LevelOne FSW-0507TX Manual de usuario

LevelOne

FSW-0507TX

FSW-0807TX

5/8 Port 10/100M PalmCon Switch

User’s Guide

FCC Warning

This equipment has been tested and found to comply with the

regulations for a Class B digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with this user’s guide,

may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be

required to correct the interference at his own expense.

CE Mark Warning

This is a Class B product. In a domestic environment, this

product may cause radio interference, in which case the user

may be required to take adequate measures.

VCCI Mark Warning

P/N:6012-1052004 Rev.H1-01

TABLE OF CONTENTS

ABOUT THIS GUIDE.................................................1

PURPOSE........................................................................................1

TERMS/USAGE............................................................................1

OVERVIEW OF THIS USER’S GUIDE...................................1

INTRODUCTION............................................................7

FEATURES .....................................................................................7

UNPACKING AND SETUP...................................9

UNPACKING.................................................................................9

SETUP .............................................................................................9

IDENTIFYING EXTERNAL

COMPONENTS...............................................................13

FRONT PANEL ...........................................................................13

REAR PANEL..............................................................................13

LED INDICATORS ...................................................................14

CONNECTING THE SWITCH.........................9

PC TO SWITCH............................................................................9

HUB TO SWITCH.......................................................................10

A. 10BASE-T Hub..............................................................10

B. 100BASE-TX Hub........................................................10

SWITCH TO SWITCH (OTHER DEVICES)...........................10

PORT SPEED & DUPLEX MODE.........................................11

TECHNICAL SPECIFICATIONS...............13

ABOUT THIS GUIDE

Congratulations on your purchase of the LeveOne 5/8 Port

10/100Mbps PalmCon Switch. This device integrates 100Mbps

Fast Ethernet and 10Mbps Ethernet network capabilities in a

highly flexible desktop package.

Purpose

This manual discusses how to install your LevelOne 5/8 Port

10/100Mbps PalmCon Switch

Terms/Usage

In this guide, the term “Switch” (first letter upper case) refers

to your LevelOne 5/8 Port 10/100Mbps PalmCon Switch and

”switch” (first letter lower case) refers to other Ethernet

switches.

Overview of this User’s Guide

Introduction.Describes the Switch and its features.

Unpacking and Setup.Helps you get started with the basic

installation of the Switch.

Identifying External Components.Describes the front panel,

rear panel and LED indicators of the Switch.

Connecting the Switch.Tells how you can connect the Switch

to your Ethernet network.

Technical Specifications. Lists the technical (general, physical

and environmental, and performance) specifications of the

Switch.

INTRODUCTION

This chapter describes the features of the Switch and some

background information about Ethernet/Fast

Features

The Switch was designed for easy installation and high

performance in an environment where traffic on the network

and the number of user increase continuously.

The Switch with its small, compact size was specifically

designed for small to middle workgroups. This Switch can be

installed where space is limited; moreover, they provide

immediate access to a rapidly growing network through a wide

range of user-reliable functions.

The Switch is ideal for deployment with multiple high-speed

servers for shared bandwidth 10Mbps or 100Mbps workgroups.

With the highest bandwidth 200Mbps (100Mbps full-duplex

mode), any port can provide workstations with a congestion-

free data pipe for simultaneous access to the server.

The Switch is expandable by cascading two or more switches

together. As all ports support 200Mbps, the Switch can be

cascaded from any port and to any number of switches.

The Switch is a perfect choice for site planning to upgrade to

Fast Ethernet in the future. Ethernet workgroups can connect

to the Switch now, and change adapters and hubs anytime later

without needing to change the Switches or reconfigure the

network.

The Switch combine dynamic memory allocation with store-

and-forward switching to ensure that the buffer is effectively

allocated for each port, while controlling the data flow between

the transmit and receive nodes to guarantee against all possible

packet loss.

The Switch is a managed 10/100 Fast Ethernet Switch that

offers solutions in accelerating small Ethernet workgroup

bandwidth. Other key features are:

Auto-MDI function supports automatic MDI/MDIX crossover

detection function gives true ‘plug and play’ capability without

the need of confusing crossover cables or crossover ports.

Store and forward switching scheme capability. As the result

of complete frame checking and error frame filtering, this

scheme prevents error packages from transmitting among

segments.

NWay Auto-negotiation for any port. This allows for auto-

sensing of speed (10/100Mbps) thereby providing you with

automatic and flexible solutions in your network connections.

Flow control for any port. This minimizes dropped packets by

sending out collision signals when the port’s receiving buffer is

full. Note that flow control is only available in half duplex

mode.

Data filtering/forwarding rate is wire-speed for 10Mbps and

100Mbps speed.

4K MAC address entry table per device with self-learning for

the Switch.

128KBytes RAM buffer per device for the Switch.
