Logitech G920 Driving Force Manual de usuario

Logitech® G920 Driving Force™ Racing Wheel

User Guide

Guide de l’utilisateur

Logitech® G920 Driving Force™

Contents

English. . . . . . . . . . . . . . . . . . 3

Français . . . . . . . . . . . . . . . . .11

Español . . . . . . . . . . . . . . . . 19

Português . . . . . . . . . . . . . . 27

www.logitech.com/support/g920

Logitech® G920 Driving Force™

3 English

What’s in the box

1. Racing wheel

2. Pedal unit

3. Power adapter

4. User documentation

USB

G920 Driving Force™ Racing Wheel

G920 Driving Force™ Volant de Course

1 2

620-006532.002

www.logitech.com/support/g920

PDF

1 2

3 4

Logitech® G920 Driving Force™

4 English

Installation

Attach power adapter and USB cables as shown.

Every time your Racing Wheel connects with your system, it will rotate fully to each

side and then to the center to calibrate. Your wheel will be ready once this calibration

is completed.

USB

Logitech® G920 Driving Force™

5 English

Mounting clamps

G920 Driving Force Racing Wheel

is equipped with a bult in clamping system

for mounting to a table.

Push down and rotate clamp knobs

to lock or unlock.

Rotate clamp knobs to tighten

or loosen clamps.

Note: Clamp extenders should be removed

for attachment to thicker tables.

Logitech® G920 Driving Force™

6 English

Buttons

1. Left bumper

2. Directional pad

3. View button

4. Left stick button

5. Right bumper

6. A, B, X, Y buttons

7. Menu button

8. Right stick button

9. Xbox button

Logitech® G920 Driving Force™

7 English

Connections and mount points

1. Mounting clamps

2. Cable management cleat

3. Optional shifter connection (DB-9 male)

4. USB cable

5. Pedal unit connection (DB-9 female)

6. Power connection

7. Bolt mounting points (uses M6X1 bolts)

Optimal cable routing

USB and pedal cables (1, 2) should be

routed through inner channels.

Power and optional shifter cables (3, 4)

should be routed through outer channels.

Cables may be wrapped multiple times

around cable management cleat to take

in slack.

14 2 3

Logitech® G920 Driving Force™

8 English

Force feedback

Your Racing Wheel contains dual motors that will provide force feedback with supported

games and systems.

Note: Your racing wheel has an overheat protection circuit safeguard to protect it

under high-temperature operating conditions. In rare instances, force feedback

features may shut down during use while controls continue to operate. If this occurs,

allow the wheel to cool down and power it down by unplugging it. If this occurs frequently,

contact product support.

Logitech® G920 Driving Force™

9 English

Pedal unit

1 2 3 1. Clutch pedal

2. Brake pedal

3. Throttle pedal

4. Textured heel rest

5. Bolt mounting points (uses M6X1 bolts)

6. Patented carpet grip system

7. Carpet grip release clip

Push towards rear or pedal unit

to release

8. Change pedal face position

(requires 2.5mm hex key)

Logitech® G920 Driving Force™

10 English

TouchSense Technology

TouchSense Technology licensed from Immersion Corporation and protected

by one or more of the following United States Patents listed at

http://www.immersion.com/haptics-technology/patent-marking/index.html
