LevelOne FNC-0107TX Manual de usuario
LevelOne
User Manual
FNC-0107TX
10/100Mbps PCI Fast Ethernet Adapter
V6.0
2
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
To assure continued compliance, any changes or modifications
not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
3
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure
limits set forth for an uncontrolled environment. This equipment
should be installed and operated with a minimum distance of
20 centimeters between the radiator and your body.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
CE Declaration of conformity
This product complies with the 99/5/EEC directives, including
the following safety and EMC standards:
EN300328-2
EN301489-1/-17
EN60950
CE Marking Warning
This is a Class B product. In a domestic environment this
product may cause radio interference in which case the user
may be required to take adequate measures.
4
Introduction
Hardware Overview
The FNC-0107TX adapters are highly integrated and
cost-effective single-chip Fast Ethernet Adapter that provides
32-bit performance, PCI bus master capability, and full
compliance with IEEE 802.3u 100Base-TX specifications.
This adapter supports both 10Mbps and 100Mbps network
speed, 100BaseTX operates on two pairs of category 5 UTP
cable and 10BaseT operates on Category 3, 4, 5 UTP cable.
With the Auto-Negotiation technology, network speed is
auto detected. When you connect the adapter to 10BaseT hub
via UTP cable, the network speed becomes 10Mbps. Similarly,
if you connect the adapter to 100BaseTX hub, the network
speed is 100Mbps. If the hub is a switching hub which supports
full duplex function, then the speed will be doubled to
20Mbps/200Mbps.
This adapter supplies many drivers including ODI driver for
NetWare 3.x/4.x/5.x, NDIS driver for Microsoft LAN Manager,
Windows 98SE/ME/2000/Vista/Win 7, Linux, and a Packet
Driver for TCP/IP software. Whatever your requirements are
ease of installation, superior performance or responsive
support backed up by unlimited technical support, this adapter
is the superior choice.
5
Features & Benefits
Compliant to PCI Revision 2.1/2.2
Supports a 32-bit general-purpose timer, referenced by the
external PCI clock source, and timer-interrupt
Supports ACPI, PCI power management
Complies with the IEEE 802.3 CSMA/CD, 100BaseTX and
10BaseT standard
Supports Full Duplex Flow Control
Full duplex design to double the performance
Supports Auto-Negotiation function
Auto-setups IRQ and I/O address
Built-in FIFO buffers to eliminate external memory
Supports smart remote boot ROM and provides the help for
RPL/PXE
Supports ODI Driver for NetWare 3.x, 4.x, NDIS Driver for
LAN Manager, Windows NT, Windows 2000, Vista, Win 7
Packet driver for TCP/IP
Provides one LED to indicate network Link/activity
6
Installation
Hardware Installation
To insert the FNC-0107TX into your computer, follow the steps
list below.
1. Turn off the computer and remove its cover.
2. Insert the adapter into a PCI slot.
3. Secure the adapter to the rear of the computer chassis and
put back the computer cover.
4. Connect the adapter to the network using twisted-pair
cables.
Hardware Requirement for Wake-On-LAN
The motherboard must support PCI 2.2. (The function will be
provided from the PCI bus directly ), Some computers may
require you to change a setting in your computer’s BIOS or
setup program to enable the WOL feature
ATX 2.01 power supply
Install only one active WOL adapter per computer.
You can install additional non-WOL adapters.
7
Driver Installation
Use the drivers supplied by the CD included in the adapter. For
detail description, please refer to "help" in the CD provided by
the adapter.
Troubleshooting
If you experience any problems with the adapter, first make
sure the appropriate driver is loaded, the proper cable is
connected to the adapter port and the hub complies with the
adapter specification, such as 10Mbps 10Base-T or 100Mbps
100Base-TX. Then recheck the LED.
The adapter provided one LEDs to indicate network status.
LINK/ACTIVE LED
A red LED will illuminate when the card has been
successfully connected to a network and blink when data is
being transmitted or received over the network. The Link/Active
LED lights up when the Adapter is connected to a network.
When the light is blinking, it indicates that the adapter is
receiving data or transmitting data.
8
Wake-On-LAN
The PC does not boot up when a Magic Packet or Wake
up Frame is sent.
1. Check the specification of this PC meets the hardware
requirement.
2. Enable the WOL function or the power-ON function of the
PC. Verify the BIOS setting of Wake-On-LAN is configured
properly. The name of this function is system dependent,
but may be located in a category heading titled something
like Power Management. (Please check your computer
owner’s manual for more information regarding the CMOS
Setup Utility and BIOS settings.
3. Boot up the PC again.
4. If the adapter still does not wake up, the reason might be
that your computer’s BIOS do not fully ACPI-compliant.
Your first step should be to contact your computer dealer
or motherboard maker to see if you need to upgrade your
computer’s BIOS.
9
Specification
Topology
Star
Connector
RJ45
Standard
IEEE802.3 10Base-T, IEEE802.3u
100Base-TX
Transmission Rate
100Mbps or 200Mbps
Hardware
PCI Local Bus Master 2.1/2.2 Support
(Supports PCI 2.2ACPI Power
Management Wake-On-LAN)
IRQ Line
Assigned by system
I/O Address
Assigned by system
Drivers
ODI driver for NetWare 3.x, 4.x, NDIS
driver for Microsoft LAN manager,
Windows 98, Windows ME, Windows
NT, Windows 2000, Win 7 Packet driver
for TCP/IP
Temperature
0 to 40 C (Operating)
Humidity
5% to 95% (Non-condensing)
Power consumption
1W (Max)
