Linksys WAP51AB - Instant Wireless - Access Point Manual de usuario

DDuuaall--BBaannddWWiirreelleessss

AAcccceessssPPooiinntt

nstall an access point that protects your infrastructure

investmentwithoutlimitingyoutoasingletypeofwire-

less technology. The Instant Wireless™ Dual-Band

Wireless Access Point works simultaneously with both

802.11a and 802.11b wireless standards to bring you the

ultimate in wireless freedom.This means you can enjoy the

broadest spectrum or wireless networking now without the

worry of a costly upgrade later.

The Dual-Band Wireless Access Point's high-powered

antennas enhance reception and provide seamless roaming

through your wireless network. An advanced user authenti-

cation feature and security encryption of up to 152-bits give

you the highest level of network security. It's easy to install

(just plug it in and you're ready to go!) and easy to use.With

Internet browser-based diagnostics and Setup Wizard,

you're always in control.

Compact, lightweight, and power-efficient, the Dual-Band

Wireless Access Point is the perfect wireless networking

solution,no matter which wireless networking standard you

choose to use.

• Operates in Both the 5GHz and 2.4GHz Bands

• Wi-Fi and Wi-Fi5 Compatibility with 802.11a and

802.11b Technology

• Up to 72 Mbps Turbo Mode (with Linksys 802.11a

products only)

• Supports up to 64 Wireless Users

• Enhanced Security Using MAC Address Filtering

and Up to 152-bit WEP Encryption

• Quick and Easy Setup Wizard

• FreeTechnical Support - 24 Hours a Day,7 Days a

Week,Toll-Free U.S. Calls

• 1-Year Limited Warranty

• High Speed Wireless Networking

• One Access Point Provides Both 802.11a and

802.11b Functionality

• Prepares You for the Faster 802.11a Standard

Now and Protects Your Wireless Investment

• Wireless Security with WEP Encryption of up to

152-bits and MAC Address Filtering

• Quick and Easy to Use with Web-Based

Management

IInnssttaannttWWiirreelleessss™™

DDuuaall--BBaannddWWiirreelleessssAAcccceessssPPooiinntt

((WWAAPP5511AABB))

Two Access Points In One

Using Both 802.11a & 802.11b Wireless Technologies

Features

Benefits

HHii--SSppeeeeddNNeettwwoorrkkiinnggFFrreeee

FFrroommCCaabblleeRReessttrriiccttiioonnss!!

Instant Wireless™ Series

Instant Wireless™

Dual-Band Wireless Access Point

• One Dual-Band Wireless Access Point

• One Setup CD-ROM with User Guide

• One Power Adapter

• One Quick Installation

• One Registration Card

DS-WAP51AB-070302NC KL

Specifications

Model Number WAP51AB

Standards IEEE 802.3, 802.3u, 802.11a and 802.11b

Channels 802.11a 8 Channels (US, Canada)

802.11b 11 Channels (US, Canada)

13 Channels (Europe)

14 Channels (Japan)

Ports/Buttons One 10/100 RJ-45 Port, One Power Port,

One Reset Button, One Power Switch

Cabling Type UTP CAT 5 or better

Data Rate Up to 54Mbps (up to 72 Mbps in Turbo Mode)

Transmit Power 18dBm

LEDs Power, Diag

802.11a:Act, Link

802.11b:Act, Link

LAN: Link/Act, Full/Col, 100

Environmental

Dimensions 7.31" x 1.88" x 6.88" (186 mm x 48 mm x 175 mm)

Antenna Height 4.5" (114 mm)

Unit Weight 15 oz. (0.42 kg)

Power External, 5V DC, 2.5A

Certifications FCC, Canada

Operating Temp. 0ºC to 40ºC (32ºF to 104ºF)

Storage Temp. -20ºC to 70ºC (-4ºF to 158ºF)

Operating Hum. 10% to 85% Non-Condensing

Storage Hum. 5% to 90% Non-Condensing

Package Contents

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Sales Information (800) 546-5797

World Wide Web* http://www.linksys.com

Japan (03) 5259-5137

Philippines (632) 638-5580

Singapore 552-8998

Thailand 717-0770

United Kingdom 0870 7393939

*Visit our website for the most current contact information.

One Pentium Class PC (200MHz or Faster

Processor) with:

• 64MB RAM,

• Internet Explorer 4.0 or Netscape Navigator

4.7 or Higher for Web-based configuration,

• one CD-ROM Drive, and

• either, an 802.11a or 802.11b Wireless

Adapter with TCP/IP Protocol Installed

a Network Adapter with Ethernet (UTP CAT

5) Cabling and TCP/IP protocol installed

Minimum Requirements
