands

○Command Editor

○Resetting Buttons

●Pedals on the G920 racing wheel do not respond

G920 Driving Force Racing Wheel FAQs 3

●Lock racing wheel profile using Logitech Gaming Software

●Mounting templates for the G920 racing wheel

●Mount and secure the G920 racing wheel using the clamping system

○Wheel Unit

○Pedal Unit

○Cable Management

●Adjust sensitivity on the G920 racing wheels with Logitech Gaming Software

○Steering Sensitivity

○Wheel Operating Range

○Pedal Sensitivity

●Clutch pedal on the G920 racing wheel does not function properly

●Force feedback turns off intermittently on G920 racing wheel

●No force feedback when using the G920 racing wheel on a PC

●Supported gaming console systems for the G920 racing wheel

●Mount and secure the G920 racing wheel using built-in bolt mounting points

○Wheel Unit

○Pedal Unit

○Cable Management

●Supported PC operating systems for the G920 racing wheels

●Optimize pedal face positions on the G920 racing wheel

●Logitech G HUB - FAQs

○About Logitech G Hub

WARRANTY

●Hardware warranty

●Logitech Support

DOWNLOAD

●G Hub

G920 Driving Force Racing Wheel FAQs 4

GETTING STARTED

USER GUIDE

What’s in the box

1. Racing wheel

2. Pedal unit

3. Power adapter

4. User documentation

Installation

Attach power adapter and USB cables as shown.

Every time your Racing Wheel connects with your system, it will rotate fully to each

side and then to the center to calibrate. Your wheel will be ready once this calibration

is completed.

G920 Driving Force Racing Wheel FAQs 5

Mounting clamps

G920 Driving Force Racing Wheel is

equipped with a built in clamping

system for mounting to a table.

Push down and rotate clamp knobs

to lock or unlock.

Rotate clamp knobs to tighten or

loosen clamps.

NOTE: Clamp extenders should be removed

for attachment to thicker tables.

G920 Driving Force Racing Wheel FAQs 6

Buttons

1. Left bumper

2. Directional pad

3. View button

4. Left stick button

5. Right bumper

6. A, B, X, Y buttons

7. Menu button

8. Right stick button

9. Xbox button

Connections and mount points

1. Mounting clamps

2. Cable management cleat

3. Optional shifter connection

(DB-9 male)

4. USB cable

5. Pedal unit connection (DB-9

female)

6. Power connection

7. Bolt mounting points (uses

M6X1 bolts)

G920 Driving Force Racing Wheel FAQs 7

Optimal cable routing

USB and pedal cables (1, 2) should be

routed through inner channels.

Power and optional shifter cables (3, 4)

should be routed through outer channels.

Cables may be wrapped multiple times

around cable management cleat to take

in slack.

Force feedback

Your Racing Wheel contains dual motors that will provide force feedback with supported

games and systems.

Note: Your racing wheel has an overheat protection circuit safeguard to protect it

under high-temperature operating conditions. In rare instances, force feedback

features may shut down during use while controls continue to operate. If this occurs,

allow the wheel to cool down and power it down by unplugging it. If this occurs frequently,

contact product support.

G920 Driving Force Racing Wheel FAQs 8

Pedal unit

1. Clutch pedal

2. Brake pedal

3. Throttle pedal

4. Textured heel rest

5. Bolt mounting points (uses M6X1

bolts)

6. Patented carpet grip system

7. Carpet grip release clip

Push towards rear or pedal unit

to release

8. Change pedal face position

(requires 2.5mm hex key)

G920 Driving Force Racing Wheel FAQs 9

SPECIFICATIONS

Product Information

Component

Model Number (M/N)

Location

Wheel

W-U0002

Under wheel base

Product Dimensions

Component

Height

Width

Depth

Weight

Wheel

270 mm

(10.63 in)

10.94 mm

(278 in)

260 mm

(10.24 in)

2.25 kg

(4.96 lb)

Pedals

167 mm

(6.57 in)

311 mm

(12.24 in)

428.5 mm

(16.87 in)

3.10 kg

(6.83 lb)

General Product Specifications

Software Support

(at release)

Logitech Gaming Software

OS/Platform Support

(at release)

Windows 7, Windows 8, Windows 8.1, Windows 10

Xbox One

Apps Available

(at release)

N/A

System

Requirements

• Xbox One and games that support Logitech® force feedback

racing wheel.

G920 Driving Force Racing Wheel FAQs 10

System

Requirements

• Windows 10, Windows 8, 8.1, or Windows 7, 150 MB of available

hard disk space, USB port, games that support Logitech® force

feedback racing wheel.

Wheel Specifications

Connection Type

USB (corded)

USB VID_PID

VID_046D&PID_C262 (PC Mode)

USB Protocol

USB 2.0

USB Speed

Full-speed

Indicator Lights (LED)

Power/Status

Wheel Rotation

900 degrees (Max)

AC Adapter

24V 1.75A, Auto Switching

Special Buttons

Directional Pad

X, Y, A, B

LB / RB (Paddles)

LSB / RSB

Xbox

View

Other Features

Dual-motor force feedback;

helical gearing

Cable Length (USB)

6 ft (1.8 m)
