Lenovo ThinkPad Thunderbolt 3 Manual de usuario

ThinkPad Thunderbolt 3 Dock

User Guide

http://www.lenovo.com/safety

Note: efore using this information and the product it supports, ensure that you read and understand the

warranty information in the documentation that comes with the product.

Fourth Edition (March 2019)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services

Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-

35F-05925.

Contents

Chapter 1. About the dock . . . . . . . 1

Product description . . . . . . . . . . . . . . 1

Dock controls, connectors, and indicators . . . . . 1

Statement on US transfer rate . . . . . . . . 4

Main features. . . . . . . . . . . . . . . . . 4

Maximum resolutions . . . . . . . . . . . . . 4

Chapter 2. Setting up the dock . . . . . 7

Installing the device driver on Windows operating

systems . . . . . . . . . . . . . . . . . . . 7

Connecting the dock to your computer. . . . . . . 7

Uninstalling the device driver from Windows

operating systems . . . . . . . . . . . . . . . 8

Chapter 3. Using the dock. . . . . . . . 9

Using the headset and microphone combo

connector . . . . . . . . . . . . . . . . . . 9

Using the Ethernet connector . . . . . . . . . . 9

Using the video output connectors . . . . . . . 10

Extend mode . . . . . . . . . . . . . . 10

Mirror mode . . . . . . . . . . . . . . 11

Single-display mode . . . . . . . . . . . 11

Rotating the external monitor display. . . . . 12

Setting the resolution of the external

monitor . . . . . . . . . . . . . . . . 12

Chapter 4. Troubleshooting . . . . . . 13

Appendix A. Accessibility

information . . . . . . . . . . . . . . . 15

Appendix B. Trademarks . . . . . . . 17

ii ThinkPad Thunderbolt 3 Dock User Guide

Chapter 1. About the dock

This chapter contains product information for the ThinkPad® ThunderboltTM 3 Dock (hereafter called dock).

Product description

The dock is a portable expansion module that enables you to easily connect your computer to the Ethernet

and multiple devices, such as a headset, a microphone, a monitor, and Universal Serial us (US ) devices.

You can set up your work area by connecting your computer to the dock with the Thunderbolt 3 cable,

connecting multiple devices to the dock, and configuring the dock on your computer. Then, you are ready to

use the multiple devices each time you connect your computer to the dock. The dock can also supply power

to your computer when it is connected to the computer.

Your option package includes the following:

• ThinkPad Thunderbolt 3 Dock

• Power adapter

• Power cord

• Thunderbolt 3 cable

• Warranty poster

Contact your place of purchase if any item is missing or damaged. e sure to retain your proof of purchase

and packing material. They might be required to receive warranty service.

Dock controls connectors and indicators

The following illustration helps you locate and identify the controls, connectors, and indicators on your dock.

Figure 1. Dock controls, connectors, and indicators

1 Power button with indicator 2 Security-lock slot

3 US 3.0 connector 4 Thunderbolt 3 connector

5 Headset and microphone combo connector 6 Always On US 3.0 connector

7 US 3.0 connector 8 Ethernet connector

9 US 3.0 connector 10 Video graphics array (VGA) connector

11 DisplayPort® (DP) connector 12 DisplayPort connector

13 High-Definition Multimedia InterfaceTM (HDMITM)

connector

14 Thunderbolt 3 connector

15 Power connector 16 Indicator in ThinkPad logo

Notes:

• Do not use the DP connector 12 and HDMI connector 13 at the same time.

• For the wireless keyboard and mouse, it is recommended that you connect the keyboard/mouse US

receiver to the US 3.0 connector 9 located above the VGA connector on the dock.

1 Power button with indicator

• Power button

– When the dock is disconnected from the computer, press the power button to turn off the dock.

– When the dock is connected to the computer, the power button on the dock has the same functions as

the power button of the computer. You can use the power button on the dock to turn on, turn off, sleep,

2ThinkPad Thunderbolt 3 Dock User Guide

hibernate, or wake up the computer after you define what power button does on your computer. To

change what the power button does, do the following:

1. Go to Control Panel and then change the view of the Control Panel from Category to Large icons or

Small icons.

2. Click Power Options ➙ Choose what the power buttons do.

3. Follow the instructions on the screen to complete the operation.

• Power button indicator

The indicator in the power button shows the dock status and computer status:

– Amber: The dock is on and ready to connect to the computer; or the dock is on and the computer is in

hibernation mode or off.

– Off: The dock is off.

– White: The dock is on and the computer is on or in sleep mode.

2 Security-lock slot

To protect your dock from theft, lock your dock to a desk, table, or other fixtures through a security cable

lock that fits this security-lock slot.

Note: You are responsible for evaluating, selecting, and implementing the locking device and security

feature. Lenovo makes no comments, judgments, or warranties about the function, quality, or performance

of the locking device and security feature.

3 7 9 USB 3.0 connector

Connect US 3.0 compatible devices, such as a US storage device or a US printer.

4 Thunderbolt 3 connector

Connect Thunderbolt 3 or US -C compatible devices to the dock, such as a Thunderbolt 3 or US -C

compatible external monitor or storage device. You also can connect a DP, HDMI, or VGA monitor to this

connector if you have a suitable convert cable available.

5 Headset and microphone combo connector

Connect headphones or a headset with a 3.5-mm (0.14-inch), 4-pole plug.

6 Always On USB 3.0 connector

Charge some mobile digital devices and smartphones when the dock is connected to the power supply.

The Always on US 3.0 connector can supply power up to 2.4 A during the charging process.

8 Ethernet connector

Connect the dock to an Ethernet LAN with an Ethernet cable.

10 VGA connector

Connect a VGA-compatible video device, such as a VGA monitor.

11 12 DP connector

Connect a high-performance monitor, a direct-drive monitor, or other devices that use a DP connector.

Chapter 1.About the dock 3

13 HDMI connector

Connect a high-performance monitor, a direct-drive monitor, or other devices that use an HDMI connector.

14 Thunderbolt 3 connector

Connect the dock to your computer by a Thunderbolt 3 cable.

15 Power connector

Connect the dock to the power adapter.

16 LED indicator in ThinkPad logo

This red indicator stays on when the dock is connected to power.

Statement on USB transfer rate

Depending on many factors such as the processing capability of the host and peripheral devices, file

attributes, and other factors related to system configuration and operating environments, the actual transfer

rate using the various US connectors on this device will vary and will be slower than the data rate listed

below for each corresponding device.

USB device Data rate (Gbit/s)

3.1 Gen 1 (3.0) 5

Main features

• Supported US devices: five US 3.0 devices, and one Thunderbolt 3 or compatible device

• Supported external monitors: two DP monitors, an HDMI monitor, a VGA monitor, and a US -C monitor

• Supported operating system: Windows® 10

• Network connection: Gigabit Ethernet speed

• Supported functions on some Lenovo computers:

– Preboot eXecution Environment (PXE)

– Media Access Control (MAC) address Pass Through

– Wake on LAN

Notes:

– For more information about these functions, see “Using the Ethernet connector” on page 9.

– For detailed computer model information, go to http://www.lenovo.com/accessoriesguide, and download

Network function support – Option Compatibility Matrix.

Maximum resolutions

To achieve better display experience, it is recommended that you connect no more than three external

monitors to the dock at a time. When you connect three external monitors, your computer display is

disabled.

Note: When you connect two or more external monitors to the dock, the Thunderbolt 3 connector works

only on some Lenovo computers. For detailed computer model information, go to http://www.lenovo.com/

support/docks and click ThinkPad Thunderbolt 3 Dock.

4ThinkPad Thunderbolt 3 Dock User Guide

• One external monitor

– DP: 3840 x 2160 pixels / 60 Hz

– HDMI: 3840 x 2160 pixels / 30 Hz

– Thunderbolt 3: 3840 x 2160 pixels / 60 Hz

– VGA: 1920 x 1200 pixels / 60 Hz

• Two external monitors simultaneous

– DP1 and DP2 / HDMI: DP1 3840 x 2160 pixels / 30 Hz; DP2 / HDMI 3840 x 2160 pixels / 30 Hz

– DP1 and Thunderbolt 3: DP1 3840 x 2160 pixels / 60 Hz; Thunderbolt 3 3840 x 2160 pixels / 60 Hz

– DP1 and VGA: DP1 3840 x 2160 pixels / 30 Hz; VGA 1920 x 1200 pixels / 60 Hz

– DP2 / HDMI and Thunderbolt 3: DP2 3840 x 2160 pixels / 60 Hz; HDMI 3840 x 2160 pixels / 30 Hz;

Thunderbolt 3 3840 x 2160 pixels / 60 Hz

– DP2 / HDMI and VGA: DP2 / HDMI 3840 x 2160 pixels / 30 Hz; VGA 1920 x 1200 pixels / 60 Hz

– Thunderbolt 3 and VGA: Thunderbolt 3 3840 x 2160 pixels / 60 Hz; VGA 1920 x 1200 pixels / 60 Hz

• Three external monitors simultaneous

– DP1, DP2 / HDMI, and Thunderbolt 3: DP1 3840 x 2160 pixels / 30 Hz; DP2 / HDMI 3840 x 2160 pixels /

30 Hz; and Thunderbolt 3 3840 x 2160 pixels / 60 Hz

– DP1, DP2 / HDMI, and VGA: DP1 3840 x 2160 pixels / 30 Hz; DP2 / HDMI 1920 x 1080 pixels / 60 Hz;

and VGA 1920 x 1080 pixels / 60 Hz

– DP2 / HDMI, Thunderbolt 3, and VGA: DP2 / HDMI 3840 x 2160 pixels / 30 Hz; Thunderbolt 3 3840 x

2160 pixels / 60 Hz; and VGA 1920 x 1200 pixels / 60 Hz

Chapter 1.About the dock 5

6ThinkPad Thunderbolt 3 Dock User Guide
