Lenovo ThinkPad 40B20135DK Manual de usuario

ThinkPad Universal USB-C Dock

ThinkPad Universal USB-C Smart Dock

User Guide

https://www.lenovo.com/sa ety

Note: Be ore using this documentation and the product it supports, ensure that you read and understand

the warranty in ormation in the documentation that comes with the product.

Second Edition (January 2022)

LIMITED AND RESTRICTED RIGHTS NOTICE: I data or so tware is delivered pursuant to a General Services

Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set orth in Contract No. GS-

35F-05925.

Contents

Chapter 1. A out the dock . . . . . . . 1

In the box . . . . . . . . . . . . . . . . . . 1

Product overview . . . . . . . . . . . . . . . 2

Chapter 2. Set up the dock . . . . . . . 5

Install the dock . . . . . . . . . . . . . . . . 5

Install the dock driver and irmware . . . . . . . . 5

Install Lenovo Dock Manager . . . . . . . . . . 5

Chapter 3. Use the dock. . . . . . . . . 7

Use the video output connectors . . . . . . . . . 7

Supported resolution . . . . . . . . . . . . 7

Con igure the external displays . . . . . . . . 7

Use the Ethernet connector . . . . . . . . . . . 7

Chapter 4. Trou leshooting . . . . . . . 9

Appendix A. Accessi ility

information . . . . . . . . . . . . . . . 11

Appendix B. Trademarks . . . . . . . 13

ii ThinkPad Universal USB-C Dock ThinkPad Universal USB-C Smart Dock User Guide

Chapter 1. A out the dock

Thanks or using ThinkPad Universal USB-C Dock / ThinkPad Universal USB-C Smart Dock.

This dock is an enhanced universal compatible module to help you expand your computer with automated

and silent updates. You can use it to connect your computer (Microso t® Windows® 10 only) to a local area

network (LAN) and multiple devices, such as a headset, external displays, and Universal Serial Bus (USB)

devices.

To view the compatible computers,

1. Go to https://support.lenovo.com/us/en/solutions/accs-guide.

2. Select ThinkPad, ThinkCentre, ThinkStation, Ideapad and Ideacentre Option Compati ility Matrix.

Then ollow the on-screen instructions.

In the ox

• ThinkPad Universal USB-C Dock / ThinkPad Universal USB-C Smart Dock

• 90W ac power adapter and power cord

• 1m USB-C® cable

• Documentation

Contact your place o purchase i any item is missing or damaged. Ensure that you retain your proo o

purchase and packing material. They might be required to receive warranty service.

Product overview

USB-C connector (for connecting computer)

Connect to your computer with the accompanying USB-C cable.

Power connector

Connect to ac power with the accompanying ac power adapter and power cord

DisplayPort® connector

Connect to an external display with a DisplayPort cable.

USB 3.2 connector Gen 2

Connect a compatible device to trans er data at USB 3.2 speed, up to 10 Gbps.

USB 2.0 connector

Connect a USB device, such as mouse.

Cloud indication (* For ThinkPad Universal USB-C Smart Dock only)

Indicates the cloud connection status.

• Solid am er: Disconnected

• Blinking am er (1 second on/off): Connecting

• Solid green: Connected

USB 2.0 connector

Connect a USB device, such as keyboard.

Ethernet connector

Connect to a LAN with an Ethernet cable.

2ThinkPad Universal USB-C Dock ThinkPad Universal USB-C Smart Dock User Guide

Always On USB 3.2 connector Gen 2

Connect a compatible device to trans er data or charge with the output voltage and current o up to

5 V and 2.4 A.

HDMITM connector

Connect to an external display with a High- De inition Multimedia Inter ace (HDMI) cable.

Power utton

Press to turn o or turn on the dock.

Security-lock slot

Support cable locks that con orm to the Kensington / Lenovo NanoSaver® lock standards (using

Cleat locking technology).

Security-lock slot

Support cable locks that con orm to the Kensington / Lenovo MicroSaver® lock standards (using T-

bar locking technology) or MiniSaver® lock standards (using CleatTM locking technology).

Audio connector

Connect a headset or headphones with 3.5 mm plug.

Power utton Indication

When the dock is connected to ac power but not your computer, press the dock power button to turn o or

turn on the dock. The indicator on the dock power button shows the dock status:

LED status Dock status

Amber On

O O

When the dock is connected to both your computer and the ac power adapter, the indicator on the dock

power button shows the computer status:

LED status Computer status

Solid white On

Blinking white In sleep mode

Blinking orange Updating driver

O O or in hibernation mode

Statement on USB transfer rate

Depending on many actors such as the processing capability o the host and peripheral devices, ile

attributes, and other actors related to system con iguration and operating environments, the actual trans er

rate using the various USB connectors on this device will vary and will be slower than the data rate listed

below or each corresponding device.

USB device Data rate (G it/s)

3.2 Gen 1 / 3.1 Gen 1 5

3.2 Gen 2 / 3.1 Gen 2 10

3.2 Gen 2 × 2 20

Thunderbolt 3 connector (USB-C) 40

Thunderbolt 4 connector (USB-C) 40

Chapter 1.About the dock 3

4ThinkPad Universal USB-C Dock ThinkPad Universal USB-C Smart Dock User Guide

Chapter 2. Set up the dock

Install the dock

Use the accompanying ac power adapter, power cord, and USB-C cable to install the dock. The dock

supplies power to the computer when the dock is connected to ac power and your computer.

Install the dock driver and firmware

The dock driver and irmware is preinstalled on compatible computers and the dock is ready or use a ter you

connect it to ac power and computer.

It is recommended that you update the dock driver and irmware whenever a new version is available to

improve per ormance o the dock.

To update dock irmware:

1. Go to https://www.lenovo.com/support/docks.

2. Select the entry or the dock and then ollow the on-screen instructions to download the irmware.

3. When the indicator on the dock power button turns to solid white, the update is completed. The update

takes e ect when you reconnect the dock to your computer.

Install Lenovo Dock Manager

Lenovo Dock Manager is designed to provide silent irmware update and device in ormation query.

To download Lenovo Dock Manager, go to https://support.lenovo.com/us/en/solutions/ht037099.

6ThinkPad Universal USB-C Dock ThinkPad Universal USB-C Smart Dock User Guide
