LENCO TAB-1012 Manual de usuario

USER'S MANUAL

TAB-1012

For information and support,www.lenco.eu

Features

Enjoy in the comfort of your living room

Enjoy your media library anywhere

Portable powerhouse plays popular music,

video,and photo formats

microSD memory card reader

Increase your storage capacity (up to 32 GB

supported)

Built-in camera

Convenient front-facing camera and back

camera

Automatic orientation detection

Read any way you want; the display adjusts

automatically!

Reading books in the ePub format requires the

E-book reader application.

Requires optional HDMI cable

(Type A-to-Type C). 1080p HD video playback

requires a video file encoded at 1080p.

Streaming video quality will be affected by the

source, and the quality and condition of your

network connection.

Features

Browse the Web.

Visit your favorite websites

Check your e-mail

Keep in touch with friends and family

Watch YouTube™ videos

Browse the world’s most popular

video-sharing community

Read your favorite books

Download thousands of books with the

included E-book reader *

Discover thousands of apps for Android™

Games, applications, and more with

marketplace(need for customer installed)

Connect to the Internet wirelessly

High-speed Wi-Fi 802.11 b/g/n networking

HDMI™ output to your TV ™

Unit at a Glance

1．ON/OFF

Press on/off to turn the table on/off/sleep

/weak up.

2. VOL-/VOL+

Press VOL- to decrease the volume level.

Press VOL+ to increase the volume level.

3.USB HOST

Connect to a USB device

4. Earphone

Audio output connection for headphones.

5.USB OTG

Connect to a USB device or a computer to

transfer

data (e.g. music, videos,photos, files).

6.MIC

Record audio.

7. DC 12V

Charge and power the tablet with the included

power adapter.

8. microSD

Load external microSD memory cards here.

9. HDMI

Connect to a TV or other displays.

Getting Started

Turning the Tablet on or off

To turn the tablet on:

Press and hold the Power key until the LCD

screen turns on. Wait until the Home screen

appears; the tablet is now ready for use.

To turn the tablet off:

1.Press and hold the Power key until the

Device Options menu appears.

2. Touch ok the screen to turn off the tablet.

Turning the Screen On or

off (Standby)

When the tablet is on, you can turn off the

screen to conserve battery power. Simply

press the Power key once to turn the screen

off. Press the Power key again to turn the

screen back on.

To conserve battery power, the screen

can be set to turn off automatically when the

tablet is not in use (between

1 minute and 30 minutes).

This Screen timeout option can be found in the

Display menu.

Getting Started

Unlocking the Screen

When the screen turns off, you will have to

unlock the screen,when you turn it back on.

To unlock the screen, drag the lock icon

across the screen towards the lock icon.

About Applications

To open an application, touch the application

icon on the home screen or in the Launcher

where you can tap the icon right up on the

home screen to get in..

Launcher screen:

The screen shown above is for illustrative

purposes only. Reserves the right to modify

and improve the final list of applications

available on the tablet.

About Applications

Preinstalled Applications

Some applications have been installed on

your tablet for your convenience.

These applications include:

Browse the web.

Perform simple mathematical

operations.

Take pictures or videos with the

frontfacing camera.

Check your e-mail.

Play music

Access the Settings menu to adjust the

tablet’s options.

Preinstalled Applications

Installing Applications

You can also download an install additional

applications from the device’s applications

marketplace, the web browser, or other

sources.

The tablet must be set to allow installation of

applications from non-Market sources. The

Unknown sources option can be set in the

Application settings menu.

Connect to a Wi-Fi network

The Notification bar displays icons that

indicate your tablet’s Wi-Fi status.

There are no Wi-Fi networks in range,

or the Wi-Fi radio is off.

1. Turn on the Wi-Fi radio if it is not already on.

To turn on Wi-Fi:

a.Go to the Home screen: Press the Home key.

b.Open the Settings menu: tap the icon right

up on the home screen to get into the launcher,

then touch Settings icon.

c.Open the Wireless & networks menu: Slide

the icon to ON status.

Notification that an open

Wi-Fi network is in range.

Connected to a Wi-Fi network

(waves indicate connection strength).

[no icon]

When Wi-Fi is on, the tablet will look for and

display a list of available Wi-Fi networks.

If a network that you have connected to

previously is found, the tablet will connect to it.

If you don’t see your network in the list, you

can force the tablet to re-scan. To scan for

networks, tap the Menu key, and then touch

Scan.

2. Select an available Wi-Fi network to

connect to: In the same Wi-Fi settings menu

above,touch a network in the list.

If the network is open,the tablet will prompt

you to confirm connection to the network.

Touch Connect to confirm.

If the network is secured (as indicated by a

Lock icon),the tablet will prompt you to enter a

password or other credentials.Touch the

Wireless password box to show the on-screen

keyboard and then use it to enter the password.

Touch Connect to confirm.

When you have successfully connected to a

Wi-Fi network, the Notifications bar at the the

low of the screen will show a Wi-Fi signal

indicator.

To learn about how to add a Wi-Fi network

when it is not in range or when the router is set

to obscure the network name (SSID); or to

configure advanced Wi-Fi options, please

refer to the manual.

Optional Connections

Connecting to a Computer

Connect the tablet to a computer to transfer

files.

1.Connect your tablet to the computer.

With the included USB cable: Plug the small

end of the cable into OTG connector of the

tablet. Plug the large end of the cable into an

available USB 2.0 high speed port on the

computer.

2.When your tablet is connected, slide up the

USB icon right down on the screen and then

touch icon USB connected.

3.Mount the storage.

Touch button Turn on USB storage to mount

the tablet’s built-in storage. When it is

mounted, you can copy files to or from your

tablet.

To connect the tablet to the TV:

1. Plug the small end of the HDMI cable into

the mini HDMI connector on the tablet.

2. Plug the large end of the HDMI cable into

the HDMI port on the TV.

3. Turn on the TV, and set its display mode to

the HDMI port that the tablet is connected to.

If you need help setting the display mode of

the TV, please refer to the documentation

provided by the TV manufacturer. If there is no

sound from the tablet on your TV, you may

need to set the HDMI switch sound settings.

Specifications

Please visit www.henag.com for the latest

product information. Design, specifications,

and manual are subject to change without

notice.

Display 10.1”TFT LCD(1024x600),

Capactive touch screen

Wi-Fi Networking IEEE 802.11 b/g/n

Video Output Mini HDMI,type C(1080p and

720p supported)

Audio Output 3.5mm headphone

PC Interface USB 2.0 high speed

Additional Features Built-in microphone

Front facing camera(0.3MP)

Back camera(2MP)

2X1.5W speaker

Operating System Android™ 4.0

Power Rechargeable Li-poly battery

power

Adapter(DC 12V,2A)

Processor ROCKCHIP2918 1GHz(Cortex A8)

RAM 1GDDR3

Storage 8GB(option) flash built-in; microSD

card slot (max.32GB supported)
