Lenovo TABS850L Cómo utilizar

Read this guide carefully before using your Lenovo TAB S8-50.

All information labeled with * in this guide refers only to the WLAN +

LTE model (Lenovo TAB S8-50L(C) ).

Lenovo TAB S8-50

Safety, Warranty & Quick Start

Guide V1.0

Technical speciﬁcations

Intel ATOM Bay Trail-T 3745, 1.86 GHz

4290 mAh

Model & version

Camera

Battery

Display

Wireless

communication

8.0 megapixels AF (back) + 1.6 megapixels HD (front)

Size: 8 inches

Resolution: 1920 × 1200

Bluetooth 4.0 WLAN 802.11 b/g/n GPS

*LTE , WCDMA, GSM

①Depending on the measuring method, the dimensions and weight might

vary slightly.

①Dimensions &

Weight

Depth: 7.9 mm (0.31 inch) Width: 123.8 mm (4.87 inches)

Height: 209.8 mm (8.26 inches) Weight: 299 g

* Your Lenovo TAB S8-50 supports LTE Band 1, 2, 3, 4, 5, 7, 8,19 and 20. But In

some countries, LTE is not supported. To know if your Lenovo TAB S8-50 works with

LTE networks in your country, contact your carrier.

*Version: WLAN + LTE

CPU

Lenovo TAB S8-50

Version: WLAN

Android

*Version: WLAN + LTE

(Data only)

(Voice)

*Model: Lenovo TAB S8-50LC;

*Model: Lenovo TAB S8-50L;

Model: Lenovo TAB S8-50F;

System

789

Earphone jack *Micro SIM card slot

MicroSD card slot Receiver Micro USB

Microphone Volume key

LED light

On/Off button

The WLAN model ( Lenovo TAB S8-50F ) does not have a Micro SIM card slot.

Back camera

209.8 mm

123.8 mm

56 7

7.9 mm

First glance

Front camera

You can use cellular services with the WLAN + LTE model ( Lenovo TAB S8-50L(C) ) by

inserting the Micro SIM card provided by your carrier.

Install the Micro SIM card and the MicroSD card as shown.

Step 1. Open the card-slot door.

Step 2. Insert the cards into the respective

slots, push the cards until they are

engaged in place.

Step 3. Close the card-slot door.

Only Micro SIM card works with your

Lenovo TAB S8-50L(C)

!!! DO not insert or remove the Micro SIM card while your Lenovo TAB S8-50L(C) is

turned on. Doing so can permanently damage your Micro SIM card or Lenovo TAB

S8-50L(C).

Preparing your Lenovo TAB S8-50

Turning on/off

Before using your Lenovo TAB S8-50, you might need to charge the battery.

Charge the battery as shown.

Connect your

Lenovo TAB S8-50

to a power outlet using the included cable and

USB power adapter.

Low battery Fully charged Charging

Turn on: Press and hold the On/Off button until the

Lenovo logo appears.

Tur n of f: Press and hold the On/Off button for a few

seconds, tap Power off and then tap OK.

Starting to use your Lenovo TAB S8-50

Taking screenshots

Press and hold the On/Off button and the volume down button at the same time.

Learning more

11244482-00

To learn more information about your Lenovo TAB S8-50 functions, refer

to the “User Guide” from the Browser favorites in your Lenovo TAB S8-50.

To obtain the “Regulatory Notices”, go to

http://support.lenovo.com/.

Getting support

For support on network service and billing, contact your wireless network

operator. For instructions on how to use your Lenovo TAB S8-50, go to

http://support.lenovo.com/.

Legal notices

Lenovo and the Lenovo logo are trademarks of Lenovo in the United States,

other countries, or both.

Other company, product, or service names may be trademarks or service

marks of others.

Manufactured under license from Dolby Laboratories. Dolby and the

double-D symbol are trademarks of Dolby Laboratories.

First Edition (August 2014)

Radio and Telecommunications Terminal Equipment Directive

This product is in compliance with the essential requirements and other

relevant provisions of the Radio and Telecommunications Terminal

Equipment Directive, 1999/5/EC.

European Union conformity

Printed in China

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is

delivered pursuant a General Services Administration “GSA” contract, use,

reproduction, or disclosure is subject to restrictions set forth in Contract

No. GS-35F-05925.

Read before using your tablet

Read ﬁrst-Regulatory information

The following sections provide critical safety and regulatory information for Lenovo

tablets and instructions on how to access electronic versions of the publications

developed for your tablet.

Downloading publications

Accessing your User Guide

The following information describes the technical support that is available for your

product, during the warranty period or throughout the life of your product. Refer to the

Lenovo Limited Warranty for a full explanation of Lenovo warranty terms. See “Lenovo

Limited Warranty notice” later in this document for details on accessing the full

warranty.

Online technical support

Online technical support is available during the lifetime of a product at

http://www.lenovo.com/support.

You can get help and information from the Customer Support Center by telephone.

Before contacting a Lenovo technical support representative, please have the following

information available: model and serial number, the exact wording of any error

message, and a description of the problem.

Your technical support representative might want to walk you through the problem

while you are at your device during the call.

Device models equipped with wireless communications comply with the radio frequency

and safety standards of any country or region in which it has been approved for wireless

use. In addition, if your product contains a telecom modem, it complies with the

requirements for connection to the telephone network in your country.

Be sure to read the Regulatory Notice for your country or region before using the wireless

devices contained in your device. To obtain a PDF version of the Regulatory Notice, refer

to the “Downloading publications” section below.

Electronic versions of your publications are available from the

http://support.lenovo.com. To download the publications for your device, go to:

http://support.lenovo.com and follow the instructions on the screen.

Your User Guide contains detailed information about your device. To access your User

Guide, go to

http://support.lenovo.com and follow the instructions on the screen.

Service and Support information

Telephone technical support

WARNING: Handling the cord on this product or cords associated with accessories

sold with this product will expose you to lead, a chemical known to the State of

California to cause cancer, and birth defects or other reproductive harm. Wash hands

after handling.

Polyvinyl Chloride (PVC) cable and cord notice

Built-in rechargeable battery notice

Prevent hearing damage

Your device has a headphone connector. Always use the headphone connector for

headphones (also called a headset) or earphones.

Worldwide Lenovo Support telephone list

DANGER:

Do not attempt to replace the internal rechargeable lithium ion battery. Contact Lenovo

Support for factory replacement.

CAUTION:

Excessive sound pressure from earphones and headphones can cause hearing loss.

Adjustment of the equalizer to maximum increases the earphone and headphone

output voltage and the sound pressure level. Therefore, to protect your hearing, adjust

the equalizer to an appropriate level.

Excessive use of headphones or earphones for a long period of time at high volume

can be dangerous if the output of the headphone or earphone connectors do not

comply with speciﬁcations of EN 50332-2.

The headphone output connector of your device complies with EN 50332-2 Sub

clause 7. This speciﬁcation limits the device's maximum wide band true RMS output

voltage to 150 mV. To help protect against hearing loss, ensure that the headphones or

earphones you use also comply with EN 50332-2 (Clause 7 limits) for a wide band

characteristic voltage of 75 mV. Using headphones that do not comply with EN

If the telephone number for your country or region is not listed, contact your Lenovo

reseller or Lenovo marketing representative.

Important safety and handling information

Plastic bag notice

DANGER:

Plastic bags can be dangerous. Keep plastic bags away from babies and children to

avoid danger of suffocation.

Important: Telephone numbers are subject to change without notice. The most

up-to-date telephone list for the Customer Support Center is always available at

http://www.lenovo.com/support/phone.

Warning statement:

To prevent possible hearing damage, do not listen at high volume levels for a long

period of time.

Lenovo Limited Warranty notice

This product is covered by the terms of the Lenovo Limited Warranty, version

L505-0010-02 08/2011. Read the Lenovo Limited Warranty (LLW) at http://www.leno-

vo.com/warranty/llw_02. You can view the LLW in a number of languages from this

Web site. If you cannot view the LLW from the Web site, contact your local Lenovo

ofﬁce or reseller to obtain a printed version of the LLW.

Lenovo TAB S8-50

Model & Version

Model Version

WLAN

WLAN+LTE (Data only)

WLAN+LTE (Voice)

Lenovo TAB S8-50F

Lenovo TAB S8-50L

Lenovo TAB S8-50LC

Sound pressure warning statement

For the device that is tested in accordance with EN 60950-1:

2006+A11:2009:+A1:2010+A12:2011, it is mandatory to perform audio tests for

EN50332.

This device has been tested to comply with the Sound Pressure Level requirement laid

down in the applicable EN 50332-1 and/or EN 50332-2 standards. Permanent hearing

loss may occur if earphones or headphones are used at high volume for prolonged

periods of time.

Warranty information

50332-2 can be dangerous due to excessive sound pressure levels.

If your device came with headphones or earphones in the package, as a set, the

combination of the headphones or earphones and the device already complies with

the speciﬁcations of EN 50332-1. If different headphones or earphones are used,

ensure that they comply with EN 50332-1 (Clause 6.5 Limitation Values). Using

headphones that do not comply with EN 50332-1 can be dangerous due to excessive

sound pressure levels.

* Excludes some components. 90-day limited warranty for power adapters, keyboards,

plastics and hinges.

Types of Warranty Service

1. Customer Replaceable Unit (“CRU”) Service

2. On-site Service

Warranty period and type of Warranty service

Country or Region Purchase Warranty Period Type of Warranty

Service

France, Germany, Italy, Austria,

United Kingdom, Israel, Australia, New

Zealand

parts and labor-1 year

battery pack -1 year 1, 3

Serbia, Costa Rica, Venezuela, Peru,

Uruguay, Ecuador, Colombia, Chile, Argentina,

Indonesia, Vietnam, India, Malaysia, Thailand,

Philippines, Singapore, Hong Kong

parts and labor-1 year

battery pack -1 year 1, 4

Russia, Ukraine, Egypt, Lebanon, Morocco,

South Africa, Tunisia, Mauritius, Mozambique,

Saudi Arabia, United Arab Emirates, Jordan,

Kenya, Nigeria, Uganda, Ghana, Oman,

Tanzania, Namibia

parts and labor-1 year

battery pack -1 year 4

Poland, Hungary, Romania, Bulgaria, Greece,

Croatia, Slovenia, Slovakia, Cyprus, United

States of America, Canada, Mexico, Japan

parts and labor-1 year

battery pack -1 year 1, 5

Panama parts and labor-1 year

battery pack -1 year 2, 4

Taiwan, South Korea parts and labor-1 year

battery pack -1 year 3, 4

Spain, Switzerland, Portugal, Netherlands,

Belgium, Sweden, Denmark, Norway, Finland,

Estonia, Latvia, Lithuania, Iceland

parts and labor-2 year

battery pack -1 year

1, 3

Czech Republic

parts and labor-2 year

battery pack -1 year

1, 5

Turke y parts and labor-2 year

battery pack -1 year 3, 4

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Tableta de Lenovo

Lenovo

Lenovo YOGA TABLET 8 Manual de usuario

Lenovo

Lenovo TAB 2 A10-70L Manual de usuario

Lenovo

Lenovo TB-7306V Manual de operación y mantenimiento

Lenovo

Lenovo IdeaTab S6000L Manual de instalación y operación

Lenovo

Lenovo YOGA Tablet 22 Cómo utilizar

Lenovo

Lenovo YOGA Tablet 2-851F Cómo utilizar

Lenovo

Lenovo YOGA Tab 3 8 Manual de usuario

Lenovo

Lenovo Tab Extreme Manual de usuario

Lenovo

Lenovo IdeaPad A1-07 Manual de usuario

Lenovo

Lenovo PHAB2 Pro Cómo utilizar

Lenovo

Lenovo TAB4 7 Essential Cómo utilizar

Lenovo

Lenovo IdeaTab A1000 Manual de usuario

Lenovo

Lenovo YOGA Tablet 2-830F Cómo utilizar

Lenovo

Lenovo IdeaTab S6000L Manual de usuario

Lenovo

Lenovo YT-J706X Manual de operación y mantenimiento

Lenovo

Lenovo 10e Chromebook Manual de usuario

Lenovo

Lenovo TAB4 10 Manual de usuario

Lenovo

Lenovo Tab M7 Cómo utilizar

Lenovo

Lenovo YOGA TABLET 8 Manual de usuario

Lenovo

Lenovo Lenovo S5000 Manual de usuario

Lenovo

Lenovo TAB 2 A10-70L Cómo utilizar

Lenovo

Lenovo TB-7304I Cómo utilizar

Lenovo

Lenovo IdeaTab A2109A Manual de operación y mantenimiento

Lenovo

Lenovo TB-X504F Cómo utilizar

Manuales populares de Tableta de otras marcas

Laser

Laser MID-1060 Guía del usuario

MUNBYN

MUNBYN IRT09J Guía de inicio rápido

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manual de usuario

Dell

Dell Latitude ST Manual del propietario

Venturer

Venturer WT9L11 Manual de usuario

EDUGEAR

EDUGEAR UnoBook Manual de usuario

Philips

Philips PI3210G/58 Manual de usuario

ADLINK Technology

ADLINK Technology IMT-BT Manual de usuario

TwinMOS

TwinMOS TwinTAB-T102D1 Manual de usuario

Archos

Archos 9.7 xenon Manual de usuario

Getac

Getac E100 Manual de usuario

HANNspree

HANNspree HANNspad SN70T3 Manual de usuario

Philips

Philips PI3105W2/55 Manual de usuario

LG LG-V935 Manual de usuario

Zeki

Zeki TBDB763B Manual de usuario

Ricoh

Ricoh eQuill Manual de usuario

DT Research

DT Research DT365CT Instrucciones de montaje

MaxWest

MaxWest Nitro Phablet 9 Manual de usuario
