LENCO TAB701 Manual de usuario

ENGLISH

NEED HELP?

As we are often updating and improving our products, your device’s software may have

a slightly different appearance or modified functionality than presented in this Quick Start Guide.

On our Website:See the Frequently Asked Questions section on www.lenco.eu/tab701

12 3

4 4

ENGLISH

DESCRIPTION OF THE DEVICE

Hardware Reset: In the event that your TAB-701 freezes operation, you can press the “pinhole reset” button,

located on the back the device, by using a sharp object such as a toothpick.

Power/Lock: slide left and hold to switch on/off. Slide right to lock the

device’s touchscreen.

When you slide left and hold, a window appears with a list of options (when the product is on).

Tap on “Power Off” to fully shut down your TAB-701.Tap on “Suspend” to put the device in

standby (and allow a quick start up when you next tap the screen).While the device is in suspend

mode, slide right to lock the device with its screen off.This can be useful if your TAB-701 is in your

backpack, for example, and you do not want to wake it up by touching the screen by accident.

Micro-SD card reader

Charging indicator: Red light: battery charging / Yellow: battery charged.

Loudspeakers

Headphone jack

Power connector: to connect the supplied power cable.

USB port:to connect your TAB-701 to your computer, using the included USB cable.

Leg stand: pull it out, and it will allow your TAB-701 to stand by itself on a flat, stable surface.

▲

EUR

ENGLISH

STARTING UP

Installation Wizard

The first time you start up your TAB-701, the installation wizard will bring you through a few screens to help you set up

the principal settings: Language, country, time, etc.

Before using your TAB-701 for the ﬁ rst time, completely charge the battery!

Charging the Battery

Connect the supplied power cable to the TAB-701 Power connector and to a wall outlet.

The TAB-701 device will turn on and start charging. The Power indicator light is red while the battery is charging. It will turn

yellow when the battery is fully charged.

▼

▼▼

▼

▼▼

ENGLISH

THE TAB-701 INTERFACE

Top bar of the Interface (varies according to the screen you are in)

Return to the

Home screen

Return to the

previous screen

Menu: gives menu options ac-

cording to the current screen.

Your TAB-701 device is equipped with a touchscreen. Most screen areas will react when you tap on them with your finger.

Status icons: (WiFi connection

status, battery level, etc.)

Notification icons: drag the top bar downwards

to reveal the notification messages (if any).

These are the default

Android™ shortcuts (Web

Browser, EMail, etc.). Tap on an

icon to open the correspond-

ing application.You can

customize the Home screen

by adding/removing shortcuts

and widgets, changing the

wallpaper, etc. See next page.

Home Screen

Applications Tab

Tap on this icon to reveal all the An-

droid™ applications installed on your

TAB-701 (games, various tools, etc.).

You can copy them onto the Home

screen.You can get more Android™

applications from the AppsLib which

can be found on the Home screen.

Time Volume -/+

ENGLISH

Customizing the Home screen items

To add a Home screen item (shortcuts, widgets, etc.), hold your finger on the screen at an empty location, then choose from-

the list.You can also tap on the Menu icon and select Add

To add a Home screen item (shortcuts, widgets, etc.), hold your finger on the screen at an empty location, then choose from

, at the bottom of the screen.

To move a Home screen item, hold your finger onto it until it gets larger, then drag it to the desired location, and release-

your finger.

To remove a Home screen item, hold your finger onto it, drag it onto the recycle bin (while you’re holding an item, the-

Applications tab, on the right side of the screen, turns into a recycle bin) and release your finger.

CUSTOMIZING YOUR PRODUCT

Changing the Settings:From the Home screen, tap on the Menu icon , tap on Settings

and choose a category: Wireless controls, Sound & display, Date & time, etc.

The extended Home screen

Slide your finger horizontally on

the screen to go to the left or right

side of the extended Home screen.

Adding more applications with APPSLIB :With the TAB-701 connected to the Internet, tap on

the AppsLib icon

Adding more applications with APPSLIB

.This online library of free and purchasable applications has thousands of

fun games and useful applications to download and use.

www

ENGLISH

CONNECTING TO THE INTERNET

First of all, you need to configure a WiFi network. For this procedure to work, you need to be in a WiFi zone that will

allow you to connect to it. Every time the TAB-701 is in range of a network that you have already configured once, it will

attempt to make a connection.

* For free access WiFi points, there is no need to enter any special information. For secured networks, you will need either a key (a series of numbers and/or letters)

of the type WEP, WPA, or WPA2. Check with the person who manages the WiFi network to obtain the exact connection parameters required.

To configure a new WiFi network, go on the Home screen, tap on the Menu icon , then

select Settings

To configure a new WiFi network, go on the Home screen, tap on the Menu icon

In the Settings screen, select Wireless controls.

If the WiFi is off, tap on the Wi-Fi line to turn it on. Then select Wi-Fi settings. The TAB-701

will scan for available WiFi networks and display them at the bottom of the screen.

Tap on the network you want to connect to, enter the required network information* and then tap on Connect.Your

TAB-701 will now attempt to establish a connection to that WiFi hot spot with the network parameters you entered.

ENGLISH

PLAYING MULTIMEDIA FILES

From the Home screen, tap on the video, audio or photo application.

The TAB-701 will display a list of ﬁ les or folders corresponding to the selected category.

Tap on an item to start playing it.

Only inVideo and Photo modes: to display/hide the on-screen controls, tap anywhere on the screen.

To pause or resume a video, tap on the icon / (bottom of screen).To go to any particular point in the video,

slide the progression bar to the desired point.

To play the next or previous song, tap on the icons / . Use the icons / and the progression bar as

in the video player screen (see above).

To start or pause a slide show, tap on the icon

.To view the next or previous photo, tap on the icons / .

Video

Music


USB

ENGLISH

TRANSFERRING MEDIA TO YOUR TAB-701

COMPUTER

TURNED ON

Connect the supplied USB cable to the TAB-701 and to a running computer.

The TAB-701 will turn on and ask you if you want to connect it. Tap on “Mount” to connect it. Within a few seconds the

TAB-701 will appear as an icon on your computer.

You can transfer your media files to the TAB-701 either by copy/pasting them into the respective folders using Win-

dows® Explorer (or the Finder on a Mac®), or by using Windows Media® Player. Open Windows Media Player® and then

use the Sync tab to synchronize your music, videos, and photos onto your TAB-701. See Windows Media Player®’s Help

to learn more about this.

Once all your file transfers are finished, closeWindows® Explorer and any other program that may have read or written to

the TAB-701. Click on the ‘safely remove’ icon in the system tray, next to the clock.You can now unplug the USB cable.

FRANÇAIS

BESOIN D’AIDE ?

Comme nous mettons à jour et améliorons régulièrement nos produits, le logiciel de votre appareil peut présenter une

interface ou des fonctionnalités légèrement différentes de celles décrites dans ce guide.

Sur notre site Web:Consultez la Foire Aux Questions (FAQ) sur www.lenco.eu/tab701

12 3

4 4

FRANÇAIS

DESCRIPTION DE L’APPAREIL

Réinitialisation de votre appareil : Si votre TAB-701 venait à se bloquer totalement, vous pouvez appuyer sur

le bouton reset, situé au dos du produit, en utilisant un objet pointu tel qu’un trombone.

Marche/Arrêt/Verrouillage : Faites glisser vers la gauche et maintenez pour

allumer/éteindre. Faites glisser vers la droite pour verrouiller l’écran tactile.

Lorsque vous faites glisser ce bouton vers la gauche et le maintenez, une fenêtre apparaît avec une liste

d’options (lorsque le produit est en marche).Appuyez sur “Eteindre” pour éteindre votre TAB-701 com-

plètement.Appuyez sur “Mettre en veille”(Suspend) pour mettre l’appareil en veille (et permettre un

redémarrage plus rapide en touchant l’écran).Lorsque l’appareil est en veille,faites glisser le bouton vers

la droite pour verrouiller l’appareil avec l’écran éteint. Cela peut s’avérer utile si votre TAB-701 se trouve

dans votre sac à dos, par exemple, et que vous ne voulez pas le réveiller en touchant l’écran par accident.

Lecteur de cartes Micro-SD

Témoin de charge - rouge : batterie en charge / jaune : batterie chargée

Haut-parleurs

Prise casque

Connecteur d’alimentation :pour connecter le câble d’alimentation fourni.

Port USB : pour connecter votre TAB-701 à un ordinateur, à l’aide du câble USB fourni.

Béquille : sortez-la, et elle vous permettra de faire tenir votre TAB-701 sur une surface plane et stable.
