Jack-It™

Aftermarket Manual

www.lippertcomponents.com (574) 537-8900 Rev: 02.17 - Jack-It™ Aftermarket Manual

Jack-It™

Aftermarket

Manual

Table Of Contents

Introduction � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 1

Safety Requirements � � � � � � � � � � � � � � � � � � � � � � � � � � � � 1

Resources Required � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2

Installation Instructions � � � � � � � � � � � � � � � � � � � � � � � � � 2

Securing Bikes � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4

Patent protected, trademarked, and produced by Let’s Go Aero, Inc.

Corporate Ofce: 4474 Barnes Road, Colorado Springs, CO 80917 USA.

Made in China.

US Patent Numbers: 8,899,456, D717,716, D717,717, D684,917, D722,289,

patents pending.

Introduction

The Jack-IT™ is a bicycle rack designed to attach to your RV.

Additional information about this product can be obtained from

www.lci1.com/support or by downloading the free myLCI app.

The app is available on iTunes® for iPhone® and iPad® and

also on Google Play™ for Android™ users.

iTunes, iPhone, and iPad are registered trademarks of Apple

Inc. Google Play and Android are trademarks of Google Inc.

Lippert Components, Inc. recommends that the following

inspections, troubleshooting, component replacement and

verications be completed only by certied RV technicians.

Safety Requirements

Failure to follow the instructions provided in this

manual may result in death, serious injury, vehicle

damage or voiding of the component warranty�

Moving parts can pinch, crush or cut� Keep clear and

use caution�

The use of this product while bicycles are loaded may

affect the turning radius on some vehicles� Check the

turning radius before travel�

Jack- It™

Aftermarket Manual

www.lippertcomponents.com (574) 537-8900 Rev: 02.17 - Jack-It™ Aftermarket Manual

Resources Required

9/16” Socket Wrench

3/4” Socket Wrench

Installation Instructions

1� Remove the tongue jack from the coupler. Position the

PowerTower™ (Fig�1G) on the coupler. Place the

tongue jack on the PowerTower (Fig�1G) and secure

both to the coupler using 3 nuts, bolts and washers each

(Fig�1H, 1I and 1J).

Note: If there is no tongue jack, attach the PowerTower

(Fig�1G) to the coupler on the front of the trailer using 3

nuts, bolts and washers each (Fig�1H, 1I and 1J).

2� Attach the stinger (Fig�1F) to the PowerTower

(Fig�1G) using the NoMotion™ pin and washers

(Fig� 1C, 1D and 1A). For safety, insert the cotter pin

(Fig�1B) through the hole at the end of the NoMotion pin

(Fig�1C) after tightening securely.

3� Attach the base (Fig�1E) to stinger (Fig�1F) using the

NoMotion pin and washers (Fig�1C, 1D and 1A). For

safety, insert the cotter pin (Fig�1B) through the hole at the

end of the NoMotion pin (Fig�1C) after tightening securely.

Fig�1

Jack- It™

Aftermarket Manual

www.lippertcomponents.com (574) 537-8900 Rev: 02.17 - Jack-It™ Aftermarket Manual

Note: Several hole positions are provided for

cradles (Fig�2A). Pads (Fig�2D) and

SwayStop™ pins (Fig�2F) slide along the

length of the wings (Fig�2G).

4� Slide one SwayStop pin (Fig�2F) onto each

wing (Fig�2G) from the bottom so that the

SwayStop locates between the snap pin

(Fig�2H) and the pad (Fig�2D).

Note: A 2nd and optional SwayStop pin is

provided to secure both wheels of the bike to

the rack, install at this time if desired.

Note: If not using the 2nd and optional

SwayStop pins then the SwayStop pins

(Fig�2F) should point in opposite directions.

5� Attach wings (Fig�2G) to base (Fig�2E)

using 2 snap pins (Fig�2H).

6� Install 6 rubber straps (Fig�2B): 1 onto

each cradle (Fig�2A) and 1 onto each

SwayStop pin (Fig�2F).

7� Attach 4 cradles (Fig�2A). Attach 2 to each

wing (Fig�2G), securing with cotter pins

(Fig�2C). Attach 1 on each wing facing the

tow vehicle and 1 on each wing facing the

trailer.

Note: Adjustment will be necessary depending

on the size and desired position of the

bicycles.

C D E

Fig�2

Jack- It™

Aftermarket Manual

www.lippertcomponents.com (574) 537-8900 Rev: 02.17 - Jack-It™ Aftermarket Manual

Manual information may be distributed as a complete

document only, unless Lippert Components provides explicit

consent to distribute individual parts.

All manual information is subject to change without notice.

Revised editions will be available for free download at www.

lippertcomponents.com. Manual information is considered

factual until made obsolete by a revised version.

Please recycle all obsolete materials and contact Lippert

Components with concerns or questions.

NotesSecuring Bikes

1� For 2 bicycles, the best technique is to position the bicycles

front to back/back to front with the chain ring to the outside.

2� Hang 1 bicycle on the tow vehicle side of the bicycle rack, so

the top of the wheels are each supported by a cradle.

3� Secure by tensioning each rubber strap over the top of each

tire and engaging a strap hole with the end of the cradle.

4� Use 1 SwayStop pin to secure at least 1 wheel below the

frame where the wheel crosses the wing using the same

technique with the stop pin rubber strap (Fig�3). A second

and optional SwayStop pin is provided to secure both wheels

of the bike to the rack if desired.

5� Repeat for a 2nd bicycle on the trailer side of the bicycle rack.

Fig�3

Always make sure all connections between the bicycle

rack and the trailer coupler are secure/tight/ready for

travel� Always make sure the bicycles are securely

attached to the bicycle rack before driving�
