Logitech® Speaker System Z240

Setup Guide

Logitech Speaker System Z240

Contents

English. . . . . . . . . . . . . . . . . . 3

По-русски . . . . . . . . . . . . . . . . . 8

Українська . . . . . . . . . . . . . . . 13

www.logitech.com/support . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Logitech Speaker System Z240

English 3

Package contents

1. Left satellite speaker

2. Right satellite speaker

3. 3.5mm audio cable

4. AC power cable

5. Documentation

3 5

Logitech® Speaker System Z240

Setup Guide

Logitech Speaker System Z240

4 English

Know your product

Satellites (front)

1. System volume

2. Power LED

Satellites (back)

3. Audio 3.5mm input

4. AC input

23 4

Logitech Speaker System Z240

English 5

Setup your product

1. Switch power on:

• Connect AC power into an AC outlet

2. Connect audio source:

• For smartphones, tablets,

music players and PCs:

Use 3.5mm cable (included).

Logitech Speaker System Z240

6 English

Visit Product Central

There’s more information and support

online for your product. Take a moment

to visit Product Central to learn more about

your new Logitech speaker system.

Browse online articles for setup help,

usage tips, or information about additional

features.

Connect with other users in our Community

Forums to get advice, ask questions,

and share solutions.

At Product Central, you’ll ﬁnd a wide

selection of content:

• Tutorials

• Troubleshooting

• Support community

• Software downloads

• Online documentation

• Warranty information

• Spare parts (when available)

Go to www.logitech.com/support/Z240

Use your product

Power on and volume

Rotate the volume knob on right satellite

until you hear a “click”. The green power

LED will be lit.

Further rotate the volume knob right or left

to adjust the volume to your desired level.

Logitech Speaker System Z240

English 7

Troubleshooting

One or both speakers produce little

or no sound?

• Check power connection to the right

speaker. Try a dierent AC outlet.

Rotate the speaker volume knob to

the 12 o’clock position.

• Check the speaker cable connection with

your computer the speaker cable must

be plugged into the line-level, speaker,

or headphone output jack.

• Check volume and balance controls in

your media application and computer’s

operating system.

• Quit your media application, and then

restart it.

• Connect the speakers to another audio

source (e.g., MP3 player). If they work,

your computer’s soundcard may be

the cause of the problem.

Checking operating system volume/

balance controls

• Windows® Vista and Windows® 7:

Go Start/Control Panel/Sounds/Playback

Devices tab. Select your soundcard

as the sound playback device. Verify that

the Speaker Icon is not muted.

• Windows® 8: From Start Menu,

select Desktop tile. From Charms menu,

select Settings/Control Panel/Hardware

and Sound/Sound/Playback devices

tab. Select your soundcard as the sound

playback device. Verify that the Speaker

Icon is not muted.

• Mac OS® X: Open System Preferences

and select Sound/Output tab.

Select your soundcard as the sound

output device and adjust the Output

Volume slider. Verify that the Mute box

is not checked.

For more troubleshooting help,

go to www.logitech.com/support/Z240

Logitech Speaker System Z240

8 По-русски

Комплект поставки

1. Левая вспомогательная колонка

2. Правая вспомогательная колонка

3. Аудиокабель с разъемом 3,5 мм

4. Кабель питания от сети

переменного тока

5. Документация

3 5

Logitech® Speaker System Z240

Setup Guide

Logitech Speaker System Z240

По-русски 9

Знакомство с продуктом

Колонки (спереди)

1. Регулятор громкости

2. Светодиодный индикатор питания

Колонки (сзади)

3. Аудиовход, 3,5 мм

4. Вход для подключения сетевого

блока питания

23 4

Logitech Speaker System Z240

10 По-русски

Установка продукта

1. Включение питания:

• Подключите кабель питания

к электрической розетке.

2. Подключите источник аудиосигнала.

• Для смартфонов, планшетов,

проигрывателей музыки и ПК:

используйте кабель с разъемом 3,5 мм

(входит в комплект поставки).
