Ch pter 1. About the dock
Product description
The dock is an expansion module. You can use it to connect your compatible computer to a local area
network (LAN) and multiple devices, such as a headset, external displays, and Universal Serial Bus (USB)
devices.
For the list o compatible computers, go to https://www.lenovo.com/support/docks and select the entry or the
dock.
Oper ting system requirement
Microso t® Windows® 10
In the box
• ThinkPad Thunderbolt 3 Workstation Dock Gen 2
• 230-watt power adapter and power cord
• ThinkPad Thunderbolt 3 Workstation Dock Split Cable
• ThinkPad Workstation Dock Slim Tip Y Cable
• Documentation
Contact your place o purchase i any item is missing or damaged. Ensure that you retain your proo o
purchase and packing material. They might be required to receive warranty service.
Product overview
1 Indic tor in ThinkP d logo: The indicator is solid on when the dock is connected to ac power.
2 Audio connector: Connect a headphone or a headset with a 3.5-mm (0.14-inch) and 4-pole plug.
3 USB-CTM connector (Thunderbolt 3 comp tible): Use the connector to trans er data (with high speed
supported by the Thunderbolt 3 technology), charge your device, or connect to an external display.
Notes:
© Copyright Lenovo 2019 1
• This connector does not support the external display i your computer does not have a USB-C connector
(Thunderbolt 3 compatible).
• Do not connect your computer to this connector.
4 USB 3.1 connector Gen 2: With greater data trans er rate, the USB 3.1 connector Gen 2 is used to
connect USB-compatible devices, such as a USB keyboard, a USB mouse, a USB storage device, or a USB
printer.
230
w
170
w
135
w
65
w
1 Security-lock slot: Lock your dock to a desk, table, or other ixture through a compatible security cable
lock.
2 Power button with indic tor: The power button works di erently in the ollowing situations:
• When you connect the dock only to ac power but not the computer, press this power button to turn on or
turn o the dock.
• When you connect the dock to both ac power and the computer, this button has the same unction as the
computer power button.
The indicator in the power button shows the status o the dock and computer:
• Off: The dock is o , the computer is o , or the computer is in hibernation mode.
• White: The computer is on.
• White nd blinking slowly: The computer is in sleep mode.
• Amber: The dock is on.
2ThinkPad Thunderbolt 3 Workstation Dock Gen 2User Guide
3 8 USB 3.1 connector Gen 2: Connect USB-compatible devices, such as a USB keyboard, a USB mouse,
a USB storage device, or a USB printer. For optimal data trans er, connect a USB 3.1 device to a USB 3.1
connector instead o a USB 2.0 connector.
Note: It is recommended that you connect the receiver o the wireless keyboard or mouse to the USB 3.1
connector Gen 2 8.
4 Alw ys On USB 3.1 connector Gen 2: Connect USB-compatible devices or charge mobile digital devices
and smartphones when the dock is connected to ac power.
5 Ethernet connector: Connect the dock to a local area network (LAN).
6 Displ yPort® connectors: Connect a high-per ormance monitor, a direct-drive monitor, or other devices
that use a DisplayPort connector.
7 HDMITM connectors: The High De inition Multimedia Inter ace (HDMI) connector is a digital audio and
video inter ace. It enables you to connect the dock to a compatible digital audio device or video monitor,
such as an HDTV.
9 c power connector: Connect the ac power adapter.
10 Thunderbolt 3 workst tion connector: Connect the dock to your computer with ThinkPad Thunderbolt
3 Workstation Dock Split Cable.
St tement on USB tr nsfer r te
Depending on many actors such as the processing capability o the host and peripheral devices, ile
attributes, and other actors related to system con iguration and operating environments, the actual trans er
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below or each corresponding device.
USB device D t r te (Gbit/s)
3.1 Gen 2 10
Chapter 1.About the dock 3
4ThinkPad Thunderbolt 3 Workstation Dock Gen 2User Guide
Ch pter 2. Set up the dock
Inst ll the dock
Connect the dock to c power nd your computer
Use the accompanying ac power adapter, power cord, ThinkPad Thunderbolt 3 Workstation Dock Split
Cable, and ThinkPad Workstation Dock Slim Tip Y Cable to install the dock.
Depending on your computer, you can connect both connectors 7a or only the Thunderbolt 3 connector 7b
to your computer.
The dock supplies power to the computer when the dock is connected to ac power and your computer.
230 W
7a 7b
65/135 W
170 W
65/135w
170w
En ble the dock
To enable the dock when connected to the computer or the irst time, do either o the ollowing:
• Con irm the change when prompted i you have the administrator privilege.
• Enter the ThinkPad Setup program (BIOS) and go to the Config menu. Select Thunderbolt(TM) 3 ➙
Security level ➙ No Security.
Inst ll the dock driver
The dock driver is preinstalled on compatible computers and the dock is ready or use a ter you connect it to
ac power and computer.
You also can download the latest dock driver rom the Lenovo Web site by doing the ollowing:
1. Go to https://www.lenovo.com/support/docks.
2. Select the entry or the dock and then ollow the on-screen instructions.
© Copyright Lenovo 2019 5
6ThinkPad Thunderbolt 3 Workstation Dock Gen 2User Guide
